- 17 - 4.7. A ppl icabl e PWBs 4.7.1. PWBs tra nsport direction Rightward flow (transporting from left to right, looking from the front side) Leftward flow (transporting from right to left , looking from the front side) …

- 16 -

(2) Lead component and ball component Unit: mm

KE-3010 KE-3020V /3020VR

MNVC

（option for KE-3010）

Lead pitch

Laser

recognition

LNC60

0.65 or more

FMLA

（KE-3020VR only）

0.65 or more

VCS recognition

Standard camera

0.38

～

2.54

High accurate camera - 0.20～2.54

Ball pitch

Laser

recognition

LNC60

1.00

～

1.27

FMLA - 1.00～1.27 -

VCS recognition

Standard camera

1.00

～

3.00

High accurate camera - 0.25～2.00

Ball diameter VCS recognition

Standard camera

0.4

～φ

1.0

High accurate camera - φ0.1～φ0.63

4.6. Component Placement Accuracy

*1 The regulated value of a component to be recognized with laser is “Cpk ≥ 1.”

*2 The placement accuracy that can be obtained when a placement position is corrected by

recognizing component image shall be the absolute value from the component reference

mark or PWB reference mark.

*3 The placement accuracy of a 0402 component described below is realized if local fiducial

marks are used, the distance between two marks is 20 mm or less, and a 0402

component is placed within the mark.

(1) Placed positions (X, Y)

(Unit:μm)

Laser

Vision (VCS)

LNC60

FMLA

MNVC

IC head

Square chip

0402, 0603

± 50 ― ― ―

Square chip

1005 or bigger

± 50 ± 50 ― ―

QFP

(Pitch: 0.5, 0.4, 0.3)

± 40

(When a component positioning

mark is used)

± 30

(When a component positioning

mark

is used)

(2) Placed posture (

) (Unit:°)

Laser Vision (VCS)

LNC60

FMLA

MNVC

IC head

Square chip

0402 ±5.0 ―

― ―

0603 ±3.0 ―

1005 ±2.5 ±2.5

1608 or more ±2.0 ±2.0

QFP

(Pitch: 0.5, 0.4, 0.3)

50 mm or more

―

－

0.04

From 40 mm to less than 50 mm

― ― － ±0.05

From 30 mm to less than 40 mm

― ― ± 1.11 ±0.07

From 20 mm to less than 30 mm

― ― ±0.12 ±0.1

From 10 mm to less than 20 mm

― ― ±0.22 ±0.2

10 mm or less

―

0.33

0.3

Adjacent pitch

- 0402: 0.15 mm

- 0603: 0.20 mm

- 17 -

4.7. Applicable PWBs

4.7.1. PWBs transport direction

Rightward flow (transporting from left to right, looking from the front side)

Leftward flow (transporting from right to left, looking from the front side)

Note

：

This direction is set at the factory (Factory-set).

4.7.2. PWB sizes and Mass

(1) PWB sizes

(Unit: mm)

Minimum size (D

x W

) Maximum size (D

x W

) Thickness T

M PWB

specification

50×30

(When the auto PWB width

adjusting function is provided:

50 x 50)

330×250

(When a function applicable to

long PWB is provided: 650 x

250)

0.3～4.0

L-PWB

specification

410×360

(When a function applicable to

long PWB is provided:

800 x 360)

L-Wide

specification

510×360

(When a function applicable to

long PWB is provided:

1010 x 360)

XL-PWB

specification

610×560

(When a function applicable to

long PWB is provided:

1210 x 560)

Note 1: “D” indicates the dimension in the board transport direction, and “W” indicates the direction

perpendicular with “D” W/D should be 2 or less.

Note 2: Contact us for a notched board or board whose shape is irregular.

Note 3: A PW B whose reflection ratio is low may not be able to be detected regardless of its material

or color.

(2) Maximum allowance of PWB mass :2,000 g

(3) Allowable warpage of a PWB

0.2 mm or less per 50 mm area, and 1 mm or less for both upper and lower directions

(these values conform to the JIS B 8461 regulation.)

- 18 -

6 mm (Pin diameter + 2.0 mm) *1

4.7.3. Unavailable areas for placing components on the board

*1: When you select the pin diameter from 1.8 mm to 2.0mm or from 2.5 mm to 4.0 mm, any component cannot

be placed in the area including the pin diameter plus 2 mm. (This rule shall be applied to the following

board type.)

M PWB specification

PWB transport direction

Placement disable range

3mm

5±0.1mm

～

330mm

3mm

～

250mm

50 to 250 mm for the auto PWB width adjusting function

Transport rail fixed side

PWB transport direction

Placement disable range

3mm

5±0.1mm

～

410mm

3mm

～

360mm

50 to 250 mm for the auto PWB width adjusting function

Transport rail fixed side

L PWB specification

5±0.1mm

When the diameter of the reference pin is 4 mm
