- 51 - ② FT FR (32 mm, 44 mm, and 56 m m) Product code Feed pitch Pick- up position (Y dire ction) Applicable component Emboss w i dth Emboss depth FF323R 12mm 132mm 23.5mm or l ess 25mm or less FF324R 16mm FF32FR 8/12/1…
- 50 -
(3) FTF/FTFR
1) Specification table
① FTF (12 mm, 16 mm, 24 mm, and 72 mm)
Product code Feed pitch
Pick-up position
(Y direction)
Applicable component
Emboss
width
Emboss
depth
FF121S
4mm
132mm
8.3mm or
less
6.5mm or
less
FF122S
8mm
FF123S
12mm
FF12FS
4/8/12mm
FF12NS
4/8/12mm
FF161S
4mm
12.2mm or
less
FF162S
8mm
FF163S
12mm
FF16FS
4/8/12/16mm
FF16NS
4/8/12mm
FF242S
8mm
20.2mm or
less
10.5mm or
less
FF243S
12mm
FF244S
16mm
FF245S
20mm
FF246S
24mm
FF24FS
8/12/16/20/24mm
FF24NS
8/12mm
FF724S
12/16mm
62mm or
less
FF728S
12/16/20/24/28/32mm
Dimensions
FF12**
L =693mm, H =472mm, W=31.5mm
FF16**
L =693mm, H =472mm, W=31.5mm
FF24**
L =693mm, H =472mm, W=40.0mm
FF72**
L =693mm, H =472mm, W=89.2mm
Mass
(Excluding a reel)
FF12**: 2.45kg , FF16**: 2.45kg , FF24**: 2.6kg,
FF72**: 5.1kg
Component transport
method
Ratchet drive system
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of
the production management system.
- 51 -
② FTFR (32 mm, 44 mm, and 56 mm)
Product code Feed pitch
Pick-up
position
(Y direction)
Applicable
component
Emboss
width
Emboss
depth
FF323R
12mm
132mm
23.5mm
or less
25mm or
less
FF324R
16mm
FF32FR
8/12/16/20/24mm
FF32FR-OP
8/12/16/20/24/28/32mm
114mm
FF443R
12mm
128mm
33.8mm
or less
FF444R
16mm
FF44FR
8/12/16/20/24mm
FF44FR-OP
8/12/16/20/24/28/32/36/40/44mm
114mm
FF564R
12/16mm
128mm
46.0mm
or less
FF568R
12/16/20/24/28/32mm
114mm
FF56FR
8/12/16/20/24mm
128mm
FF56FR-OP
8/12/16/20/24/28/32/36/40/44/48/56mm
114mm
Dimensions
L =693mm, H =472mm
W= FTFR32**: 47.7mm, FTFR44**: 61.6mm, FTFR56**: 66.0mm
Mass
(Excluding a reel)
FTFR32**: 3.2kg, FTFR44**: 3.5kg, FTFR56**: 3.8kg
Component
transport method
Ratchet drive system
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of
the production management system.
2) O
ptions
① Emboss spacer (FTFR only)
When the component width and length are large and the tape depth is small, t
he
pos
ture stability at component pick-up can be improved by placing the spacer at the
component pick-up position of the tape feeder.
The usable emboss depth is 1.0 mm to 8.0 mm.
② T
ag Insert Kit (RFID tag attachment kit)
By attaching a RFID tag on a ATF feeder currently used, you can manage the
feeders with the production management system.
* RFID tag cannot be attached on the old type of the FTF feeder.
For further advice, contact JUKI or the representative office in your area.
- 52 -
6.3.2. Tape feeder for electric bank
Electric tape feeders enable the component feeds in stable state that suppresses the
vibration by adopting the motor for the drive system and is steady. Moreover, high
utilization rate is achieved by simplifying the work for changing feed pitch, splicing the
tapes, etc., compared with the former mechanical type feeders.
1) Specifications
EF series Electric feeder
Product
code
Tape type
Feed pitch
Applicable
tape width/
reel diameter
Applicable
component
emboss depth
Remarks
Paper Embossed
EF02HS ○ 2 mm 8 mm -
0402 to
1005
EF08HS
○ ○
2/4 mm
8 mm
3.5 mm or less
0603 to
EF08HD
○ ○
2/4 mm
8 mm
×
2
3.5 mm or less
0603 to
EF12FS -
○
4/8/12 mm
12 mm
17 mm or less
EF16FS
-
○
4/8/12/16 mm
16 mm
EF24FS
-
○
4/8/12/16/20/24 mm
24 mm
EF32FS -
○
4/8/12/16/20/24/
28/32 mm
32 mm
26 mm or less
EF44FS - ○
4/8/12/16/20/24/
28/32/36/40/44 mm
44 mm
EF56FS
-
○
4/8/12/16/20/24/
28/32/36/40/44/48/
52/56 mm
56 mm
EF72FS
-
○
72 mm
EF88FS
○
88 mm
* Use components whose size and tape specifications conform to JIS C0806-3:1999 and
IEC 60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of t
he
pr
oduction management system.
RF
series Electric feeder
Product
code
Tape type
Feed pitch
(mm)
Supported
tape width
Supported
component
emboss depth
Remarks
Paper Embossed
RF04AS
－ ○
1mm
4mm
RF08AS
○ ○
1/2/4mm
8mm
RF12AS
－ ○
2/4/8/12mm
12mm
RF16AS
－ ○
4/8/12/16mm
16mm
0.95 mm or less 4 mm size in general
3.5 mm or less 8 mm size in general 17
mm or less 12 mm size in general 17
mm or less 16 mm size in general
RF24AS
－ ○
4/8/12/16/20/
24mm
24mm
17 mm or less 24 mm size in general
RF32AS
－ ○
4/8/12/16/20/
24/28/32mm
32mm 20 mm or less 32 mm size in general
RF44AS
－ ○
4/8/12/16/20/
24/28/32/36/
40/44mm
44mm
26 mm or less
44 mm size in general
RF56AS
－ ○
4/8/12/16/20/
24/28/32/40/
44/48/52/
56mm
56mm 56 mm size in general
* Use components whose size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
*
P
lease use the Feeder setup stand for the electric feeder (RF-FSS).
* I
t's necessary to change the cutter unit to the latest to use "Feeder exchange trolley RF".
* R
F04AS(Ver. 8.20A or later)
