- - 25.P WB CO N VE Y O R COM P ONEN T S (5) 5 2 0 1 9 1 1 2 0 1 1 2 1 2 1 2 5 2 3 2 4 1 5 5 1 5 1 7 2 1 2 5 2 3 4 8 2 7 9 7 2 6 2 6 1 0 1 9 1 2 1 0 1 7 8 1 3 2 4 1 4 1 3 1 4 1 2 6 2 0 1 9 2 1 2 5 2 3 2 4 2 6 1 7 2 8 1…
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-01060 RAIL PLATE RR ASM(L) 1
2 400-01062 SUPPORT PLATE RR ASM(L) (1)
3 400-01069 SUPPORT PLATE RR(L) (1)
4 SM-4040855-SC SCREW (3)
5 E2111-715-0A0 CONVEYOR PULLEY ASM. (3)
6 WP-0430800-SC WASHER M4 (3)
7 400-01061 RAIL PLATE RR(L) (1)
8 400-00828 CONVEYOR RAIL (1)
9 SL-6031492-TN SCREW (4)
10 SL-6041092-TN SCREW (2)
11 SB-8160001-00 BEARING (2)
12 SM-4040855-SC SCREW (2)
13 SM-4042501-SC SCREW M4X0.7 L=25 (1)
14 WP-0430801-SC WASHER 4.3X9X0.8 (1)
15 WS-0410002-KN SPRING WASHER (1)
16 NM-6040001-SC NUT M4 (1)
17 E2089-721-0A0 CONVEYOR PULLEY B ASM. (4)
18 E2055-721-000 PULLEY SPACER (4)
19 SM-4042501-SC SCREW M4X0.7 L=25 (4)
20 WP-0430801-SC WASHER 4.3X9X0.8 (4)
21 WS-0410002-KN SPRING WASHER (4)
22 NM-6040001-SC NUT M4 (4)
23 SM-6041002-TN BOLT (8)
24 400-00839 DRIVE PULLEY R ASM (2)
25 400-00840 DRIVE PULLEY R (1)
26 E2160-721-000 PULLEY FLANGE (1)
27 SL-6030892-TN SCREW (3)
28 SL-6030892-TN SCREW (6)
29 E2111-715-0A0 CONVEYOR PULLEY ASM. (3)
30 WP-0430800-SC WASHER M4 (3)
31 E3931-750-000 PULLEY WASHER (4)
32 E2160-721-000 PULLEY FLANGE (2)
33 SL-6042092-TN SCREW M4 L=20 (4)
34 E4074-725-000 SUPPORT PLATE C(E) (1)
35 400-01066 RAIL STAND RR(L) 1
36 400-01002 GUIDE SHAFT ASM(L) 4
37 E2209-725-000 GUIDE SHAFT (4)
38 WP-0501046-SC WASHER 5 X 14 X 1 (8)
39 SL-6051292-TN BOLT (4)
40 SL-6052042-TN SCREW (4)
41 SL-6052092-TN SCREW 2
42 SL-6052092-TN SCREW 2
43 400-01065 RAIL STAND RL(L) 1
- -
25.PWB CONVEYOR COMPONENTS (5)
5
2 0
1 9
1 1
2 0
1 1
2 1
2 1
2 5
2 3
2 4
1 5
5
1 5
1 7
2 1
2 5
2 3
4 8
2 7
9
7
2 6
2 6
1 0
1 9
1 2
1 0
1 7
8
1 3
2 4
1 4
1 3
1 4
1 2
6
2 0
1 9
2 1
2 5
2 3
2 4
2 6
1 7
2 8
1 8
2 9
3 2
3 6
3 7
3 3
4 1
4 3
3 9
4 0
3
2
3 0
3 0
4 7
2 1
2 9
1 8
2 8
2 1
2 9
1 8
2 8
8
9
7
6
3 4
3 5
3 8
4 2
2
3
4
2 2
2 2
2 2
1 6
3 1
4 4
5 1
4 5 4 6
5 1
4 9
5 0
5 0
1
4 9
4 9
4 9
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-00860 PWB GUIDE ASM 1
2 400-00861 PWB GUIDE U (8)
3 SL-6031092-TN SCREW (16)
4 400-01003 SCREW SHAFT ASM(L) 1
5 SL-6041692-TN SCREW (8)
6 SB-1080002-00 SIDE BEARING (4)
7 WP-0320500-SF WASHER 3.2X7X0.5 (8)
8 WP-0330516-SC WASHER 3.3X8X0.5 (4)
9 SM-6030602-TN HEX SCREW M3 X 6 (4)
10 E2141-721-000 STOPPER COLLAR (2)
11 SM-8040402-TP SCREW M4X0.7 L=4 (4)
12 E2156-721-000 PULLEY A (2)
13 SM-8040602-TP SCREW M4X0.7 L=6 (4)
14 E2146-721-000 TIMING BELT (1)
15 400-15578 SCREW SHAFT(L) (2)
16 400-54803 DRIVE SHAFT ASM L(6) 1
17 E2152-721-000 DRIVE SHAFT C (3)
18 SM-6030602-TN HEX SCREW M3 X 6 (6)
19 E2141-721-000 STOPPER COLLAR (3)
20 SM-8040402-TP SCREW M4X0.7 L=4 (6)
21 SB-1080002-00 SIDE BEARING (6)
22 400-00849 DRIVE PULLEY F ASM 1
23 400-00850 DRIVE PULLEY F (3)
24 SM-8040602-TP SCREW M4X0.7 L=6 (6)
25 400-00851 MOTOR_PULLEY_B (3)
26 SL-6031642-TN SCREW (9)
27 400-01005 DRIVE BELT C(L) (1)
28 WP-0320500-SF WASHER 3.2X7X0.5 (12)
29 WP-0330516-SC WASHER 3.3X8X0.5 (6)
30 400-46033 DRIVE BELT S(6) (2)
31 400-00853 PIN ADJUST UNIT 1
32 400-00854 ADJUST HAND WHEEL ASM. (1)
33 E2018-715-000 PULLEY SLEEVE (1)
34 SM-6052002-TN BOLT (1)
35 SM-6041002-TN BOLT (1)
36 400-00855 ADJUST HAND WHEEL (1)
37 400-00856 ADJUST HAND WHEEL COLLAR (1)
38 400-00859 STOPER COLLAR (1)
39 400-00977 STOPER SPRING (1)
40 RE-0320000-K0 E-RING 3.2 (1)
41 400-00857 ADJUST STOPER BRAKET (1)
42 SL-6041292-TN SCREW (2)
43 400-00858 ADJUST STOPER (1)
44 400-01068 CONVEYOR BELT ASM(L) 1
45 SL-4031091-SC SCREW M3 X 10 (8)
46 SL-6031092-TN SCREW (16)
47 400-00863 CONVEYOR BELT S (4)
48 400-01070 CONVEYOR BELT C(L) (2)
49 E2046-725-000 PWB INNER (12)
50 400-21327 SHORT PLATE 4
51 400-33349 SHORT PLATE B 4
