Introduction
2-3
Part 1121836_03
E 11/2014 Nordson Corporation
Description of the Bulk Melter
AltaPail bulk melters are designed to accommodate 20 liter containers.
3 4 5 6 87
1 2
Figure 2-1
1 Electrical cabinet
2 Platen
3 Pump
4 Sealing ring
5 Melting plate
6 Aeration and air relief valve
7 Pressure control valve Material
pressure
8 Hose fitting
Introduction
2-4
Part 1121836_03
E 11/2014 Nordson Corporation
Electrical Cabinet
Back view of melter
Front/side
view of melter
Figure 2-2
1 Display Platen pressure
2 Pressure control valve Platen
pressure
3 Touch Screen Display
4 Door lock
5 Air filter / fan with filter
6 Button Two-hand control
7 Selector Raise/lower platen
8 Main switch
9 I/O Connector
10 Cable gland Inputs/outputs
11 Air Filter
Introduction
2-5
Part 1121836_03
E 11/2014 Nordson Corporation
Button Two-hand Control and Selector Raise/Lower
Platen
Used to raise and lower the platen.
WARNING! The two-hand control may only be operated by one person using
both hands!
Main Switch
The main switch is used to switch the bulk melter on and off.
Position
0
/OFF = Bulk melter is switched off.
Position
I
/ON = Bulk melter is switched on.
Padlocks can be used to protect the main switch from being turned on by
unauthorized personnel.
Fan with Filter
The fan reduces the temperature inside of the electrical cabinet. The filter
must be serviced regularly. Refer to page 8-7, Fan and Air Filter.
Door Lock
The electrical cabinet can be opened for installation, maintenance and repair.
Store the included key such that it is accessible only to qualified and
authorized personnel. The bulk melter may not be operated when the
electrical cabinet is open.
WARNING! Risk of electrical shock. Failure to observe may result in
personal injury, death, or equipment damage.
WARNING: Disconnect the bulk melter from the line voltage.
