Installation

Final work Installing the Solenoid Valve for the Nozzle Station CAN Nodes

64 Retrofit Instructions CAN Node X Series SW70x

6.7 Final work

X Check whether you have removed all the tools and assemblies which are not needed for operating

the machine from the travel range of the placement heads.

X Switch the machine on.

X Move the component trolley into the machine.

X Download the embedded software.

X Perform a firmware download to the tape cutter control board.

Function check and troubleshooting

Check the functions by enabling the tape cutter components in the single functions and, if present, by

opening and closing the nozzle changer, checking the reject bin queries and by switching on the nozzle

station solenoid valve.

X Remove the component trolley.

X Switch off the machine.

X Fit the cover from the retrofitting kit onto the CAN nodes assembly.

X Shorten the cable ties if this has not already been done.

X Fit the box PC unit and the "power supply for the component trolley feed-in device FCU" back into

place in the machine backpack.

X Fit all covers.
