Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 5A8 221HA105 W ASHER 4 1 100103K00-108 5B1 0916DK20 SHAFT 1 2091603K01-001 5B2 23K10341 CASE_CONN 1 2091603K01-002 5B3 23K10287 CASE_CONN 1 2091603K01-003 5B4 4J300048 CAB…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
501 0916DK2A MOTOR 1 1100103K00-001
504 225F0702 PIPE FITTINGS 1
1100103K00-004
507 221C0080 SET SCREW 1
1100103K00-007
508 225F0612 PIPE FITTINGS 1
1100103K00-008
510 0916DK39 GUIDE_LINEAR 1
1100103K00-010
517 0916D30T COUPLING 1
1100103K00-017
518 222D0425 BEARING_RADIAL 1
1100103K00-018
519 222D0426 BEARING_RADIAL 1
1100103K00-019
520 222D0430 BEARING_RADIAL 2
1100103K00-020
522 226A0293 SEAL 2
1100103K00-022
523 226A0190 SEAL 2
1100103K00-023
524 09163N06 ASSY_SENSOR 1
1100103K00-024
535 0916DK21 ROD 1
1100103K00-035
536 211G5983 BLOCK 1
1100103K00-036
537 0916DK3L BLOCK 1
1100103K00-037
546 211FD778 BRACKET 1
1100103K00-046
548 0916D333 COUPLING 1
1100103K00-048
549 211E1034 SPACER 2
1100103K00-049
551 225F0427 PIPE_FITTINGS 1
1100103K00-051
556 221G0206 NUT 1
1100103K00-056
557 0916DK3E HOLDER 1
1100103K00-057
558 222D0435 BEARING RADIAL 1
1100103K00-058
559 0916DK27 COLLAR 1
1100103K00-059
560 0916DK28 ROD 1
1100103K00-060
561 0916DK2F SPRING_COMP 1
1100103K00-061
562 221KA002 RING_E_2 1
1100103K00-062
563 216A1582 COLLAR 2
1100103K00-063
564 222D0439 BEARING_RADIAL 1
1100103K00-064
567 221H0266 WASHER 1
1100103K00-067
568 211AC769 COVER 1
1100103K00-068
569 211DE191 PLATE 2
1100103K00-069
575 221AA333 ROHS_HEX-SCT 3
1100103K00-075
577 221AA001 ROHS_HEX-SCT 3
1100103K00-077
582 221AA005 ROHS_HEX-SCT 2
1100103K00-082
583 221AA006 ROHS_HEX-SCT 5
1100103K00-083
584 221AA007 ROHS_HEX-SCT 11
1100103K00-084
587 221AA031 ROHS_HEX-SCT 4
1100103K00-087
589 221DA003 MACHINE SCREW 2
1100103K00-089
591 221CA026 SET SCREW 2
1100103K00-091
597 221HA001 WASHER 8
1100103K00-097
598 221HA101 WASHER 8
1100103K00-098
5A2 221HA003 WASHER 14
1100103K00-102
5A3 221HA103 WASHER 14
1100103K00-103
5A5 221AA115 BOLT_HEX-SCT 6
1100103K00-105
5A7 221HA005 WASHER 4
1100103K00-107
1202-001
Fig. A1-6
Fig. A1
GS-HH160
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
5A8 221HA105 WASHER 4 1100103K00-108
5B1 0916DK20 SHAFT 1
2091603K01-001
5B2 23K10341 CASE_CONN 1
2091603K01-002
5B3 23K10287 CASE_CONN 1
2091603K01-003
5B4 4J300048 CAB_JOINTSLEEVE 11
2091603K01-004
5B5 23K10264 CASE_CONN 1
2091603K01-005
5B6 4J300047 CAB_JOINTSLEEVE 3
2091603K01-006
5B7 23K00012 CONTACT_PARTS_C 4
2091603K01-007
5B8 0916D305 CORD 1
2091603K01-008
5B9 0916D304 CORD 1
2091603K01-009
5C0 0916D303 CORD 1
2091603K01-010
5C1 0916D302 CORD 1
2091603K01-011
5C2 0916D30E CORD 1
2091603K01-012
5C3 0916D30F CORD 1
2091603K01-013
5C4 0916D30A CORD 1
2091603K01-014
5C5 0916D309 CORD 1
2091603K01-015
5C6 0916D308 CORD 1
2091603K01-016
5C7 0916DK2M BOARD 1
2091603K01-017
5C8 0916DK2N BOARD 1
2091603K01-018
5D0 23N20110 TUBE_WIRING 9
2091603K01-020
Fig. A1
1202-001
Fig. A1-6
GS-HH160
平成
24
年
2
月
初版発行
Published, Feb. 2012
CHIP MOUNTING SYSTEM
立体分解図
EXPLODED ILLUSTRATION
編集及び発行所
Editing & Publishing
Printed by T.H.I
不許複製
1202-001
奥付
COLOPHON
