6.7. TR Series

TR series device supplies a mounter with a tray component.

The three types of DTS (Dual Tray Server), MTS (Matrix Tray Server), and MTC (Matrix Tray

Changer) are available. For MTS and MTC, the standard type and non-stop type are

available. In the case of the non-stop type, two tray stackers are used for independent shaft

control and components can be changed without stopping production even if “no components”

occur. (In DTS, the standard mode or non-stop mode can be selected by software.)

*1 TR**R series models that have been used with conventional mounters are not supported.

Regarding the correspondence table for the TR**X series and TR**V series, check “6.7.2

Correspondence table for the TR series.”

*2 TR6DXLX/6SXLX models are to be used exclusively for a mounter designed for an

XL-sized board.

*3: For the wide PWB specification, and fluxer type 2 specification, MTC cannot be installed.

*4: For the fluxer type 3 specification, MTS cannot be installed.

6.7.1. Overview

(1) TR1SNR/TR1EB (DTS, Dual Tray Server)

This is a tray supply device on which two trays can be set, and is to be installed on

feeder bank of the rear bank so that the head of the mounter can pick up components

directly from this tray server. If this device is used in the non-stop mode where a tray

change of the same components is performed alternately, the tray change can be

performed without stopping the main unit at occurrence of “no components.”

Since the head of the mounter directly picks up components from this tray server, even

irregularly-shaped components can be supplied easily.

(2) TR5SNX (MTS, Matrix Tray Server) /TR5DNX (MTS, matrix tray server, non-stop type)

This matrix tray server is to be installed on the rear bank of a mounter, and pulls out all

trays at a time so that the head of the mounter can pick up components directly from the

trays. Since the head of the mounter directly picks up components, even

irregularly-shaped components can be supplied easily.

(3) TR7DN (MTS, high-speed matrix tray server, non-stop type)

This device is installed in the rear bank. With a two sets of tray tracker (hereinafter

called stacker), components are transported and supplied alternately on the same plane

from the tray stacker to the pickup position. When same components are set in both

stackers, they can be supplied automatically without stopping the main unit from the

other stacker even if one stacker becomes empty.

(4) TR6SNV, 6SXLX (MTC, matrix tray changer)/TR6DNV, 5DXLX (MTC, matrix tray

changer, non-stop type)

This is a tray changer equipped with a shuttle type conveyor that supplies various types

of tray components.

This can supply a mounter with tray components without reducing the number of tape

feeders provided.

Note: When Barcode is used for the traceability, MTC (TR6SNV/6DNV) cannot be used

with a mounter, of which transport direction is “Right to Left”.

- 62 -

6.7.2. Correspondence table for the TR series

Model KE-3010/3020V/3020VR

Board specifications M,L XL

MTS

TR5SNX

○

TR5DNX

○

TR7DN

○

MTC

TR6SNX

TR6SNV

○

TR6SXLX

○

TR6DNX

TR6DNV

○

TR6DXLX

○

6.7.3. Specifications

(1) MTS specification

Model

TR5SNX

TR5DNX

TR7DN

Method for supplying a mounter

Direct supply from the tray

Applicable bank specification

Overall change table system

Tray unit

(*1)(*2)(*3)

(*4)(*8)

Size of a tray that

can be supplied

Width: 150mm～340mm

Length:90mm～230mm

Thickness: 5mm～23mm

Mass (*6)

500 g or less/tray

(Total of the mass of a tray and that of a component(s))

Component size

Maximum □ 74 mm and 50 x 150 mm

Mass

217kg (Standard)

220kg (EN)

287kg (Standard)

290kg (EN)

310kg (Standard)

320kg (EN)

Occupied position

Voltage of the power supply

Single-phase 200､220､240､380､400､415 V AC

(supply from the mounter side)

Apparent power

800VA

600VA

1.0kVA

Air consumption (normal)

3L/min

5L/min

6L/min

RFID option (*7)

Applicable

- 63 -

(2) MTC specification

Model

TR6SNV / TR6SXLX

TR6DNV / TR6DXLX

Method for supplying a mounter

Supplying components by a shuttle

Applicable bank specification

Tray unit

(*1)(*2)(*3)(*4)

Number of units 20 30（15×2）

Size of a tray that can be

supplied

Width: 150mm to 340mm

Length: 90mm to 230mm

Thickness: 5mm to 15mm

Mass(*6)

500g or less / tray

(Total of mass of a tray and that of a component(s))

Component size(*5)

□5mm to □50mm

Mass

226kg (Standard: TR6SNV)

231kg (EN: TR6SNV)

235kg (Standard: TR6SXLX)

240kg (EN: TR6SXLX)

325kg (Standard: TR6DNV)

331kg (EN: TR6DNV)

334kg (Standard: TR6DXLX)

340kg (EN: TR6DXLX)

Pick up pad 2 types: φ11mm and φ4.8mm

Length of the transportation rails

840mm(L)

740mm(XL)

840mm(L)

740mm(XL)

Voltage of the power supply

Single-phase 200, 220, 240, 380, 400, and 415 V AC (supply

from the mounter side)

Apparent power

900VA

1kVA

Air consumption (normal)

50 L/min

RFID option(*7)

Applicable

(3) DTS specification

Model

TR1SNR

TR1EB

Method for supplying a mounter

Direct supply from the tray

Applicable bank specification

Mechanical bank

Electric bank (*9)

Tray unit[

(*1)(*2)(*3)

Size of a tray that can be

supplied

Width: 150mm～340mm

Length: 90mm～230mm

Thickness: 5mm～27mm

Mass 500g or less / tray

(Total of mass of a tray and that of a component(s))

Component size

Maximum

□

74mm

、

150mm

Mass

16kg

19kg

Occupied position

Operating voltage

DC 24V±10%

RFID option(*7)

Applicable
