KD-2077-Rev03PD - 第21页
- - REF.NO N O TE PART NO D E S C R I P T I O N Qty 1 400-69517 CO VER SUB(ST)ASM 1 2 SL-306123 2 -TN SCREW (6) 3 400-69183 CO VER CUL (1) 4 SL-606129 2 -TN SCREW (3) 5 NM-6060001-SC NU T M6 (1) 6 400-43518 CO VER CUC …
- -
9. COVER COMPONENTS (3)
3
2
4
5
1 1
7
8
2
2
1 0
9
4
6
1 2
1 2
A
A
1 3
2 3
2 4
2 1
2 4
2 0
2 4
2 2
2 3
2 6
2 5
1 8
2 3
2 0
1 8
1 9
1 9
4 4
B
B
4 3
2
1
1 5
1 4
1 6
1 7
2 4
2 3
2 7
2 8
4 5
4 2
3 3
4 1
4 0
3 9
2 9
3 4
3 8
3 7
3 2
3 0
3 1
3 5
3 6
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-69517 COVER SUB(ST)ASM 1
2 SL-3061232-TN SCREW (6)
3 400-69183 COVER CUL (1)
4 SL-6061292-TN SCREW (3)
5 NM-6060001-SC NUT M6 (1)
6 400-43518 COVER CUC A (1)
7 400-69184 COVER SUL (1)
8 400-46569 COVER CUR (1)
9 400-69185 COVER SUR (1)
10 SL-6061292-TN SCREW (9)
11 SL-6061292-TN SCREW (4)
12 SL-6061292-TN SCREW (4)
13 SL-6061292-TN SCREW (9)
14 400-69186 COVER FU 1
15 SL-6041092-TN SCREW 4
16 SL-6061292-TN SCREW 2
17 SL-6061292-TN SCREW 2
18 400-43524 COVER HINGE GUIDE 2
19 E3065-729-000 SHAFT LABEL 2
20 SL-4041091-SC SCREW M4 L=10 4
21 400-43530 COVER HINGE L 1
22 400-43531 COVER HINGE R 1
23 400-43528 GUIDE PIN 4
24 NM-6060001-SC NUT M6 4
25 400-43529 PIPE HANDLE 1
26 SL-4041091-SC SCREW M4 L=10 4
27 400-33517 VISION MONITOR BRACKET ASM 1
28
400-99654
CRT BASE (1)
29 400-99656 CRT BR (1)
30 SL-6040892-TN BOLT (4)
31 400-99655 FREE STOP HINGE (1)
32 400-99657
CRT STOPPER
(1)
33 SL-6041092-TN SCREW (4)
3
4 SL-6040892-TN BOLT (2)
35 HX-0022100-0A
RUBBER BUSHING
(1)
36 EA-9500B01-00 CABLE BAND (1)
37 L127E-021-000 COVER CUSHION (1)
38 SL-6030602-TN SCREW M3X6 (1)
39 HX-0029400-00 FIXED BASE (1)
40 SM-4040601-SC SCREW M4X0.7 L=6 (1)
41 SL-6040892-TN BOLT (1)
42 401-02599 8.4 LCD MONITOR (CE) 1
43 400-43525 COVER SUPPORT L 1
44 400-43526 COVER SUPPORT R 1
45
SL-6040892-TN BOLT 4
- -
10.COVER COMPONENTS (4)
4
5
5
7
6
1 8
1 3
1 5
1 6
1 7
8
1 9
8
1 0
1 3
1 3
2 0
2 0
2 0
4
2 0
2 0
1 8
1 8
1 4
1 4
1 4
1 2
1
3
2
1 1
9
1 0
