d-YTF_YGR_mpl_e.pdf - 第9页
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level 1 KGX-M13A2-L0 CO VER 2,DOOR-L 1 / 39 2 KGX-M13A2-R0 CO VER 2,DOOR-R 1 / 40 3 KJF-M13A3-00 GUIDE RA CK DOOR 2 A …
20
13
33
33
36
36
34
22
22
21
20
35
14
15
29
14
17
16
27
28
5
7,8
26
3
32
26
25
6
37
23
31
9
2
1
4
10
10
32
11
24
35
30
18
12
19
21
30
KJF-0902
2
2
Acryl/Rear/LS-Axis
Cover
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KGX-M13A2-L0 COVER 2,DOOR-L 1 /
39
2 KGX-M13A2-R0 COVER 2,DOOR-R 1 /
40
3 KJF-M13A3-00 GUIDE RACK DOOR
2
A
41
4 KGX-M13A7-00 STOPPER BOLT 3 /
42
5 KGX-M13A8-00 BRACKET STAY 1 /
43
6 KGF-M1313-00 CHANNEL HINGE 1 /
44
7 KGF-M1316-00 STAY L 1 for Left /
45
8 KGF-M1316-10 STAY R 1 for Right /
46
9 KGF-M1335-00 PULL 1 /
47
10 K16-90105-00 BOLT, 5 4 /
48
11 K44-M1354-00 MG. CATCH 1 /
49
12 KGW-M13D1-00 COVER,DOOR ACRYLIC 1 /
50
13 KH2-M1324-00 GRIP 1 /
51
14 KM0-M1346-00 SHOULDER,BOLT 2 /
52
15 KL3-M1348-10 GAS SPRING 1 A
53
16 KGW-M13D6-00X BRACKET 1 SCHMEASAL 1 /
54
17 KL0-M1374-00 PLATE 1 SCHMESAL 1 /
55
18 K46-M1374-10 HINGE 2 2 /
56
19 K16-90101-08 BOLT:TP-M4X8 12 /
57
20 KGW-M13E4-00 COVER,SIDE 2 /
58
21 KGW-M13E9-00 BRACKET MAGNET 2 /
59
22 KJ9-M1354-10 CATCH MG. 2 /
60
23 91314-04006 BOLT HEX.SOCKET HEAD 4 M4X6 61
24 91314-04010 BOLT HEX.SOCKET HEAD 12 M4X10 62
25 91314-05010 BOLT HEX.SOCKET HEAD 2 M5X10 63
26 91317-03010 BOLT HEX.SOCKET HEAD 4 M3X10 64
27 91317-04010 BOLT HEX.SOCKET HEAD 2 M4X10 65
28 91317-05014 BOLT HEX.SOCKET HEAD 2 M5X14 66
29 95307-06600 NUT HEXAGON 1 67
30 92902-04200 WASHER PLAIN 4 68
31 92903-04200 WASHER PLAIN 4 69
32 98704-03006 SCREW FLAT HEAD 4 70
33 90990-12J001 SCREW BIN.HEAD W/W 37 71
34 90990-12J003 SCREW BIN.HEAD W/W 12 72
35 98904-04008 SCREW BINDING HEAD 14 73
36 98502-03005 SCREW PAN HEAD 4 74
37 99001-04600 CIRCLIP : 2 75
38 76
KJF-0902
2
2
Acryl/Rear/LS-Axis
Cover
11
2
10
4
4
14
5
9
13
6
7
12
3
15
15
15
1
8
12
KJF-0902
3
1
Z-Axis
Moving-axis
