5.2.27. Multi-code Reader / Bottom view type Multi-code Reader (Factory-Set

Option)

This is an option that reads a PWB code (Barcode or 2-D code) with one sensor. It is to be

used with the IFS-NX software and so.

Attach a multi-code reader on the head section to read a code on the surface of a board.

Attach a bottom view multi-code reader on the conveyor (under the IN buffer board waiting

position) to read a code on the bottom side of a board.

Note: A multi-code reader/Bottom view type multi-code reader does not support a placement

monitor.

5.2.28. Software to support production (Option)

(1) EPU (External Programming Unit)

This is software for creating a production program for KE-3000 series on a personal

computer (PC). The screen displayed on a PC is exactly same as that of the machine.

Even while a machine is running productions, you can edit a production program and

manage a database on a PC with this software.

(2) Flexline CAD

With this software you can convert text data files in ASCII format and production

programs created with a CAD system for other manufacture’s machines to the JUKI

format. This permits reducing the production program creating time and transferring data

smoothly from the line of another company.

For

detailed information on converting data from other manufacture’s machine, pleas

ontact JUKI or the representative office in your area.

(3) IS (Intelligent Shopfloor Solutions) : Production support system

In addition to the functions of HLC and SCS, IS allows you to obtain information on the

whole shop floor to optimize and manage the production collectively. This comprehensive

management system supports you to reduce cost, and to improve productivity and

product quality effectively. The ”Board viewer” function is equipped as a standard feature.

Also a production plan for a whole shop floor can be created.

* For

details of IS, refer to “IS PRODUCT SPECIFICATIONS”.

(4) IFS-NX (Intelligent Feeder System) : Production management system

IFS-NX can use alone a software without the production support system.

It uses barcodes, 2-D codes and a multi-code reader to perform quality control operations

such as “prevention of a component placement error” and “traceability,” “improve the

workability of preparations” and “manage the number of the remaining components.”

To authenticate a feeder or a tray supply unit, you can select a barcode or an RFID.

When you use a component supply unit that supports an RFID, operation such as

verification and management can be automated, so that the quality control and working

efficiency are improved drastically.

* To use a function of IFS-NX, all of a mounter main unit, a feeder exchange trolley, each

type of feeder, and a tray supply unit have to support an RFID. If you use any

conventional device, contact our Sales staff.

* Refer to the “IFS-NX PRODUCT SPECIFICATIONS” for details of the IFS-NX.

(5) IS Lite : Production management system

Juki software, the IS, has been simplified to develop the IS Lite. This software

consolidates and optimizes information on JUKI mounters allocated on the whole a line

(production site) to improve productivity and to reduce production cost of each line.

Applicable models : RX-6 series, RX-7, KE-3000 series, FX-3 series,

KE-2070/80 series, KE-2050/60 series

- 43 -

(6) JaNets : Production support system

As with our software IS and IS Lite, This software consolidates and optimizes information

on JUKI mounters allocated on the several lines (production site) to improve productivity

and production quality and to reduce production cost of each line.

Applicable models : RS-1, RX-7, RX-6 series, KE-3000 series, FX-3 series, KE-2070/80

series, KE-2050/60 series, KD-2077

* For

line configuration that the RS-1 is located, JaNets is required.

- 44 -

Component supply unit

6.1. List of Feeder Bank Specifications

A bank is selected from five types shown below, which supplies components.

It is possible to combine with a front bank and/or a rear bank according to your usage.

Bank type Attachable feeder type

Attachable feeder exchange

trolley

①

Mechanical feeder bank (fixed

type)

Mechanical feeder

②

Electric feeder bank (fixed type) Electric feeder

③

Mechanical feeder bank feeder

exchange trolley type

Mechanical feeder

Mechanical feeder exchange

trolley only

④

Electric feeder bank feeder

exchange trolley type

Electric feeder

Electric feeder exchange trolley

only

⑤

Mechanical feeder bank and

electric feeder bank feeder

overall change table cart

combined system

Mechanical feeder

Electric feeder

Mechanical feeder exchange

trolley

Electric feeder exchange trolley

* Compatibility of our mounter KE-2010/2020/2040 mechanical type feeder bank

For installing the KE-2010/2020/2040 overall change table cart in the mechanical/electric

feeder bank overall change table cart combined system (No.⑤) of this model, an adapter

component is separately requited.

When installing it in the mechanical type overall change table cart (No.③), no adapter

component is required.

* C

ompatibility of the electric feeder bank of our mounter KE-3020/3020R

For setting the electric change table card for this model in KE-3020/20R, a modification kit is

required depending on conditions.

- When there is a cutter unit in KE-3020/3020R

→ A modification kit is required.

- When there is no cutter unit in KE-3020/3020R

→ A modification kit is not required.

For setting the change table cart of KE-3020/20R in this model, no modification kit is

required.
