- 55 - 6.3.4. Feeder setu p stand This is platform for attaching a tape reel onto a tape feeder . Since it allows you to attach a tape reel on a tape feeder while keeping the t ape feeder in position, the tape att achmen…

- 54 -

6.3.3. Feeder calibration jig

This Jig is for calibrating a feeder while monitoring the component pick-up position with a

CCD camera. If you check and calibrate the pick position on a regular basis, you can

maintain the stable pick-up capability.

On support of IFS-NX *Only IFS-NX for a mechanical feeder (JM01) is available.

As an option, if you attach the RFID reader (antenna) onto the jig main unit, you can manage

the maintenance state of each feeder with the IFS-NX system, which records the

maintenance history, the frequency of usage and others for each feeder; For example, the

system indicates a feeder of which pick-up ratio became lower, and displays a list of feeders

that need to be calibrated according to the maintenance interval settings.

* T

o use “Intelli feeder calibration Jig with LCD monitor, “IFS-NX” is required.

Refer to the “IFS-NX PRODUCT SPECIFICATIONS” for “IFS-NX.”

Note 1: A jig tape and tools are required separately when adjust feeder.

Note 2: The RFID correspondence of the tape feeder is necessary for using the RFID function of the

production management system.

For Mechanical Feeder

（

JM01

）

For Electric Feeder

EF-ATG

RF-ATF

Feeders

*See Note1

ATF

8mm to 24mm

*Note2

EF series

electric

eeder

8mm

12mm

16mm

24mm

32mm

44mm

56mm

RF series

electric

feeder

4mm

8mm

12mm

16mm

24mm

32mm

44mm

56mm

CTF,

CTFR

8mm

*Note2

FTF

FTFR

8mm to 72mm

*Note2

32mm to 56mm

*Note2

BF10AS,BF11AS,

BF12BS,BF12CS,

BF25CS,BF28CS,

BF28RS

Specifications

Power supply

Select 100 V - 120 V

or 200 V - 240 V

100 - 240V 100 - 240V

Outer dimension

L=290mm ,

H=480mm,

W=157mm

L=400mm ,

H=710mm,

W=240mm

L=300mm ,

H=710mm,

W=250mm

(

Except for the PC and

the power supply Box)

Mass

- Adjustment jig main unit:

12 kg or less

(including the CCD camera

and lens section)

- Master feeder: 2 kg

- Monitor: 4kg

- Adjustment jig main

unit: 20 kg or less

(including the CCD

camera and lens section)

- Master feeder: 3.5 kg

- Monitor: 4 kg

- Power supply: 2.5kg

- Adjustment jig main

unit: 20 kg

(including the CCD

camera and lens section)

- Master feeder: 3.5 kg

- Power supply: 2.7kg

Environment

During operation

Temperature

10°C to 35°C

Accuracy

guaranty

temperature

20°C to 25°C

Humidity

30% to 80%RH (No condensation)

Altitude 1,000m or less

Transportation or

storage

Temperature

-15°C to 70°C

Humidity

20% to 95%RH (No condensation)

Option for IFS-NX

Options for the RFID system

- Controller (MPC)

- Antenna

－－

- 55 -

6.3.4. Feeder setup stand

This is platform for attaching a tape reel onto a tape feeder. Since it allows you to attach a

tape reel on a tape feeder while keeping the tape feeder in position, the tape attachment

capability is improved and it also functions to prevent a tape feeder from falling.

wo types of packages of feeder setup stand designed for a mechanical feeder are available

in response to applications.

Type Application

Feeder setup stand

(With a stand)

Equipped with pedestal stand: can be installed as desired.

Feeder setup stand

(without a stand)

A user has to fix the platform on a table or similar

substance with screws.

(

1) Specifications

For a mechanical tape

feeder

For an electric tape feeder

FSS (For EF series)

RF-FSS (For RF series)

Power

supply

―

Input side:

90 to 250 V AC

Output side:

DC ± 24 V (± 10 %)

Input side:

90 to 250 V AC

Output side:

DC 24 V DC 5 V

Frequency

―

Input side: 50/60 Hz

Current ―

Input side: 1.5 A

(maximum)

Output side: 4.2 A

(maximum)

Input side: 1.4 / 0.7 A

(100V / 200V) typ.

Output side: 3A

(maximum)

Outer

dimensions

Platform equipped with a

stand:

* When including a

eeder support section

L = 666 mm,

W = 400 mm,

H = 977 ± 50 mm

* Base side only

L = 550 mm,

W = 400 mm,

H = 977 ± 50 mm

* P

latform without a

stand:

L = 187 mm,

W = 127 mm,

H = 187 mm

L=550mm,

W=470mm,

H=950±50mm

L=550mm,

W=470mm,

H=950±50mm

Mass

20. kg (with a stand)

1.5 kg (without a stand)

25 kg (with a stand) 25 kg (with a stand)

Number of

feeders to

which

power can

be supplied

― 1 1

* The outer dimensions and mass described above indicate values to be applied when

any

feeder is not mounted on the platform.

- 56 -

6.3.5. Electric Trolley Power Station

Power supply for an electric feeder exchange trolley

This is an optional unit that supplies power to a feeder exchange trolley for an electric feeder in

order to set a tape onto an electric tape feeder (ETF type) without removing the feeder from the

electric feeder exchange trolley. This shall be used for an electric feeder exchange trolley only.

(1) Specifications

Model

PW01

PW02

Power supply

100 – 120 V/200 – 240 V AC

AC100-120V/200-240V

Frequency

50/60Hz

Rated power

600VA

Output voltage

24 V ± 10 % DC

DC24V±10%

Output current

9.0A(Max)

18.0A(Max)

External

dimensions

(L/W/H)

200mm / 260mm / 545mm 308 mm / 290 mm / 540 mm

Mass

Approximately 9.0 kg

Approximately 16kg

Connectable

feeder exchange

trolley number

1 2

Remarks

It has a built-in MPC-CAN,

can communicate with the

IFS-NX server by connecting

a LAN cable.
