69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT) 69.MTU-4L Tray unit(QUT) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg.No. & Code No. QTY Description Rating Remarks 39 QMT1640 1 PLATE ﾌﾟﾚｰﾄ 40 QMT1670 10 PLATE ﾌﾟﾚｰﾄ 41 QMT1681 10 GUIDE ｶﾞｲﾄﾞ 42 QMT…
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 IPT0160 1 BOLT ﾎﾞﾙﾄ
2 IPT0211 1 CASE, BEARING ｹｰｽ ﾍﾞｱﾘﾝｸﾞ
3 IPT0220 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
4 IPT0340 1 ABSORBER ｱﾌﾞｿｰﾊﾞ
5 IPT0370 20 RETAINER 押え
6 IPT0510 1 COVER ｶﾊﾞｰ
7 IPT0670 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ
8 IPT0730 1 COLLAR ｶﾗｰ
9 KPT1070 1 PLATE ﾌﾟﾚｰﾄ
10 KPT1171 1 BLOCK ﾌﾞﾛｯｸ
11 KPT1210 1 COLLAR ｶﾗｰ
12 KPT1220 1 RETAINER 押え
13 KPT1240 1 PULLEY ﾌﾟｰﾘ
14 QMT1690 10 STOPPER ｽﾄｯﾊﾟ
15 QMT1820 1 FRAME ﾌﾚｰﾑ
16 QMT1131 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
17 QMT1140 1 COVER ｶﾊﾞｰ
18 QMT1150 1 COVER ｶﾊﾞｰ
19 QMT1161 2 GUIDE ｶﾞｲﾄﾞ
20 QMT1170 8 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
22 QMT1211 25 GUIDE ｶﾞｲﾄﾞ
23 QMT1220 1 ABSORBER ｱﾌﾞｿｰﾊﾞ
24 QMT1300 10 PLATE ﾌﾟﾚｰﾄ
25 QMT1310 20 PLATE ﾌﾟﾚｰﾄ
26 QMT1341 10 DOOR 扉
27 QMT1350 10 HOLDER 受け
28 QMT1390 10 DOG ﾄﾞｯｸﾞ
29 QMT1410 10 PLATE ﾌﾟﾚｰﾄ
30 QMT1500 10 PIN ﾋﾟﾝ
31 QMT1510 1 PLATE ﾌﾟﾚｰﾄ
32 QMT1520 2 COLLAR ｶﾗｰ
33 QMT1552 1 RETAINER 押え
34 QMT1560 1 NUT ﾅｯﾄ
35 QMT1571 10 RETAINER 押え
36 QMT1600 10 ARM ｱｰﾑ
37 QMT1611 10 COLLAR ｶﾗｰ
38 QMT1631 10 STOPPER ｽﾄｯﾊﾟ
IP-Ⅲ PARTS LIST ver17
69 - 2
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
39 QMT1640 1 PLATE ﾌﾟﾚｰﾄ
40 QMT1670 10 PLATE ﾌﾟﾚｰﾄ
41 QMT1681 10 GUIDE ｶﾞｲﾄﾞ
42 QMT1703 10 TRAY ﾄﾚｲ
43 QMT1713 10 TRAY ﾄﾚｲ
44 QMT1720 1 BKT, SENSOR BKT ｾﾝｻ
45 QMT1730 2 BKT, SENSOR BKT ｾﾝｻ
46 QMT1740 2 BKT, SENSOR BKT ｾﾝｻ
47 QMT1750 1 BKT, SENSOR BKT ｾﾝｻ
51 QMT1180 2 BKT, SW BKT SW
52 QMT1191 1 BKT, SW BKT SW
53 QMT1811 10 STOPPER ｽﾄｯﾊﾟ
55 SAM1210 1 MOTOR ﾓｰﾀ
56 AIPT5030 40 GUIDE ｶﾞｲﾄﾞ
57 H3216A 1 PULLEY ﾌﾟｰﾘ 24PB8M25AF-S424
58 H4500A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 584P8M25
59 H4190A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 6206ZZ
60 K4181A 1 REDUCTION GEAR 減速機 BM4-15B-02NDZAK6
61 H3170T 10 PLUNGER, BALL ﾌﾟﾗﾝｼﾞｬ ﾎﾞｰﾙ BSJ-8
62 S4042A 4 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX670A
64 H4094T 20 BEARING ﾍﾞｱﾘﾝｸﾞ F608ZZ
65 H4137A 2 BEARING ﾍﾞｱﾘﾝｸﾞ HR30206J
66 S3138A 2 SW, PHOTOELECTRIC SW 光電 PZ-51L
67 R2041A 3 RING, LOCKING ﾘﾝｸﾞ 締結 RFN8006 No.22
68 S2036T 30 SEAL ｼｰﾙ S5012
69 S2036Y 20 SEAL ｼｰﾙ S5047
70 S20361 10 SEAL ｼｰﾙ S5009
71 S1024A 30 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-6
72 T4044T TAPE ﾃｰﾌﾟ #130(AS)20mm
73 N1089A NUT, HEX ﾅｯﾄ 六角 M8 P=1.25
74 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5
75 K5178Z SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X16L
76 K5233A SCREW, ROUND 小ﾈｼﾞ 丸 M4X6L
77 K5225A SCREW, ROUND 小ﾈｼﾞ 丸 M3X8L
78 K5230A SCREW, ROUND 小ﾈｼﾞ 丸 M3X25L
79 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X6L
80 W1027A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M
IP-Ⅲ PARTS LIST ver17
69 - 3
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
81 W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M
82 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
83 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
84 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
85 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
86 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/MX1.6X17
87 W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10
88 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
89 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
90 W1015A WASHER, CONICAL ﾜｯｼｬ 皿 M-10-H
91 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
92 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
93 W1004H 10 WASHER ﾜｯｼｬ LR8-1
94 H5392A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X45L
95 H5362A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X35L
96 H5361A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X30L
97 H5360A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X25L
98 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
99 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
100 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
101 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
103 H5291A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18L
104 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
105 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
106 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
108 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
109 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L
110 QMT1621 10 PIN ﾋﾟﾝ
111 IPT0360 4 COLLAR ｶﾗｰ
112 IPT0441 40 GUIDE ｶﾞｲﾄﾞ
113 QWB0020 1 SEAL, BAR CODE ｼｰﾙ ﾊﾞｰｺｰﾄﾞ Option
IP-Ⅲ PARTS LIST ver17
69 - 4
69.MTU-4L ﾄﾚｲﾕﾆｯﾄ(QUT)
69.MTU-4L Tray unit(QUT)
