18.第13ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出)(DCPK) 18.Station 13(Parts eject)(DCPK) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Material 115 DCPU0220 1 RETAINER 押え FE 116 H5274A 2 BOLT, HEX SOCK…

100%1 / 257
18.第13ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出)(DCPK)
18.Station 13(Parts eject)(DCPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Material
75 W1043A 1
WASHER, FLAT ﾜｯｼｬ 平
4W-4
FE
76 DGPU0420 1
BKT
BKT
FE
77 H5288A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M04x010
FE
78 W1022A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
4M/M
FE
81 W1011A 2
WASHER, CONICAL ﾜｯｼｬ 皿
M-4-L
FE
82 DCPU0410 1
PIN, ECCENTRIC ﾋﾟﾝ 偏心 FE
83 DCPU0040 1
JOINT
ｼﾞｮｲﾝﾄ
FE
84 N1089A 1
NUT, HEX ﾅｯﾄ 六角
M8 P=1.25
FE
85 DCPU0050 1
BKT
BKT
FE
86 H5300A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M05×015 HRC34-44
FE
87 W1023A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
5M/M
FE
88 W1044A 2
WASHER, FLAT ﾜｯｼｬ 平
4W-5
FE
89 DCPU0171 1
BKT, SENSOR
BKT ｾﾝｻ
FE
90 H5275A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×008
FE
91 W1021A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
92 W1040A 2
WASHER, FLAT ﾜｯｼｬ 平
3M/M×0.5×7
FE
93 DCPU0181 1
BKT, SENSOR
BKT ｾﾝｻ
FE
94 H5275A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×008
FE
95 W1021A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
96 W1040A 2
WASHER, FLAT ﾜｯｼｬ 平
3M/M×0.5×7
FE
97 DCPU0190 1
CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ FE
98 N1089A 1
NUT, HEX ﾅｯﾄ 六角
M8 P=1.25
FE
99 W1025A 1
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
8M/M
FE
100 S1053A 2
SILENCER ｻｲﾚﾝｻ
SL-1
FE
101 H1081N 1
VALVE, SOL ﾊﾞﾙﾌﾞ SOL
PCS245-01-D24-SP
FE
102 H5280A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×020
FE
103 W1021A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
104 W1040A 2
WASHER, FLAT ﾜｯｼｬ 平
3M/M×0.5×7
FE
105 Y3044H 2
UNION
ﾕﾆｵﾝ M-5ER
FE
106 Y30827 2
UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ
KQ2H06-M5
FE
107 Y3083A 3
UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ
KQ2H06-01S
FE
109 Y3061W 2
UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ
KJS06-M5 (白)
FE
110 K5342D 2
CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ
AS2201F-01-06S (白)
FE
111 S40443 2
SENSOR
ｾﾝｻ EE-SX770(A)
FE
112 H5275A 4
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×008
FE
113 W1021A 4
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
114 DCPU0210 1
BOX
BOX
FE
CP-733E,CP-732E PARTS LIST
18 - 5
18.第13ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出)(DCPK)
18.Station 13(Parts eject)(DCPK)
18.第13ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出)(DCPK)
18.Station 13(Parts eject)(DCPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Material
115 DCPU0220 1
RETAINER 押え FE
116 H5274A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×006
FE
117 W1021A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
118 DCPU0230 1
RETAINER 押え FE
119 H5274A 2
BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴
M03×006
FE
120 W1021A 2
WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ
3M/M
FE
121 DCPU0240 1
PLATE ﾌﾟﾚｰﾄ FE
122 DCPU0310 1
SHEET, RUBBER
ｼｰﾄ ｺﾞﾑ
PL
123 MPK0294 1
PIN
ﾋﾟﾝ
FE
124 MPK0300 1
SPRING
ｽﾌﾟﾘﾝｸﾞ
FE
125 DCWZ0220 1 BKT BKT FE
126 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
127 W1023A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
128 DCWZ0050 1 PLATE ﾌﾟﾚｰﾄ FE
129 H5287A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
130 W1022A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
131 T2063A 1 TUBE ﾁｭｰﾌﾞ TU0604B-20 OT
132 H4403A 1
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA 810Z FE
CP-733E,CP-732E PARTS LIST
18 - 6
18.第13ｽﾃｰｼｮﾝ(NGﾊﾟｰﾂ排出)(DCPK)
18.Station 13(Parts eject)(DCPK)
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
0.5 1 2 10
47
57
14
23
25
62
逆流れ
Right-to-left board frow
22
25
26
35
51
24
21
29
52
52
55
52
52
52
52
41
40
40
40
40
40
34
35
51
23
52
41
1
60
43
2
51
36
31
43
56
15
52
43
4
39
50
59
55
52
42
33
38
54
27
28
51
35
60
52
3
17
7
48
17
41
56
5
6
57
45
52
61
32
58
49
10
18
19
19
20
19
18
19
12
44
13
13
44
57
46
8
9
17
52
61
57
67
66
65
63
64
19 - 1
19.Waste tape cutter(DCPK)
19.残テープカッタ(DCPK)
19.Waste tape cutter(DCPK)
19.残テープカッタ(DCPK)
x5.5
CP-733E,CP-732E PARTS LIST
逆流れのセンサ見えなくしてある(ctr＋Ｙで)
