25.ｱｳﾄｺﾝﾍﾞｱ(QQC)
25.Out conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 IQC5413 2 HOUSING ﾊｳｼﾞﾝｸﾞ
2 IQC5470 2 COLLAR ｶﾗｰ
3 IQC5791 2 PLATE ﾌﾟﾚｰﾄ
4 IQC5920 2 COLLAR ｶﾗｰ
5 IQC5931 2 COLLAR ｶﾗｰ
6 IQC6041 4 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ
7 IQC6062 15 NUT ﾅｯﾄ
8 IQC6072 52 NUT ﾅｯﾄ
10 IQC6301 8 NUT, SQUARE ﾅｯﾄ 四角
11 MQC0320 1 KNUCKLE ﾅｯｸﾙ
12 MQC1061 4 PULLEY ﾌﾟｰﾘ
13 MQC1290 4 PULLEY ﾌﾟｰﾘ
14 MQC3293 2 COVER ｶﾊﾞｰ
15 MQC3313 2 GUIDE ｶﾞｲﾄﾞ
16 MQC3323 2 GUIDE ｶﾞｲﾄﾞ
17 MQC3440 8 WASHER ﾜｯｼｬ
18 MQC3501 2 PULLEY ﾌﾟｰﾘ
19 MQC3901 8 SPACER ｽﾍﾟｰｻ
20 MQC3941 1 STOPPER ｽﾄｯﾊﾟ
21 NQC0111 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
22 NQC0431 4 NUT ﾅｯﾄ
23 NQC0441 1 PIN ﾋﾟﾝ
24 NQC0490 2 PLATE ﾌﾟﾚｰﾄ
25 NQC0610 2 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ
26 NQC0630 2 COLLAR ｶﾗｰ
27 PQC0120 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
28 PQC0130 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
29 PQC0152 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
30 PQC0181 2 PLATE ﾌﾟﾚｰﾄ
31 PQC0191 2 PLATE ﾌﾟﾚｰﾄ
32 PQC0210 1 PLATE ﾌﾟﾚｰﾄ
33 PQC0220 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
34 PQC0230 1 BKT BKT
35 PQC0240 1 BKT BKT
36 PQC0314 2 CONVEYOR, BELT ｺﾝﾍﾞｱ ﾍﾞﾙﾄ
37 PQC0321 1 BKT BKT
38 PQC0330 1 BKT BKT
IP-Ⅲ PARTS LIST ver17
25 - 2
25.ｱｳﾄｺﾝﾍﾞｱ(QQC)
25.Out conveyor(QQC)
25.ｱｳﾄｺﾝﾍﾞｱ(QQC)
25.Out conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
39 PQC0340 4 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ
40 PQC0390 2 SHAFT ｼｬﾌﾄ
41 PQC0400 1 STOPPER ｽﾄｯﾊﾟ
42 PQC0510 2 BKT BKT
43 PQC0640 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
44 PQC0650 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
45 PQC0660 1 HOLDER ﾎﾙﾀﾞ
46 PQC0670 1 BKT BKT
47 PQC0750 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
52 PQC0200 1 PLATE ﾌﾟﾚｰﾄ
54 CLC3430 3 SPROCKET ｽﾌﾟﾛｹｯﾄ
55 CLC9191 4 NUT ﾅｯﾄ
56 GVC0350 2 COLLAR ｶﾗｰ
57 H4013A 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6RH-DZ7.5R039
58 . 1 PIN, NEEDLE ﾋﾟﾝ ﾆｰﾄﾞﾙ 5゜X27.3L
59 S3122A 2 SW, PHOTOELECTRIC SW 光電 E3S-LS3C1D
60 K1049A 1 FIXTURE 金具 HPU2-FAO
61 K4164T 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ HPU206-R3813 Link
62 K1052A 1 FIXTURE 金具 HRU2-MAO
63 H4440A 4 BEARING ﾍﾞｱﾘﾝｸﾞ L-1910ZZ
64 H4445A 4 BEARING ﾍﾞｱﾘﾝｸﾞ LF-1050ZZ
65 H4429H 2 BEARING, BALL ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16UU
66 A4067T 2 ELBOW ｴﾙﾎﾞ M-5ALHU-4
67 M5063A 2 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6A6ZMR039
68 S3034A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2-Type
69 T2034H 1 CHAIN ﾁｪｰﾝ RS25NP 282-Link
70 S1022A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4
71 H4123A 2 BEARING ﾍﾞｱﾘﾝｸﾞ UFL000
72 K5359A
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X6L
73 K5261H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X12L
74 N1014A 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU AN00
75 N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5
76 N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0
77 N4027A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L
78 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
79 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
80 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
IP-Ⅲ PARTS LIST ver17
25 - 3
25.ｱｳﾄｺﾝﾍﾞｱ(QQC)
25.Out conveyor(QQC)
25.ｱｳﾄｺﾝﾍﾞｱ(QQC)
25.Out conveyor(QQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
81 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
82 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
83 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
84 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
85 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
86 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
87 N4052T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L P1.0
88 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
89 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
90 H5309A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X50L
91 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
92 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
93 H5296Z 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X100L
94 H5291A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18L
96 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
97 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
98 H5277A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X12L
99 Y30742 1 CONNECTOR ﾕﾆｵﾝ KQ2U04-00
･
IP-Ⅲ PARTS LIST ver17
25 - 4
