- 6 9 - 作。 : S tart. After clicking this button, the sy stem will judge whether th ere is PCB board on the transmission rail and will indicate whether it needs to adjust the width o f the transmission rail etc. The equip…

- 68 -

图 4-13（刮刀设

13：：界面切换按钮。单击该按钮进行生产界面与主界面的切换；

: Interface shift. Do the shift of the production interface and main

interface by clicking this button.

14：：退出按钮。单击该按钮退出系统；

: Exit. Exit the system by clicking this button.

15：：开始按钮。单击该点击该按钮后系统会执行“判断运输导轨上有 PCB

板”、以及“提示是否调整运输导轨的宽度”等操作，依次点击是或否后机器执行印刷操

- 69 -

作。

: Start. After clicking this button, the system will judge whether there

is PCB board on the transmission rail and will indicate whether it needs to adjust

the width of the transmission rail etc. The equipment will do the printing operation

by clicking “是 ”（yes）button or “否”（no）button .

16：：暂停按钮。此按钮只作为状态提示；

: Pause. This button is only used as the notes for the state.

17：：停止按钮。点击该按钮并确认后机器会停止生产动作；

: Stop. The printer will stop production by clicking this button.

4.2.3 附属菜单解释及其操作 Function explanation and operation of attached

1：：主界面点击菜单进入如图 4-14

:Click “menu” button in the main interface to enter the

interface in the pix 4-14

- 70 -

图 4-14（附属菜单）

Pix 4-14(attached menu)

2：：操作按钮。在图 4-14 中点击操作按钮打开操作菜单如图 4-15

: Operation. Open the operation menu by click this button in pix 4-14.

See pix 4-15.
