- 50 - (3) FTF/FTFR 1) S pecification table ① FT F (12 mm, 16 mm, 24 mm, and 72 mm) Product code Feed pitch Pick- up position (Y dire ction) Applicable co mponent Emboss w i dth Emboss depth FF121S 4mm 132mm 8.3mm or les…
- 49 -
* T
he RFID correspondence of the tape feeder is necessary for using the RFID function of
the production management system.
2) Common specifications
8mm 12mm/16mm 24mm
1 Dimensions L=645mm,
H=213mm,
W=16.8mm
L=693mm,
H=472mm,
W=31.5mm
L=693mm,
H=472mm,
W=40mm
2 Mass (Excluding a reel) 1.8 kg or less 2.45kg or less 2.6kg or less
3 Component transport method Ratchet drive system
3) O
ptions
① Bar code tag (8mm only)
This tag is used to paste a bar code mark onto the rear edge of a tape feeder.
Even after you install a tape feeder on the feeder bank, the pasted bar code can be
read easily.
② E
mbossed tape spacer
To improve the feed and pick-up stability of the carrier tape for the emboss
component made of a soft and fragile material, this spacer is installed in the emboss
groove of the feeder to support the bottom surface of the carrier tape.
A type for 8 mm feeder, type for both 12 mm and 16 mm feeders, and type for 24
mm feeder are available.
③ J
oint tape splicing jig (8mm only)
When you use a JUKI designated joint tape, this jig allows you to paste a joint
tape with glue easily.
④ Joint tape
This is a tape that splices an old tape reel and a new tape reel.
A dedicated type for each tape width is available.
⑤ S
cissors (Tape cutting jig A, and B)
A positional adjustment between the tape feeder used during the production and
a new tape feeder to be connected can be accurately and quickly made by
cutting the tapes with dedicated scissors when they are spliced.
・Tape cutting jig A: Available for feed pitch (4, 12, 20, 28, 36, 44, 52).
・Tape cutting jig B: Available for feed pitch (8, 16, 24, 32, 40, 48, 56).
⑥ T
ag Insert Kit (RFID tag attachment kit)
By attaching a RFID tag on a ATF feeder currently used, you can manage the
feeders with the production management system.
- 50 -
(3) FTF/FTFR
1) Specification table
① FTF (12 mm, 16 mm, 24 mm, and 72 mm)
Product code Feed pitch
Pick-up position
(Y direction)
Applicable component
Emboss
width
Emboss
depth
FF121S
4mm
132mm
8.3mm or
less
6.5mm or
less
FF122S
8mm
FF123S
12mm
FF12FS
4/8/12mm
FF12NS
4/8/12mm
FF161S
4mm
12.2mm or
less
FF162S
8mm
FF163S
12mm
FF16FS
4/8/12/16mm
FF16NS
4/8/12mm
FF242S
8mm
20.2mm or
less
10.5mm or
less
FF243S
12mm
FF244S
16mm
FF245S
20mm
FF246S
24mm
FF24FS
8/12/16/20/24mm
FF24NS
8/12mm
FF724S
12/16mm
62mm or
less
FF728S
12/16/20/24/28/32mm
Dimensions
FF12**
L =693mm, H =472mm, W=31.5mm
FF16**
L =693mm, H =472mm, W=31.5mm
FF24**
L =693mm, H =472mm, W=40.0mm
FF72**
L =693mm, H =472mm, W=89.2mm
Mass
(Excluding a reel)
FF12**: 2.45kg , FF16**: 2.45kg , FF24**: 2.6kg,
FF72**: 5.1kg
Component transport
method
Ratchet drive system
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of
the production management system.
- 51 -
② FTFR (32 mm, 44 mm, and 56 mm)
Product code Feed pitch
Pick-up
position
(Y direction)
Applicable
component
Emboss
width
Emboss
depth
FF323R
12mm
132mm
23.5mm
or less
25mm or
less
FF324R
16mm
FF32FR
8/12/16/20/24mm
FF32FR-OP
8/12/16/20/24/28/32mm
114mm
FF443R
12mm
128mm
33.8mm
or less
FF444R
16mm
FF44FR
8/12/16/20/24mm
FF44FR-OP
8/12/16/20/24/28/32/36/40/44mm
114mm
FF564R
12/16mm
128mm
46.0mm
or less
FF568R
12/16/20/24/28/32mm
114mm
FF56FR
8/12/16/20/24mm
128mm
FF56FR-OP
8/12/16/20/24/28/32/36/40/44/48/56mm
114mm
Dimensions
L =693mm, H =472mm
W= FTFR32**: 47.7mm, FTFR44**: 61.6mm, FTFR56**: 66.0mm
Mass
(Excluding a reel)
FTFR32**: 3.2kg, FTFR44**: 3.5kg, FTFR56**: 3.8kg
Component
transport method
Ratchet drive system
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of
the production management system.
2) O
ptions
① Emboss spacer (FTFR only)
When the component width and length are large and the tape depth is small, t
he
pos
ture stability at component pick-up can be improved by placing the spacer at the
component pick-up position of the tape feeder.
The usable emboss depth is 1.0 mm to 8.0 mm.
② T
ag Insert Kit (RFID tag attachment kit)
By attaching a RFID tag on a ATF feeder currently used, you can manage the
feeders with the production management system.
* RFID tag cannot be attached on the old type of the FTF feeder.
For further advice, contact JUKI or the representative office in your area.
