- 12 -

4.3. Component placement Cycle Time

(The Number of Component to Be Placed Per Hour)

① Laser recognition

(Unit: CPH)

KE-3010 KE-3020V/3020VR

Reference rail Front reference Rear reference Front reference Rear reference

PWB size

Component height

M L XL M L M L XL M L

6mm

18,500 18,500 18,500 17,500 15,500

- - - - -

12mm

17,100 17,100 17,100 16,500 15,000 17,100 17,100

16,500 15,000

20mm - - - - -

15,900 15,900

14,500 14,000

25mm

- - - - - - -

15,300

- -

*1： This is the number of components to be placed for one hour when 400 pieces of 0603 and 1005 capacitors

are placed onto a 200 mm x 200 mm board at an angle of 0, 90, 180 and 270 degrees sequentially. (This

method conforms to the IPC9850 regulation.)

*2： Electric feeders are used as a component supply device.

*3： KE-3020V and KE-3020VR place components in sequence by simultaneous pick-up of the 6 nozzles of the

LNC60 head.

*4： Since the 0402 components require to be placed in the particular sequence, when only the 0402

components are placed the placement cycle time is reduced to approximately half.

*5： For the rear reference, each value indicates the cycle time to be applied when components are placed from

a tape feeder attached on the front side.

*6： The cycle time will take longer by up to 3% when the placement monitor is used. In addition, when the

setting “The system pauses if a component existence error occurs” is enabled, the cycle time will take

longer by up to 30%.

- 13 -

② Image recognition

(Unit: CPH)

Head

KE-3020V

KE-3020VR

KE-3010

（

MNVC

）

LNC60

＋

IC head

LNC60

PWB size

Supply form

M L XL M L XL

Feeder simultaneous

pickup

9,470 9,350 7,100 9,000 9,000 7,000

DTS 5,100 5,100 4,000 5,100 5,100 4,000

MTS(TR5SNX) 5,100 5,100 4,000 5,100 5,100 4,000

MTC(TR6SNV) 1,300 1,300 1,100 1,300 1,300 1,100

Head

KE-3020V

KE-3020VR

KE-3010（MNVC）

IC head(1 nozzle)

LNC60 (1 nozzle)

PWB size

Supply form

M L XL M L XL

DTS 2,400 2,400 2,000 2,400 2,400 2,000

MTS(TR5SNX) 2,300 2,300 1,900 2,300 2,300 1,900

MTC(TR6SNV) 1,300 1,300 1,100 1,300 1,300 1,100

*1： This is the number of components to be placed for one hour when 36 pieces of QFP and BGA whose outer

dimension is 10 mm x 10 mm or less are placed onto a 330 mm x 250 mm board at an angle of 0, 90, 180

and 270 degrees sequentially.

：

For a tape feeder, it indicates the placement cycle time to be applicable when lead components whose outer

dimensions are 10 mm x 10 mm or less are placed from a tape feeder attached on the rear side.

*3： Component height is 12 mm for M and L machine and 25mm for XL machine.

*4： The time for ATC replacement, board transport and BOC mark recognition is excluded.

- 14 -

4.4. Nozzles

Various types of nozzles have been designed to increase the reliability of placement of each type

of components as shown in the table below.

You can select one of the nozzle sets shown in Table 1: as the standard nozzles supplied.

Table 1 Nozzles supplied as the standard devices

Nozzle

Nozzle assembly

Applicable components

(reference) and remarks

NO.

Internal

diameter of a

nozzle

External

diameter of a

nozzle

A B D E F G H

Std.

Nozzle

Select

500

2-φ0.4 1.0 x 0.5 − 6 − − − − −

* See

Note 1

1005, 1608, 2012 *See Note2

SOT (Molding: 1.6 x 0.8)

501

φ0.25 0.7 x 0.4 − − 6 − − −

0603

502

φ0.4 φ0.7 6 − 6 3 − − 3

1005

503

φ0.6 φ1.0 6 − 3 6 3 6 3

1608, 2012, SOT (Molding:

1.6 x 0.8), SOT (Molding: 2.0

x 1.25)

504

φ1.0 φ1.5 − 4 1 3 6 6 3

2012, 3216, SOT23, SOT

(Molding: 2.0 x 1.25)

505

φ1.7 φ3.5 1 2 − 3 3 1 3

Aluminum electrolytic capacitor

(small), tantalum electrolytic

capacitor, trimmer

506

φ3.2 φ5.0 1 1 − 1 3 1 3

Aluminum electrolytic capacitor

(medium),

SOP (narrow type),

SOJ, Connector

507

φ5.0 φ8.5 1 1 − − 1 1 1

Aluminum electrolytic capacitor

(large),

SOP (wide type),

TSOP, QFP, PLCC, Connector

508C

φ8.0 φ9.5 1 1 1 1 1 1 1

QFP, PLCC, BGA

Total number of nozzles 16 15 17 17 17 16 17 15

* Total number of nozzles that can be installed onto an ATC station: 36 pieces (Standard nozzles 34

pieces and up to large-size standard nozzles 2 pieces)

Note 1 As a Std. Nozzle Select, you can select 15 nozzles among those whose number is from 500 to 508C.

However, you have to select a nozzle to be used for calibration of the machine:

・ For laser calibration (one of the nozzles choose from 500, 502 and 503)

・ For image calibration (508C nozzle)

Note 2 Since a theta error may occur due to the shape of the surface of a 2012R component to be picked up

(such as differences of manufactures and/or resistance values), use a No. 504 nozzle if you have to

place 2012R components in the high density (the gap between the adjacent components: 0.3 mm or

less).

Limitation on nozzles to be used

(1) Limitation on nozzles used on the LNC60

The LNC60 head cannot be used together with a large nozzle.

(2) Limitation on nozzles used on the IC head side of KE-3020V

The IC head of KE-3020V is intended for components of □ 3mm or more. Accordingly,

the following nozzles cannot be used because their nozzle ends are thin. (The IC head

(FMLA) of KE-3020VR has no limitation for use (except the 509 nozzle)).

Nozzle No. under limitation for use

Standard nozzle

500, 501, 502, 503

Optional nozzles

Other nozzles than the nozzle attached as standard are optional. In addition to the nozzle

dedicated for 0402 (509 nozzle), nozzles matched to different-shape components are

prepared. For details, please ask JUKI sales or dealer.
