YSP20 - 第49页
Conv 1 Conv 2 58 49 23 24 49 56 57 49 59 6 17 60 3 47 3 4 8 48 4 18 7 15 29 34 16 31 13 47 26 53 38 2 50 51 36 43 19 33 45 28 42 50 18 46 52 22 30 44 17 22 9 17 40 5 8 10 12 1 1 55 20 14 20 35 1 27 13 54 19 39 28 10 37 4…
Conv 1
Conv 2
32
14
8
18
21
31
5
26
14
3
15
16
24
19
20
27
18
2
9
12
11
10
22
8
23
17
7
25
4
6
30
3
13
33
1
28
13
28
29
34
Conv 1/2 stand L (transport)
Conveyor
KKX-1305
8-2
Conv 2
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-11J001
SCREW, PAN HEAD W/W
2
2
91312-03010
BOLT HEX,SOCKET HEAD
4
3
91312-04006
BOLT HEX,SOCKET HEAD
4
4
91312-04050
BOLT HEX,SOCKET HEAD
4
5
91312-05010
BOLT HEX,SOCKET HEAD
1
6
91312-05012
BOLT HEX,SOCKET HEAD
2
7
91312-06016
BOLT HEX,SOCKET HEAD
2
8
91312-06020
BOLT HEX,SOCKET HEAD
4
9
KG2-M9108-11
COLLAR CONVEYOR
1
10
KGK-M9170-00
DC MOTOR ASSY.
1
11
KGT-M9135-00
PULLEY 1, SPLINE
1
12
KGT-M9193-00
NUT PLATE
4
13
KH2-M9105-11
PULLEY,MOTOR:P30-3GT
2
14
KH2-M9121-00
BEARING
2
15
KHT-M9111-02
PULLEY 1,MOTOR
1
16
KHT-M9113-00
COUPLING
1
17
KKX-M9107-00
BRKT.,CONV. MOTOR
1
18
KKX-M9108-00
SPLINE
1
18-1
KKX-M9108-01
SPLINE
1
OK
MKY0087-2014/1/14
19
KKX-M910A-00
PLATE,CONV. 1
1
20
KKX-M910B-10
PLATE,CONV. 2
1
Conv 1
21
KKX-M910B-60
PLATE,CONV. 2
1
Conv 2
22
KKX-M910G-10
BRKT.,CONV. 2L
1
Conv 1
23
KKX-M910H-10
BRKT.,CONV. 3L
1
24
91312-06025
BOLT HEX,SOCKET HEAD
2
25
92902-04200
WASHER,PLAIN
4
26
92902-05200
WASHER,PLAIN
1
27
92902-06200
WASHER,PLAIN
2
28
92A08-04306
SCREW SET
4
29
KLH-M91AH-00
BELT(219-3GT-9)
1
30
$CTAM1
ANCHOR MOUNT
2
31
KKX-M910G-00
BRKT.,CONV. 2R
1
Conv 2
32
90990-28J018
WASHER,PLAIN
1
MKY0087-2014/1/14
33
90990-41J106
COLLAR
1
MKY0087-2014/1/14
34
91312-04012
BOLT HEX,SOCKET HEAD
1
MKY0087-2014/1/14
Conv 1
Conv 2
58
49
23
24
49
56
57
49
59
6
17
60
3
47
3
4
8
48
4
18
7
15
29
34
16
31
13
4726
53
38
2
50
51
36
43
19
33
45
28
42
50
18
46
52
22
30
44
17
22
9
17
40
5
8
10
12
11
55
20
14
20
35
1
27
13
54
19
39
28
10
37
40
41
61
32
25
21
12
13
Conv 1/2 stand L (width adjust)
Conveyor
KKX-1305
8-3
Conv 2
NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date
1
KKX-M9A00-000 BALL SCREW W
1
2 90933-01J200 BEARING 1
3 90933-02J608 BEARING 2
4 90933-03J608 BEARING 2
4-1 90990-25J024 BEARING 2 OK MJ70186-2012/10/3
5 KKX-M911B-01 COVER,HNS.
1
6 90990-28J102 WASHER,PLAIN 1
7 90990-41J057 COLLAR 1
8 90990-41J128 COLLAR 2
9 90K63-221306 AC SERVO MOTOR
1
10 91312-03008 BOLT HEX,SOCKET HEAD 2
11 91312-03010 BOLT HEX,SOCKET HEAD 4
12 91312-04006 BOLT HEX,SOCKET HEAD 4
13 91312-04010 BOLT HEX,SOCKET HEAD 7
14 91312-04016 BOLT HEX,SOCKET HEAD 8
15 91312-05008 BOLT HEX,SOCKET HEAD 2
16 91312-05012 BOLT HEX,SOCKET HEAD 2
17 91312-05020 BOLT HEX,SOCKET HEAD 5
18 91312-06014 BOLT HEX,SOCKET HEAD 4
19 91312-06016 BOLT HEX,SOCKET HEAD 4
20 91312-06020 BOLT HEX,SOCKET HEAD 4
21 92902-04200 WASHER,PLAIN 2
22 92902-05200 WASHER,PLAIN 4
23 KG7-M9113-01 PULLEY 3
1
24 KH2-M9105-11 PULLEY,MOTOR:P30-3GT
1
25 KH2-M9121-00 BEARING
1
26 KHW-M9139-00 PLATE,BRG.
1
27 KKX-M652J-01 SENSOR W ORG ASSY
1
28 KKX-M9101-00 BLOCK,CONV. 2
29 KKX-M9102-10 LEG,CONV. 1L
1
Conv 1
30 KKX-M9102-60 LEG,CONV. 1L
1
Conv 2
31 KKX-M9103-01 LEG,CONV. 2R 1 Conv 2
32 KKX-M9103-11 LEG,CONV. 2L
1
Conv 1
33 KKX-M9104-00 STAY,GUIDE R
1
Conv 2
34 KKX-M9104-10 STAY,GUIDE L
1
Conv 1
35 KKX-M9105-00 GUIDE,WL
1
36 KKX-M910C-00 BRKT.,CONV. 1R 1 Conv 2
37 KKX-M910C-10 BRKT.,CONV. 1L 1 Conv 1
38 KKX-M910E-00 PLATE,NUT R
1
Conv 2
39 KKX-M910E-10 PLATE,NUT L
1
Conv 1
40 KKX-M910J-00 DAMPER 2
41 KKX-M910K-00 DOG,W ORG.
1
42 KKX-M9111-02 BRKT.,W MOTOR
1
43 KKX-M9113-02 BRKT.,TENSION
1
Conv 1
44 KKX-M9113-52 BRKT.,TENSION
1
Conv 2
45 KKX-M9114-00 BRKT.,TENSION
1
Conv 1
46 KKX-M9114-50 BRKT.,TENSION
1
Conv 2
47 92902-05600 WASHER,PLAIN 2
48 92902-08600 WASHER,PLAIN
1
49 92A08-04306 SCREW SET 6
50 95302-05600 NUT HEXAGON 2
51 95302-08600 NUT HEXAGON
1
52 97002-05016 BOLT HEXAGON
1
53 97002-05020 BOLT HEXAGON
1
54 97602-03310 SCREW PAN HEAD W/WASHER 2
55 99480-05014 PIN,PARALLEL 1
56 KKX-M9115-00 PULLEY:P18-5GT
1
57 KKX-M9118-00 BELT,W
1
58 KKX-M9119-00 BELT(252-3GT-9)
1
59 KKX-M911A-00 PIN,IDLER
1
60 90K81-200004 CAP C4 8
61 91312-04012 BOLT HEX,SOCKET HEAD 4 MJ70001-2012/7/5
Conv 1
Conv 2
32
6
42
2
17
40
35
16
9
6
32
36
4
5
27
4
11
27
33
31
8
3
10
1
4
8
5
26
24
23
25
32
43
3
21
42
13
27
17
15
1
47
14
35
24
4
5
39
23
45
19
6
30
48
34
34
37
20
28
18
30
34
3
7
1
5
24
23
38
3
24
46
1
5
23
33
8
10
12
41
31
8
32
13
22
29
44
Fix conv.
Conveyor
KKX-1305
8-4
Conv 2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-01J038
BOLT HEX,SOCKET HEAD
20
2
90990-11J001
SCREW, PAN HEAD W/W
3
3
90990-19J024
NEEDLE PIN
8
4
91312-03006
BOLT HEX,SOCKET HEAD
10
5
91312-03012
BOLT HEX,SOCKET HEAD
52
6
91312-04006
BOLT HEX,SOCKET HEAD
8
7
91312-04008
BOLT HEX,SOCKET HEAD
2
8
91312-04014
BOLT HEX,SOCKET HEAD
8
9
91312-05020
BOLT HEX,SOCKET HEAD
1
10
91312-06020
BOLT HEX,SOCKET HEAD
4
11
KKX-M9181-00
GUIDE 1,END
1
12
KKX-M9182-00
GUIDE 2,END
1
13
KGY-M9140-A0
PULLEY CONV. ASSY.
2
14
KKE-M9119-A0
PULLEY CONV. ASSY.
1
15
KKE-M9120-A0
PULLEY CONV. ASSY
1
16
KKX-M652C-01
SENSOR YMZ SAFE ASSY
1
17
KKX-M652L-00
SENS.YMYZ SAFE ASSY
2
18
KKX-M652S-01
SENS.CONV ENT ASSY
1
19
KKX-M652S-11
SENS.CONV EXIT ASSY
1
20
KKX-M652S-21
SENS.CONV SLOW ASSY
1
21
KKX-M9121-01
FRAME,FIXED
1
Conv 1
22
KKX-M9121-51
FRAME,FIXED
1
Conv 2
23
KKX-M9122-00
GUIDE,W BELT
4
24
KKX-M9123-00
PLATE,CONV.
4
25
KKX-M9124-00
BELT,CONVEYOR
1
26
KKX-M9125-01
GUIDE,X AXIS
1
27
KKX-M9134-00
COVER,X GUIDE
3
28
KKX-M9141-02
BRKT.,SENSOR 1
1
29
KKX-M91T1-00
BRKT.,SENSOR 1
1
30
92902-04200
WASHER,PLAIN
4
31
92902-04600
WASHER,PLAIN
4
32
92902-05200
WASHER,PLAIN
5
33
92902-06200
WASHER,PLAIN
4
34
97602-03310
SCREW PAN HEAD W/WASHER
6
35
97602-03314
SCREW PAN HEAD W/WASHER
4
36
98702-03010
SCREW,FLAT HEAD
2
37
KKX-M9142-02
BRKT.,SENSOR 2
1
38
KKX-M91T2-00
BRKT.,SENSOR 2
1
39
KKX-M9143-01
BRKT.,SENSOR 3
1
40
KKX-M9144-00
BRKT.,SENSOR 4
1
Conv 1
41
KKX-M9144-50
BRKT.,SENSOR 4
1
Conv 2
42
KKX-M9145-00
BRKT.,SENSOR 5
2
43
KKX-M9147-00
BRKT.,HNS.
1
Conv 1
44
KKX-M9147-50
BRKT.,HNS.
1
Conv 2
45
KKX-M9148-00
BRKT.,SENSOR 7
1
Conv 1
46
KKX-M9148-50
BRKT.,SENSOR 7
1
Conv 2
47
KKX-M9170-00
EXIT STOPPER 1 ASSY.
1
48
91312-04010
BOLT HEX,SOCKET HEAD
2
from 6 to 48
MJ00108-2012/10/24
