YSP20 - 第72页
16 22 18 13 1-6,35,36 7 14 8 19 1 1,37 9-10 20 19 17 23-34 12 19 1-6,35,36 15 20 21 7 8 16 19 1 1,37 9-10 17 Exterior Exterior ,etc KKX-1305 1 1-1 NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 KKE-M669…
7,27
26
19
10
11
12
8,9
2
13,28
5
3,4
1
6
1
14
2
24
20
22
2
23
25
13,28
21
18
16
17
15
8,9
2
12
11
10
7,27
26
19
10
11
12
8,9
2
13,28
5
3,4
1
6
1
14
2
24
20
22
2
23
25
13,28
21
18
16
17
15
8,9
2
12
11
10
Control Box
Control Box
KKX-1305
10-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90166-12JA10
SCREW PAN HEAD
6
2
97602-04308
SCREW PAN HEAD W/WASHER
13
3
KLA-M4209-00
SYSTEM UNIT ASSY
1
STD
4
KLA-M4209-20
SYSTEM UNIT ASSY
1
for INSPECTION
5
KLA-M4255-00
FLASH DISK
1
6
KHL-M441H-53
VISION BOARD ASSY
1
7
KHN-M4530-56
REMOTE IF BOARD ASSY
1
STD
8
KHN-M5840-B2
SERVO BOARD ASSY
2
STD SERVO BOARD 3
9
KHN-M5803-81
SERVO UNIT ASSY
2
for PSC SERVO BOARD 3
10
KJJ-M5880-20
D.POWER BOARD ASSY
2
11
KHN-M5840-02
SERVO BOARD ASSY
2
SERVO BOARD 1
12
KHN-M5840-A2
SERVO BOARD ASSY
2
SERVO BOARD 2
13
KJJ-M4140-10
DUMMY PANEL SERVO
4
STD
14
KJJ-M4141-00
DUMMY PANEL SYS
1
15
KJJ-M411A-00
PLATE
4
16
KJJ-M411B-00
BRACKET 2
4
17
KJJ-M53A9-20
FILTER
4
18
KJJ-M53E9-20
TAPE
4
19
KJX-M4116-00
BRACKET,1 FILTER
2
20
KJX-M4117-00
BRACKET,2 FILTER
2
21
KJX-M4216-00
BRACKET 1 FILTER
1
22
KJX-M4217-00
BRACKET 2 FILTER
1
23
KJX-M53A9-00.
FILTER
1
24
KJX-M53A9-20
FILTER
2
25
KJX-M53E9-00
TAPE
1
26
KJX-M53E9-20
TAPE
2
27
KHN-M4530-26
REMOTE IF BOARD ASSY
1
for YTC
28
KHN-M5840-52
SERVO BOARD ASSY
1
for YTC SERVO BOARD 4
16
22
18
13
1-6,35,36
7
14
8
19
11,37
9-10
20
19
17
23-34
12
19
1-6,35,36
15
20
21
7
8
16
19
11,37
9-10
17
Exterior
Exterior,etc
KKX-1305
11-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KKE-M669V-00
HNS,SWITCH ACTIVE
2
2
KKE-M669V-10
HNS,SWITCH READY
2
3
KKE-M669V-20
HNS,SWITCH START
2
4
KKE-M669V-30
HNS,SWITCH STOP
2
5
KKE-M669V-40
HNS,SWITCH ERR.CLR.
2
6
KKE-M669V-50
HNS,SWITCH RESET
2
7
KKE-M6555-A0
LANE SELECT SWITCH ASSY
2
8
KGK-M5138-00
SWITCH EMG ASSY
2
9
KGT-M5106-02
15"NORMAL LCD
2
AC100V
9-1
KGT-M5106-B0
SMT OPE.PANEL ASSY
2
DC12V
NG
MJ00092-2012/10/25
10
KKE-M5119-00
15"TOUCH LCD ASSY.
2
10-1
KGT-M5119-03
SMT OPE.T.PANEL ASSY
2
OK
MK20042-2013/2/25
11
KKX-M13B0-00
ERROR SIGNAL ASSY.
2
STD
12
KKX-M5126-30
SAFETY SW LOCK ASSY
1
13
KKX-M5126-40
SAFETY SW LOCK ASSY
1
14
KKX-M5126-20
SAFETY SW LOCK ASSY
1
15
KKX-M5126-00
SAFETY SW LOCK ASSY
1
16
KKX-M5126-10
SAFETY SW LOCK ASSY
2
17
91312-04045
BOLT HEX,SOCKET HEAD
16
18
KJJ-M4580-24
I/O CONV. BOARD ASSY
1
19
KGA-M4187-00
FAN GUARD 119MM
8
20
KHY-M6185-10
FAN MOTOR ASSY
4
21
KKE-M6554-00
MAIN SWITCH
1
22
KGK-M6680-20
HNS,USB MEMORY 2M AS
1
23
KJX-M4899-00
LIGHT 1 ASSY.
1
1850mm RYG
24
KJX-M4899-10
LIGHT 1 ASSY.
1
1850mm CBG
25
KJX-M4899-20
LIGHT 1 ASSY.
1
1900mm RYG
26
KJX-M4899-30
LIGHT 1 ASSY.
1
1900mm CBG
27
KJX-M4899-40
LIGHT 1 ASSY.
1
2000mm RYG
28
KJX-M4899-50
LIGHT 1 ASSY.
1
2000mm CBG
29
KJX-M4899-60
LIGHT 1 ASSY.
1
2100mm RYG
30
KJX-M4899-70
LIGHT 1 ASSY.
1
2100mm CBG
31
KJX-M4899-80
LIGHT 1 ASSY.
1
2200mm RYG
32
KJX-M4899-90
LIGHT 1 ASSY.
1
2200mm CBG
33
KJX-M4899-A0
LIGHT 1 ASSY.
1
2300mm RYG
34
KJX-M4899-B0
LIGHT 1 ASSY.
1
2300mm CBG
35
KKE-M669V-60
HNS,SWITCH STOP
2
for CE
36
KKE-M669V-70
HNS,SWITCH ERR.CLR.
2
for CE
37
KKX-M13B0-50
ERROR SIGNAL ASSY.
2
for CE
7
9
3
1
6
10
5
15
2
13
6
8
14
1
3
11
16
4
12
13
17,18
17,18
7
9
3
1
6
10
5
15
2
13
6
8
14
1
3
11
16
4
12
13
17,18
17,18
Brkt. Keyboard
Exterior, etc.
KKX-2103
11-2
OLD
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
8
2
90172-00J040
WASHER, EXTL, TOOTHED
8
3
90990-11J001
SCREW, PAN HEAD W/W
8
4
90990-41J007
COLLAR
2
5
90990-41J097
COLLAR
4
6
91312-04006
BOLT HEX,SOCKET HEAD
16
7
91312-04012
BOLT HEX,SOCKET HEAD
4
8
91312-05014
BOLT HEX,SOCKET HEAD
4
9
KG2-M1362-00
STOPPER
4
10
KGA-M13B2-01
SHAFT,KEYBOARD
2
11
KGA-M13B4-00
BRACKET, PAD
2
12
KGB-M1391-00
MOUSE PAD
2
13
KKX-M13K1-00
BRACKET,KEYBOARD
2
13-1
KKX-M13K1-01
BRACKET,KEYBOARD
1
NG
H028372-2021/3/10
14
KKX-M13K4-00
BRKT.,KEYBOARD
2
15
92902-04200
WASHER,PLAIN
8
16
KKX-M13K0-00
BRKT. KEYBOARD ASSY.
1
16-1
KKX-M13K0-01
BRKT. KEYBOARD ASSY.
1
NG
H028372-2021/3/10
17
KW3-M5150-50
KEYBOARD J
1
Japanese
17-1
KW3-M5150-01
KEYBOARD J
1
Japanese
NG
H028372-2021/3/10
18
KW3-M5150-60
KEYBOARD E
1
English
18-1
KW3-M5150-11
KEYBOARD E
1
English
NG
H028372-2021/3/10
