Safety Instructions for the Compressed Air Supply Safety Instructions

Retrofit Instructions CAN Node X Series SW70x

4.1.4 Safety Instructions for the Compressed Air Supply

4.1.5 Safety Instructions for Work on the Cutting Device

4.1.6 Safety Instructions for the Gantry

CAUTION: Risk of injury from compressed air!

Risk of injury when disconnecting the compressed air lines.

X NEVER detach compressed air lines while they are still pressurized.

CAUTION: Prolonged interruptions to the compressed air supply can cause damage.

When the machine is switched on, do not use the stop valve to interrupt the compressed air

supply for more than 30 minutes.

X If you need to shut off the compressed air system for longer, in order to carry out maintenance

or servicing work, you must switch the machine off at the main switch and disconnect it from

the power supply.

WARNING: Risk of injury when working near the cutter.

If you wish to work on the tape cutter, disconnect the machine from the mains supply and

compressed air supply.

X Wait until the operating pressure has dropped to 0 MPa.

X Always secure the machine against unauthorized reactivation.

X Wear appropriately thick protective gloves when working near the blades and the tape

deflector!

X There is a high risk of injury from stationary blades and moveable blades and from the tape

deflector of the cutter, even when the machine has been turned off!

X Never reach into the pneumatic cutter from below or into the empty-tape duct from above, not

even to resolve a problem (e.g. when tape is jammed).

CAUTION: Risk of injury when performing service work on the cutter.

Never support the cutter on your body, e.g., on your knees or thighs. Do not place your feet

under the cutter.

X Wear appropriately thick protective gloves.

X When removing/fitting the cutter, hold it only on the left and right, on the outside.

X Make sure that no one can injure themselves on the cutter after it has been dismantled!

CAUTION: Moving the gantry can damage the placement head.

When moving the gantry, observe the following:

X NEVER move the gantry by pushing with your hands against the placement head.

X NEVER push the gantry while the Z axis is lowered.

X ALWAYS take hold of the X axis base with your hands to move the gantry.

Introduction

Preparatory Work... Safety Instructions for the Gantry

38 Retrofit Instructions CAN Node X Series SW70x

4.2 Preparatory Work...

Purpose and scope

Before performing any preventive maintenance work or service work, a procedure of locking and tagging

must be followed and warning signs must be attached. The procedure, when followed correctly,

eliminates the possibility of an employee being injured.

Description

Whenever it becomes necessary to isolate, control and release energy, the following procedure is to be

followed.

X Notify affected employees.

X Switch off the machine and all additional devices. Carry out all normal stopping procedures:

 Press the Stop button.

 Shut down the station computer.

 Switch the machine off at the main switch.

X Isolate the machine from all its energy sources:

 Shut off the compressed air supply

 Shut off the main power supply

X Lock out the machine.

 Attach a lock whenever possible, e.g. to the motor contactor.

NOTE:

These procedures represent the minimum lock/tag out requirements during preventive

maintenance work and service work. Any additional safeguards needed to complete work safely

can be specified by facilities supervision, the safety officer, the safety committee and the health

department.

X Turn the operating lever (1) counterclockwise.

X Use the screwdriver to push the locking lug (2)

out of the operating lever (1).

X Secure the operating lever with a padlock (3).

Introduction

Safety Instructions for the Gantry Preparatory Work...

Retrofit Instructions CAN Node X Series SW70x

X Alternative: Attaching warning signs

If a machine can be locked, it must be. However, there are situations where energy isolating devices

cannot accommodate locks. In these cases, the energy isolating devices must be tagged to warn

employees that the machine is de-energized for servicing. The tag or label must be securely

fastened, it must be placed in a position visible to all and it may only be removed by the person who

attached it.

X Release of stored energy

Stored energy in the compressed air supply or electrical energy in electrolytic capacitors must be

released by appropriate means.

 After switching off the placement machine wait until the voltages and the compressed air have

discharged, to be able work without any risk.

X Testing the lock out.

Testing the lock out can be done simply by pressing the start button.

X The following steps must be taken to restore the machine to operation.

X Check the area. Authorized employees should remove all of their tools and reinstall all guards.

X Notify all affected employees.

X Before removing even one lock or tag, inform all workers in the area that the machine is going to be

restarted.

X Remove locks/tags

X Every authorized employee has to remove his own lock and shut it away.

X Turn the machine on. Authorized workers should observe the equipment in operation to insure

repairs were done correctly.

Testing

Service personnel may test the circuits by energizing the circuit for a short period of time without voiding

the lock out procedure provided. This may be done only when no other work is being performed by any

other person on the equipment being tested.

It is extremely important that all remote start switches be tagged with the "Do Not Operate" tag to prevent

inadvertent operation of the equipment during these periods.

Responsibilities

 It shall be the responsibility of the maintenance and service personnel to make sure this procedure

is adhered to.

 It shall be the responsibility of the maintenance and service personnel's immediate supervisor to

instruct his personnel on this procedure.

 It shall be the responsibility of the Safety Officer with assistance from the Safety Committee, Health

Service Department, and the various managers and vice-presidents to administer the Lock Out / Tag

Out Procedure.
