- 12 -
get the best holding force. Edge holding system uses the software to control and
adjust the pressure to match thickness of the programmed base board. This solution
can help the top holding system to hold the base board firmly. It can support the best
connection between the template and base board and insure the Effective
precipitation of the solder paste and improve the printing quality.
1.4.3 图像捕捉系统 Image capture system
组成：包括 CCD 运动部分和 CCD—Camera 装置（摄像头、光源）及高分辨率显示器等，
由视觉系统软件进行控制。
Component: It includes the CCD movement, CCD-Camera device (camera, light source)
and high resolution screen etc.. Control by the visual system software.
功能：上视/下视视觉系统，独立控制与调节的照明，高速移动的镜头确保快速、精确地进行
PCB 和钢网板对准，无限制的图像模式识别技术具有 0.01mm 的辩识精度。
Function: Up/down visual system, independent controllable and adjustable lighting, high
speed mobile lens which can insure the make the PCB and stencil aligned fast and
accurate. Unlimited image pattern recognition technology reaches 0.01mm recognition
accuracy.
1.4.4 钢网自动定位及其清洁系统 Stencil automatically positioning and the
cleaning system
1.4.4.1 钢网自动定位系统 Stencil automatically positioning
组成：包括网板移动装置及网板固定装置等。
Component: It includes stencil mobile device and stencil fixed device etc..
功能：只需输入钢网 MARK 点位置就可以自动定位,更方便用户不同大小钢网的灵活更换.
适用的钢网夹持装置,可支持钢网最小为 370x470mm（470 左右方向放置),最大为 737×737mm,厚度
20~40mm.
Function: Inputting the stencil mark location can positioning automatically and it is
convenient for operator to replace different sizes of stencil. The stencil holding device can
hold the Min. stencil whose size is 370x470mm (470 left and right direction placed) and
Max. stencil whose size is 737×737mm and thickness is 20~40mm.
- 13 -
1.4.4.2 钢网清洗系统-擦拭组件 Stencil cleaning system-wipe component
组成：包括真空管、文丘里管、鼓风机、清洗液储存和喷洒装置、卷纸装置、升降气缸等。
网板清洗装置被安装在视觉系统后面，通过视觉系统拖动清洗系统移动，自动清洗网
板底面。
进行清洗时清洗卷纸上升并且贴着模板底面移动，用过的清洗纸被不断地绕到另一滚
筒上。清洗间隔时间可自由选择，清洗行程可根据印刷行程自行设定。进行湿洗时，
当储存罐中清洗液不够时，系统出现报警显示，此时应将其充满清洗液。干、湿、真
空洗周期可自由调节。
Component: It includes vacuum tube, venturi tube, blower, liquid restore and spraying
device, paper roller, lifting cylinder etc.. Stencil cleaning device is assembled behind the
visual system. Cleaning system will remove by the dragging from visual system. The
bottom of the stencil will be cleaned automatically.
The cleaning roller paper lift up and remove on the bottom of the template when do the
cleaning. The used cleaning paper will roll to another roller continually. The cleaning
interval can be selected freely. The cleaning movement can be set on the base of the
printing movement. Doing the wet cleaning, the system will alarm if there is not enough
cleaning liquid in the restore container. Then operator need full the container with cleaning
liquid. The cycle of the dry/wet/vacuum cleaning can be adjusted freely.
功能：
自动有效的分离式清洗结构，大功率风机加文丘里真空发生装置抽真空，喷射系统加可编程
的喷洒清洗液，干﹑湿﹑真空三种清洗方式,并可任意选择自由组合，用户可根据实际需求设
定清洗周期﹑时间及速度等参数，长短擦拭纸通用,拆卸方便,节约资源；加强型的真空栅,充
分利用风机效率, 彻底清除网板孔中的残留锡膏，保证印刷品质。
Function: Automatic, effective and separating cleaning structure. High power fan and
venture vacuum device do the vacuum pump. Spraying system, programmed spraying
cleaning liquid and three cleaning methods (dry/wet/vacuum). These can be selected and
combined freely. Operator can set the cleaning cycle, time, speed etc according to the
actual need. General paper is easy to assemble and disassemble and it can save resource.
Enhanced vacuum gate and good fan can removed the remaining solder paste in the hole
on the stencil. It can insure the printing quality.
- 14 -
1.4.5 刮锡系统 Solder paste removed system
组成：包括印刷头（刮刀升降行程自动调节装置、刮刀片安装部分）、刮刀横梁及刮刀驱动部
分（步进马达、驱动皮带等）等。
Component: Printing head (scraper lifting movement automatic adjustment device, scraper
blade assembling section), scraper beam, scraper drive section (stepping motor,
driving belt) etc..
功能：悬浮式能平衡自重的自适应刮刀，刮刀 Y 方向驱动使用随动结构，双滑块线性导轨，
印刷平稳,动作敏捷，独立直联式步进马达控制,内置精确压力控制系统，能精确的测定刮刀原
始压力值,无需顾及刮刀片类型，长度，重量或者厚度的变化.可编程实现印刷工艺灵活多变。
Function: Suspended, balanced and adaptive scraper. The driving on the Y direction of the
scraper is moving structure. The linear rail has two sliders. These make the printing even,
stable and fast. Controlled by the independent and direct stepping motor. Accurate
pressure control system can set the original pressure value precisely regardless of the
change of the type, length, weight and thickness of scraper. It can be programmed to insure
the flexibility of the printing technology.
1.4.6 电控系统 Electronic control system
组成:Windows XP 操作系统，集成电路，智能化的先进软件控制。
Component: Windows XP system, integrated circuit, advanced intelligent control
software
特点：安全，维修方便，极大地方便了用户的使用。
Feature: Safe, convenient maintenance and easy operation.
1.5 工作原理 Working principles
由以上各部组成的全自动视觉印刷机在印刷焊膏时，锡膏受刮刀的推力产生滚动的前进，
所受到的推力可分解为水平方向的分力和垂直方向的分力。当运行至模板窗口附近，垂直方
向的分力使粘度已降低的焊膏顺利地通过窗口印刷到 PCB 焊盘上，当平台下降后便留下精确
的焊膏图形。
When the automatic visual printer prints the solder paste, the solder paste will move
forward with the force from the scraper. The force will be divided into horizontal component
and vertical component. When move to the nearby of the template window, the vertical
