Page SAMSUNG TECHWIN 89 SM451 C over Ass’y (1/3)
Page
SAMSUNG TECHWIN
88
SM451
Cover Ass’y (1/3)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
A-1 J90521065A COVER ASSY SM421P 1
1 J70521027B UPPER COVER FL 2 J70521026A
2 J91651041A COVER FRAME TOP 1 ASSY 2
3 J70521039C TOP SIDE COVER R 1 J70521039A
4 J3212049A AREA SENSOR 4
5 J70521040C TOP SIDE COVER L 1 J70521040A
6 J70521027B UPPER COVER FL 2 J70521027A
7 J91651046A COVER_FRAME_SUB_R-ASSY 1 J91651048A
8 J70521376C COVER FRAME REAR R 1 J70521376B
9 J70521379C COVER FRAME FRONT L 1 J70521379B
10 J91651047A COVER FRAME SUB L ASSY 1
11 J70521378B TOP COVER-2 1 J70521378A
12 J7070297A MONITOR CABLE COVER 1
13 J73520001B DOOR CUSHION 4
14 J70521053B CONVEYOR COVER 2 J70521053A
15 J70521038B UPPER SIDE COVER 2 J70521038A
16 J70521025B SM330 LOWER OP PANEL 2
A-2 J90721029A NON SCANNER ASSY 1 OPTION
A-3 J91731033A AREA SENSOR ASSY 1
