Vision XP+ V AC / XP+ / XP / XS Page 19 2 Mainte nance 2.4 Proces s Chamber Service Instructions V ersion 1.3 2.4.5 Cleaning the Curtains Fig. 2-7 Bottom Curta ins Fig. 2-8 T op curtains (2-par t) Fig. 2-9 Push the clip …
Page 18 Vision XP+ VAC / XP+ / XP / XS
2 Maintenance
2.4 Process Chamber
Service Instructions
Version 1.3
2.4.4 Cleaning the Guide Rails for the Sheet Metal Covers
The guide rails for the sheet metal cover are located at the inlet and the out-
let.
Fig. 2-6 Cleaning the Guide Rails
Consumable materials:
• Oven cleaner
• Rags
Procedure:
1. Raise the process chamber as
far as it will go. Set width
adjustment to the maximum
value and move the center
support to the middle.
2. Unscrew the sheet metal cover
(A) and pull it out.
3. Clean the groove in the top (B)
and bottom (C) guide rails with
a screwdriver, rags and oven
cleaner.
A
B
C
Vision XP+ VAC / XP+ / XP / XS Page 19
2 Maintenance
2.4 Process Chamber
Service Instructions
Version 1.3
2.4.5 Cleaning the Curtains
Fig. 2-7 Bottom Curtains
Fig. 2-8 Top curtains (2-part)
Fig. 2-9 Push the clips up with prying tool
Consumable materials:
• Oven cleaner
• Rags
• Prying tool
Procedure:
1. Raise the process chamber.
2. Lift the curtains out of the
system along with the mounting
bracket.
3. Clean all curtains, the mounting
bracket and the interior of the
process chamber with oven
cleaner and a rag.
If the curtains are excessively dam-
aged they must be replaced.
Procedure:
1. Push up the clips at the left and
right-hand sides of the
mounting rail with the prying
tool.
2. Remove the old curtain.
3. Insert the new curtain.
4. Replace the clips.
Page 20 Vision XP+ VAC / XP+ / XP / XS
2 Maintenance
2.4 Process Chamber
Service Instructions
Version 1.3
2.4.6 Cleaning the Seal
Fig. 2-10 Cleaning the Process Chamber
Seal
The seals must be clean and un-
damaged in order to assure reliable
production.
Consumable materials:
• Appropriate cleaning agent
• Rags
Procedure:
1. Raise the process chamber.
2. Clean the process chamber
seals with industrial alcohol and
a rag.
3. Clean all contamination from
the sheet metal panel at the
mating side of the seal.
4. The seals at the system’s inlet
and outlet must be cleaned
using the same procedure.
Seals
