User Manual S-23 HM 2 Operational Safety Software Vers ion SR.405.xx 05/99 Iss ue 2.1 Safety instructions 49 È The key for ope ning con trol and s ervo u nit do ors and the key for the key swi tch sho uld b e kep t in a …
2 Operational Safety User Manual S-23 HM
2.1 Safety instructions Software Version SR.405.xx 05/99 Issue
48
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
2.1.3 Use as prescribed
WARNING 2
The product must only be used for the applications specified in the catalogs and technical
descriptions, and then only in conjunction with non-Siemens devices and components that have
been recommended or approved by Siemens. For the product to operate correctly and reliably, it
must have been transported, stored, erected and assembled correctly and must be operated and
maintained with care.
2.1.4 Important notes on operational safety
WARNING 2
The following points MUST be observed in order to maintain operational safety: 2
È NEVER open one of the protective covers if you are not totally familiar with the use and func-
tioning of the machine! Do not open the protective covers during operation unless you are told
to do so in this Manual or in the station software dialog.
È Only trained and qualified personnel may set the key switch to set-up mode ("I").
During operation, do not set the key switch to the "I" position (set-up mode) unless prompted
to do so in this manual or by the station software. 2
È NEVER place your head or arms in the gantry travelling range while the station is switched on!
È Never make changes, however minor, unless you are totally aware of the effect they will have
on the overall functioning of the system.
È The stations must always be set up, retooled and maintained by appropriately trained person-
nel.
È Only use Siemens original spare parts and authorized accessories. The use of other parts will
affect safety and may invalidate the liability for any consequential damage.
È The operational safety of SMD automatic placement systems can be guaranteed only if the
system is used as prescribed and in accordance with the instructions in the User/Service Man-
uals.
User Manual S-23 HM 2 Operational Safety
Software Version SR.405.xx 05/99 Issue 2.1 Safety instructions
49
È The key for opening control and servo unit doors and the key for the key switch should be kept
in a place that is only accessible to qualified personnel.
È If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a Siemens service technician. Siemens AG will not accept
liability for any damage or consequential damage that is the result of incorrect work.
È Machine operators must only carry out work for which they have been adequately trained and
with which they are totally familiar.
È Always follow any safety regulations specific to your country.
È Do not make modifications to the safety equipment. In particular, NEVER bypass circuit-break-
ers or remove safety devices.
È If particularly hazardous situations are identified while the machine is in use, the machine
owner must immediately notify the manufacturer in writing so that appropriate action can be
taken to reduce the potential danger.
È Protective devices must NOT be modified. In particular, circuit-breakers must never be by-
passed and protective devices must never be removed.
È If particular hazards are identified while the machine is in use, the machine operator must im-
mediately notify the manufacturer in writing so that the manufacturer can take appropriate ac-
tion to minimise the potential danger.
DANGER 2
This machine is electrically operated. When electrical devices are in use, certain parts carry dan-
gerous voltage levels. Switch off at the main switch and disconnect the placement system from
the power supply before carrying out any work on live components. There is a risk of death, severe
injury and/or considerable damage to equipment if these instructions are not followed. 2
WARNING 2
Despite all the safety measures taken by the manufacturer, severe injury (e.g. from the gantry)
and/or considerable damage to equipment may result if the placement system is operated incor-
rectly. For the machine to be safe, it must be used correctly by qualified personnel and all warn-
ings must be observed. Some work on the machine (e.g. setting up) requires training that goes
beyond the scope of this Manual.
2 Operational Safety User Manual S-23 HM
2.1 Safety instructions Software Version SR.405.xx 05/99 Issue
50
2.1.5 Warning signs on the placement system
The following diagram shows the position of the warning signs on the basic machine. 2
2
Fig. 2.1 - 1 Warning signs on the basic machine - part 1
2
Item 1 from the diagram 2.1 - 1 showing the warning signs on the basic machine 2
1
2
3
3
3
4
3
6
5
