24.ｲﾝｺﾝﾍﾞｱ(QQC)
24.In conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 IQC5413 2 HOUSING ﾊｳｼﾞﾝｸﾞ
2 IQC5470 2 COLLAR ｶﾗｰ
3 IQC5791 2 PLATE ﾌﾟﾚｰﾄ
4 IQC5920 2 COLLAR ｶﾗｰ
5 IQC5931 3 COLLAR ｶﾗｰ
6 IQC6041 4 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
7 IQC6062 11 NUT ﾅｯﾄ
8 IQC6072 54 NUT ﾅｯﾄ
10 IQC6301 8 NUT, SQUARE ﾅｯﾄ 四角
11 MQC1061 4 PULLEY ﾌﾟｰﾘ
12 MQC1290 4 PULLEY ﾌﾟｰﾘ
13 MQC3293 2 COVER ｶﾊﾞｰ
14 MQC3313 2 GUIDE ｶﾞｲﾄﾞ
15 MQC3323 2 GUIDE ｶﾞｲﾄﾞ
16 MQC3440 8 WASHER ﾜｯｼｬ
17 MQC3501 2 PULLEY ﾌﾟｰﾘ
18 MQC3901 8 SPACER ｽﾍﾟｰｻ
19 NQC0320 1 KNUCKLE ﾅｯｸﾙ
20 NQC0431 4 NUT ﾅｯﾄ
21 NQC0490 2 PLATE ﾌﾟﾚｰﾄ
22 NQC0591 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
23 NQC0610 2 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ
24 NQC0630 3 COLLAR ｶﾗｰ
25 PQC0100 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
26 PQC0110 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
27 PQC0181 4 PLATE ﾌﾟﾚｰﾄ
28 PQC0200 2 PLATE ﾌﾟﾚｰﾄ
29 PQC0220 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
30 PQC0230 1 BKT BKT
31 PQC0240 1 BKT BKT
32 PQC0251 1 BKT BKT
33 PQC0304 2 CONVEYOR, BELT ｺﾝﾍﾞｱ ﾍﾞﾙﾄ
34 PQC0330 1 BKT BKT
35 PQC0340 4 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
36 PQC0350 1 PIN ﾋﾟﾝ
37 PQC0390 2 SHAFT ｼｬﾌﾄ
38 PQC0472 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
IP-Ⅲ PARTS LIST ver17
24 - 2
24.ｲﾝｺﾝﾍﾞｱ(QQC)
24.In conveyor(QQC)
24.ｲﾝｺﾝﾍﾞｱ(QQC)
24.In conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
39 PQC0510 2 BKT BKT
40 PQC0520 1 SHAFT ｼｬﾌﾄ
41 PQC0530 1 HOUSING ﾊｳｼﾞﾝｸﾞ
42 PQC0540 1 COVER, CHAIN ｶﾊﾞｰ ﾁｪｰﾝ
43 PQC0550 1 COLLAR, INNER ｶﾗｰ ｲﾝﾅ
44 PQC0590 1 BKT BKT
45 PQC0610 1 BKT BKT
46 PQC0620 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
47 PQC0630 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
48 PQC0710 1 HOLDER ﾎﾙﾀﾞ
49 PQC0720 1 BLOCK ﾌﾞﾛｯｸ
50 PQC0730 1 PIN ﾋﾟﾝ
51 PQC0741 1 BKT BKT
59 CLC3430 5 SPROCKET ｽﾌﾟﾛｹｯﾄ
60 CLC9191 4 NUT ﾅｯﾄ
61 H4006A 2 HEAD GEAR ﾍｯﾄﾞ ｷﾞﾔ 2GN7.5K
62 H4175A 2 BEARING ﾍﾞｱﾘﾝｸﾞ 6000ZZ
63 . 1 PIN, NEEDLE ﾋﾟﾝ ﾆｰﾄﾞﾙ 5゜X27.3L
64 AJQC3940 1 HANDLE ﾊﾝﾄﾞﾙ
65 S2095H 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDJ2B10-35-C73L
66 S2105T 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2B20-15D-A73
67 S3122A 2 SW, PHOTOELECTRIC SW 光電 E3S-LS3CID
68 S3123Z 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3RC4-1
69 GVC0350 2 COLLAR ｶﾗｰ
70 K1049A 1 FIXTURE 金具 HPU2-FA0
71 K1052A 1 FIXTURE 金具 HPU2-MA0
72 K4164T 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ HPU206-R38.13 Link
73 H4440A 4 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ
74 H4445A 4 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ
75 H4429H 2 BEARING, BALL ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16UU
76 A4067T 2 ELBOW ｴﾙﾎﾞ M-5ALHU-4
77 K5325A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ M4R-M5-0
78 M5017H 2 MOTOR, INDUCTION ﾓｰﾀ ｲﾝﾀﾞｸｼｮﾝ 21K6RGN-A-K1
79 S3034A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T2 Type
80 T2011A 1 CHAIN ﾁｴｰﾝ RS25NP 50 Link
81 T2030T 1 CHAIN ﾁｪｰﾝ RS25NP 266 Link
82 S1022A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4
IP-Ⅲ PARTS LIST ver17
24 - 3
24.ｲﾝｺﾝﾍﾞｱ(QQC)
24.In conveyor(QQC)
24.ｲﾝｺﾝﾍﾞｱ(QQC)
24.In conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
83 H4123A 2 BEARING ﾍﾞｱﾘﾝｸﾞ UFL000
84 N4027A 8 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L
85 N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0
86 N1091T 8 NUT, HEX ﾅｯﾄ 六角 M10 P=1.5
87 N1014A 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU AN00
88 K5261H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X12L
89 K5359A
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X6L
90 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
91 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
92 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
93 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
94 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
95 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
96 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
97 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
98 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
99 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
101 H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L
102 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
103 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
104 H5309A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X50L
105 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
106 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
107 H5296X BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X90L
108 H5291A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18L
109 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
110 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
111 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
112 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
113 Y30742 1 CONNECTOR ﾕﾆｵﾝ KQ2U04-00
･
IP-Ⅲ PARTS LIST ver17
24 - 4
