Safety Guidelines
Edition 1.0 11 QP-132 Level 3 Tutorial
Wear protective gloves when handling glue or solder
paste.
● When handling glue or solder paste, wear protective gloves to avoid
solder or glue coming into contact with the skin.
● When using solvent to clean machine parts, use protective gloves,
eyewear, a face shield and an apron.
● In case glue, solder paste, etc. comes into contact with the skin, use
plentiful amounts of water, cleaning fluid or alcohol to remove the
glue or solder paste.
All chemicals and industrial waste must be handled in
compliance with local regulations.
CAUTION
6. Safety Labels
To warn the operator of hazards, safety labels are attached to the machine at the
positions indicated in the figure below.
Familiarize yourself with each label and its message before operating the machine.
QP1MO001
R
E
S
E
T
R
E
S
E
3
4
1
2
5
7
Never insert your hand
inside an operating machine.
Moving parts may cause injury.
DANGER
CAUTION
Make sure that nozzles are up position when PFU is installed
or removed in order to avoid damages to nozzles.
Verifier que les buses sont en position haute lors de I'insertion
ou du retrait d'un PFU pour eviter d'endomagger les buses.
3
7
1
1
1
1
5
2
1
7
7
7
1
4
6
6
Never load 2 pallets
simultaneously.
DANGER
Safety Guidelines
Edition 1.0 12 QP-132 Level 3 Tutorial
(Continued from the previous page.)
2
9
5
8
1
11
10
1
1
1
1
1
1
4
1
1
1
5
2
1
To avoid damage,
do not open the drawer
during operation.
CAUTION
CAUTION
BE SURE TO WEAR THE WRIST STRAP
BEFORE WORKING IN THE CONTROL BOX.
1. TAKE OUT THE WRIST STRAP FROM THE
CONTROL BOX.
2. PUT ON THE WRIST STRAP. 3. START WORK IN THE CONTROL BOX.
<CAUTION>
It is NOT possible to use the main or rear
control panels while the inching box is in use.
(With the exception of the ON, OFF, CYCLE STOP
and EMERGENCY STOP buttons.)
<CAUTION>
AN EXPLOSION MAY OCCUR IF THE BATTERY IS NOT REPLACED
PROPERLY. USE THE BATTERY TYPE SPECIFIED BY FUJI (OR
EQUIVALENT BATTERY TYPE). USED BATTERIES MUST BE
DISCARDED FOLLOWING THE MANUFACTURER'S INSTRUCTIONS.
10
11
9
8
QP1MO002
Safety Guidelines
Edition 1.0 13 QP-132 Level 3 Tutorial
