Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 101 0916D20J P_C_B_MOUNT 1 1 100103M00-001 102 225F0656 PIPE FITTINGS 1 1 100103M00-002 103 225F0566 PIPE FITTINGS 1 1 100103M00-003 104 09163N00 ASSY_V AL VE 1 1 100103M0…
134
131
136
U03
Y0902
X0307
X0305
X0306
U25
X2503
X2501
X2507
X2504
X25B2
X25X1
X25X2
X3105
X3103
X31P1
A31
5
N C
A
2 P N C
B 2 P
N C
C
2 P
N C
D
2 P N C
A
2
N C
B 2 N
C
C 2 N C
D 2 N C
3 P
N C
1
P N
C
D 4 N
C
C 4
N C B 4 N C 3 N C
X3104D
X3104B
X3104C
X331P1
X131P1
X12501
X13701
B3106
B3103
X23701
7 N
C
1 N
C
2 N
C
3 N C
2 0 X
1
0
X
1
0
B
4
N
C
2
0
B
6
N C
5 N C
135
132
104
133
141
141
141
Fig. A1
1202-001
Fig. A1-2
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 0916D20J P_C_B_MOUNT 1 1100103M00-001
102 225F0656 PIPE FITTINGS 1
1100103M00-002
103 225F0566 PIPE FITTINGS 1
1100103M00-003
104 09163N00 ASSY_VALVE 1
1100103M00-004
105 225B0573 AIR LINE EQPT 1
1100103M00-005
106 0916DM17 BRACKET 1
1100103M00-006
107 0916DM18 BOX 1
1100103M00-007
108 221DA051 SEMS_PANHEADSCR 18
1100103M00-008
109 221DA057 MACHINE_SCREW 4
1100103M00-009
110 221A0245 BOLT_HEX-SCT 2
1100103M00-010
113 221AA021 ROHS_HEX-SCT 1
1100103M00-013
114 221HA001 WASHER 2
1100103M00-014
116 221HA004 WASHER 1
1100103M00-016
117 221HA101 WASHER 2
1100103M00-017
119 221HA104 WASHER 1
1100103M00-019
120 221DA056 MACHINE SCREW 4
1100103M00-020
131 4W204782 CORD 1
1100103M00-101
132 4W204987 CORD 1
1100103M00-102
133 1001DN04 CORD 1
1100103M00-103
134 4W204984 CORD 1
1100103M00-104
135 4W204985 CORD 1
1100103M00-105
136 4W204786 CORD 1
1100103M00-106
139 23N30632 WIRING 12
1100103M00-109
141 0916D209 ACCESSORY_WRING 25
1100103M00-111
142 0916D20D ACCESSORY_WRING 1
1100103M00-112
151 0916D20A TUBE D4 1
3100103J02-001
152 0916D20Q TUBE D8 1
3100103J02-002
1202-001
Fig. A1-2
Fig. A1
GS-HH160
