Advanced Software M elter Configuration 7 -28 Part 1121836_03 E 1 1/2014 Nordson Corporation Table 7-4 Security level details Security Level Functions Enabled High Medium Low 3 Application names (temp erature channels an…

100%1 / 230
Advanced Software Melter Configuration
7-27
Part 1121836_03
E 11/2014 Nordson Corporation
Configuring Password Protection
By default, password protection is disabled.
NOTE: Refer to Table 7-4 for an explanation of each security level.
The following are default password level numeric codes:
Level # Default Code Notes
1 1000
S
Cannot start with the number 0 (zero).
S
Can be one up to five numbers long.
S
The largest 5 digit number is 65535.
S
Each
level
must
have
a
unique
numeric
code.
2 2000
3 3000
System
Done
Home
Formats/Units
Date/Time
Password
Display
Service Interval Administration
Scheduler Language
03/20/2014 4:40PM
500 Hours
Password
Done
Home
Create/Modify
Timeout
Set Security Level
5 min.
1. From the Home Display touch
Master
Controls
2. Touch System, then Password.
3. Do the following to continue. When finished, touch Done.
Touch Description
Create/Modify Modify the default numeric password code for each
level.
Timeout Enter the amount of time (the default is 10 minutes)
the selected password protection becomes active
after no user interaction with the touchscreen.
Set Security Level Refer to Table 7-4 for an explanation of each
security level.
Advanced Software Melter Configuration
7-28
Part 1121836_03
E 11/2014 Nordson Corporation
Table 7-4
Security level details
Security
Level
Functions Enabled High Medium Low
3 Application names (temperature channels and pumps
Controlled system heating rate temperature
Switch between °C, °F
Switch between bar, psi, kPa
Temperature channel settings (PID control mode)
Maximum temperature set point
Assign standard I/O inputs for application groups
Seven-day clock settings: (delete/edit schedule, copy schedule)
Motor enables from control panel / control panel AND standard I/O
Gear-to-line signal: Analog/frequency, voltage/current
Speed control / Line speed for min./max. pump speed/pressure
Threshold switch
Restore default settings
Melter configuration
Configuration code input (Local mode / field bus mode)
Customer setup (recipes / application names)
Service interval
System ready-delay setup
Password setup
2 Under-temperature/over-temperature warnings/faults
Standby values (setback delta and duration)
Automatic enter standby
Temperature channel enabled/disabled
Changing pump modes (manual and gear-to-line)
1 Temperature set point
Individual motor enable
Speed set point
Min. and max. pump speed/pressure (in gear-to-line mode)
NOTE: The table indicates the following:
S
High Security includes levels 1, 2 and 3
S
Medium Security includes levels 2 and 3
S
Low Security includes only level 3
Advanced Software Melter Configuration
7-29
Part 1121836_03
E 11/2014 Nordson Corporation
Configuring Scheduled Events
Use the scheduler to time daily heater and standby events. The following
figure illustrates a typical daily schedule.
Heaters On
Enter Standby - break
Heaters Off
Exit Standby
Enter Standby - shift change
Exit Standby
NOTE: About scheduling events:
S
Define up to 12 events per day.
S
Each day can have its own unique schedule.
S
Copy and paste schedules to other days of the week.
S
Scheduled events cannot cross over to the next day.
Creating a Schedule of events is a 3-step process
Step 1: Access the Scheduler and verify that the system date, time and day
of week are correct.
Step 2: Define the first work day of the week that you want to start
scheduling events.
Step 3: Switch On the Scheduler control.
