Advanced Software Melter Configuration
7-11
Part 1121836_03
E 11/2014 Nordson Corporation
Advanced Pump Settings
Touch the Advanced button to do the following:
S
Switch the Auto Pump option On/Off
S
Calibrate the pump
S
Define container to low timer settings
S
When using hand applicators, define pump off delay timing
The following sections detail each procedure in greater detail.
Accessing the Advanced Pump Screen
You can access the Advanced Pump screen by:
S
Touching
Pump
GTL
45 RPM
from the Home screen then the Advanced
button.
S
Touching the touch
Master
Controls
from the Home screen, then Settings |
Pump | Advanced
NOTE: Refer to Basic Pump Configuration in the previous chapter for more
information.
Pump - Advanced
Done
Pump Off Delay Infinite
Off
Pump Off Delay Time
0 Sec.
Pump Calibration
On
Container Low to Empty
Timer
0 Sec.
Auto Pump
Off
Remote Control
Advanced Software Melter Configuration
7-12
Part 1121836_03
E 11/2014 Nordson Corporation
Modifying the Pump and Hand Applicator Usage
By default, when a handgun is connected to an external zone, the pump will
only run when the hand applicator trigger is engaged, and when released, the
pump will stop running. However, you can configure the pump to continue to
run for a predefined amount of time, after the trigger is released or keep the
pump running, regardless if the hand applicator trigger is engaged or not.
NOTE: The Pump Off Delay Infinite and the Pump Off Delay Time
buttons are available only when a hand applicator is connected and enabled.
Setting Default Options
Pump Off Delay Infinite Off
S
On
S
Off
Pump Off Delay Time 0 Seconds
S
Minimum: 0 Seconds
S
Maximum: 360 Seconds
Pump - Advanced
Done
Pump Off Delay Infinite
Off
Pump Off Delay Time
0 Sec.
Pump Calibration
On
Container Low to Empty
Timer
0 Sec.
Auto Pump
Off
Remote Control
Done
Cancel
7 8 9
4 5 6
1 2 3
0
Pump Off Delay Time Settings
0
Home
min
1. Access the Home screen, touch
Pump
GTL
45 RPM
then the Advanced button
2. Touch Pump Off Delay Time and enter how long you want the pump to
continue running after the trigger is released.
3. Touch Done.
NOTE: Touch the Pump Off Delay Infinite button located on the Pump
Advanced screen to prevent the pump from switching Off when you release
the trigger.
Advanced Software Melter Configuration
7-13
Part 1121836_03
E 11/2014 Nordson Corporation
Using the Auto Pump Option
The Auto Pump option allows you to touch the Pump button at any time while
the melter is heating up to normal operation temperature, thereby allowing
the Pump to automatically start when the melter status indicates Ready/OK.
Setting Default Options
Auto Pump Off
S
On
S
Off
Pump - Advanced
Done
Pump Off Delay Infinite
Off
Pump Off Delay Time
0 Sec.
Pump Calibration
On
Container Low to Empty
Timer
0 Sec.
Auto Pump
Off
Remote Control
1. Access the Home screen, touch
Pump
GTL
45 RPM
then the Advanced button
2. Touch Auto Pump to switch this option On or Off.
3. Touch Done.
NOTE: The Pump Control button changes to the following (light
orange) indicating the Auto Pump option is switched On.
