4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH) 4.1 No.2 placing head (L-side)(QPH) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 76 H5152H 1 BOLT, ADJUSTING ﾎﾞﾙﾄ ｾﾘ BSF6X16 77 S3090A 1 SW, PROXI…

100%1 / 299
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 APPH8014 1 JOINT, ROTARY ｼﾞｮｲﾝﾄ ﾛｰﾀﾘ
4 QPA1001 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ
7 PPH0180 1 DOG ﾄﾞｯｸﾞ
8 PPH0190 2 DOG ﾄﾞｯｸﾞ
15 PPH0300 1 SHAFT, PULLEY ｼｬﾌﾄ ﾌﾟｰﾘ
20 PPH0450 1 BKT BKT
21 PPH0460 1 PLATE ﾌﾟﾚｰﾄ
22 PPH0500 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
29 QPH1340 1 RETAINER 押え
32 PPH0950 1 PULLEY ﾌﾟｰﾘ
34 PPH0992 1 BKT, TERMINAL BKT ﾀｰﾐﾅﾙ
37 PPH1020 1 HOLDER, SENSOR ﾎﾙﾀﾞ ｾﾝｻ
38 PPH1040 1 SPACER ｽﾍﾟｰｻ
39 PPH1050 2 BUSHING ﾌﾞｯｼｭ
40 PPH1062 1 BKT BKT
42 PPH1170 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
43 PPH3011 1 ADAPTER ｱﾀﾞﾌﾟﾀ
44 PPH3021 1 HOUSING ﾊｳｼﾞﾝｸﾞ
45 PPH3060 1 SPRING ｽﾌﾟﾘﾝｸﾞ
46 PPH3070 1 BUSHING ﾌﾞｯｼｭ
47 PPH3080 1 COLLAR ｶﾗｰ
48 PPH3150 1 JOINT ｼﾞｮｲﾝﾄ
51 PPH3200 2 COLLAR ｶﾗｰ
52 PPH3210 1 DOG ﾄﾞｯｸﾞ
53 PPH3230 1 BKT, SENSOR BKT ｾﾝｻ
54 PPZ0330 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL
56 QPH0121 1 STOPPER ｽﾄｯﾊﾟ
57 QPH1360 1 COVER ｶﾊﾞｰ
58 QPH0202 1 STOPPER ｽﾄｯﾊﾟ
59 QPH0223 1 DOG ﾄﾞｯｸﾞ
63 QPH0311 2 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
66 QPH1323 1 BODY 本体
68 PPH3220 1 BKT, SENSOR BKT ｾﾝｻ
69 PPH0490 1 BKT BKT
70 PPH0150 1 BKT BKT
73 H4485T 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 212P2M6-530
75 S2146A 1 JOINT ｼﾞｮｲﾝﾄ BF4BU-M3
IP-Ⅲ PARTS LIST ver17
4 - 2
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
76 H5152H 1 BOLT, ADJUSTING ﾎﾞﾙﾄ ｾﾘ BSF6X16
77 S3090A 1 SW, PROXIMITY SW 近接 E2E-CR8C1
78 S3090H 2 SW, PROXIMITY SW 近接 E2EC-CR8D1
79 S4042A 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A
80 S4044A 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX405-W2A
82 N2034A 1 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ GP-AM-6(P=1.0)
86 Y3061E 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5(ｼﾛ)
88 H3145H 1 PLUG ﾌﾟﾗｸﾞ M-3P
89 K5322Z 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ MB4R-M3-O
90 H4144H 2 BEARING ﾍﾞｱﾘﾝｸﾞ MR137ZZS
91 NPA0190 2 COLLAR ｶﾗｰ
92 S2157T 1 JOINT ｼﾞｮｲﾝﾄ PAU4
94 N2037A 1 NIPPLE, GREASE ﾆｯﾌﾟﾙ ｸﾞﾘｽ PF1/8X45゜B Type
97 . 2 O RING O ﾘﾝｸﾞ S-3
98 A5161T 1 O RING O ﾘﾝｸﾞ S15
99 A5129A 1 O RING O ﾘﾝｸﾞ S4
102 T2060A 1 TUBE ﾁｭｰﾌﾞ SP-4-LBX100M
103 R2037A 2 RING, INSERT ﾘﾝｸﾞ ｲﾝｻｰﾄ WRO425
109 PPH3040 1 NUT ﾅｯﾄ
110 N4016A 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M2X2L
111 N4018A 7 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X3L
112 N4027A 4 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L
113 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
114 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
115 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
116 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
117 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
118 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
119 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
122 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
123 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
125 K5173A 4 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X10L
128 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X6L
129 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
130 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
131 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
132 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
IP-Ⅲ PARTS LIST ver17
4 - 3
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
134 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
135 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
136 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
137 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
140 H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X15L
141 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
143 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
144 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
145 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L
148 QPH1311 1 BLOCK ﾌﾞﾛｯｸ
149 QPA1030 1 RETAINER, WIRING 押さえ 配線
150 QPH1391 1 DOG ﾄﾞｯｸﾞ
151 QPH1421 1 DOG ﾄﾞｯｸﾞ
152 QPH1431 1 COVER ｶﾊﾞｰ
153 QPH1440 1 TUBE ﾁｭｰﾌﾞ
154 QPH1450 1 PLATE ﾌﾟﾚｰﾄ
155 QPH1471 1 BKT, SW BKT SW
156 QPH1490 1 BKT BKT
157 QPH1510 1 BKT BKT
159 A1022S 1 ADAPTER ｱﾀﾞﾌﾟﾀ KQ2N06-01S
160 A1022N 1 ADAPTER ｱﾀﾞﾌﾟﾀ KQ2N04-M5
161 Y30827 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2H06-M5
162 H1006M 1 GENERATOR, VACUUM 発生器 真空 VBH12-66P
163 H1121Y 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL SY5120-5MZ-01-F2-X19
164 H3018X 1 FILTER ﾌｨﾙﾀ LF-M5A-Z
165 Y3075A 1 CONNECTOR ｺﾈｸﾀ KQ2U06-00
167 Y3078A 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-01S
168 W1004G 1 WASHER, FLAT ﾜｯｼｬ 平 LR6-0.5
169 H5281A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X25L
170 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
･
IP-Ⅲ PARTS LIST ver17
4 - 4
4.1 No.2ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(L側)(QPH)
4.1 No.2 placing head (L-side)(QPH)
