2.ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(DCPH)
2.Placing head(DCPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 H30763 1 RING, LOCKING ﾘﾝｸﾞ 締結 EPT-K-25 XNo.49∼ 注1．Note.1 OT
2 DCPH0060 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
3 DCPH0070 1 BEARING, ROLLER ﾍﾞｱﾘﾝｸﾞ ﾛｰﾗ ZCRB19211AUE01 OT
4 DCPH0630 16 FILTER ﾌｨﾙﾀ OT
5 DCPH0560 16 SHAFT, SPLINE ｼｬﾌﾄ ｽﾌﾟﾗｲﾝ LT8UUCLS+126.5L OT
6 DCPH0551 16 SHAFT ｼｬﾌﾄ CPU-22-A-T4 OT
7 DCPH0110 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ 2RSR7WMUUC1S+200LPMS OT
8 DCPH0100 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ 2RSR7WMUUC1S+140LPMS OT
9 DCPH0201 16 SLEEVE ｽﾘｰﾌﾞ FE
10 DCPH0742 16 SHAFT ｼｬﾌﾄ FE
12 DCPH3270 1 GEAR, HELICAL ｷﾞﾔ ﾍﾘｶﾙ XNo.49∼ 注1．Note.1 OT
13 DCPH0010 1 CAM, CYLINDRICAL ｶﾑ 円筒 FE
14 DCPH0050 1 GEAR, HELICAL ｷﾞﾔ ﾍﾘｶﾙ XNo.49∼ 注1．Note.1 FE
15 K1005X 16 COUPLING ｶｯﾌﾟﾘﾝｸﾞ CPU-22-A-T1 OT
16 H4118H 16
BEARING
ﾍﾞｱﾘﾝｸﾞ SST-1680 FE
17 H4581A 16 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ BK81010A FE
18 A5138A 1
O RING
Oﾘﾝｸﾞ S32 OT
19 DCPH0641 16 CLUTCH ｸﾗｯﾁ FE
20 DCPH0681 16 VALVE ﾊﾞﾙﾌﾞ OT
22 DCPH0300 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ FE
23 DCPH0220 16 NIPPLE ﾆｯﾌﾟﾙ AL
24 DCPH0690 16 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ PL
25 DCPH0261 1 HOSE, AIR ﾎｰｽ ｴｱｰ SR-1554 OT
26 DCPH0150 1 JOINT ｼﾞｮｲﾝﾄ FE
27 DCPH0090 1 SLIDER ｽﾗｲﾀﾞ FE
28 DCPH0651 16 SPRING ｽﾌﾟﾘﾝｸﾞ FE
29 DCPH0700 16 HOLDER ﾎﾙﾀﾞ OT
30 ADCPH3123 16 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
31 DCPH0022 1 DRUM ﾄﾞﾗﾑ AL
32 DCPH0170 1 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ FE
33 DCPH0130 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ FE
34 DCPH0191 16 CLAMPER ｸﾗﾝﾊﾟ FE
35 DCPH0181 16 CLAMPER ｸﾗﾝﾊﾟ FE
36 DCPH0750 16 WASHER ﾜｯｼｬ FE
37 DCPH0590 16 WASHER ﾜｯｼｬ FE
38 DCPH0031 32 PIN ﾋﾟﾝ OT
39 DCPH0120 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ FE
CP-733E,732E PARTS LIST
2 - 3
2.ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(DCPH)
2.Placing head(DCPH)
2.ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(DCPH)
2.Placing head(DCPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
40 DCPH0160 1 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ FE
41 DCPH0080 1 SLIDER ｽﾗｲﾀﾞ FE
42 DCPH0140 1 JOINT ｼﾞｮｲﾝﾄ FE
43 ADCPH3233 16 SHAFT ASSY ｼｬﾌﾄ ASSY OT
44 WPL0232 2 NUT ﾅｯﾄ FE
45 WPH0870 16 BKT BKT FE
46 DCPH0601 16 SPRING ｽﾌﾟﾘﾝｸﾞ FE
47 WPH2120 16 PIN ﾋﾟﾝ FE
48 H3181E 2
PLATE, END
ﾌﾟﾚｰﾄ ｴﾝﾄﾞ MBWT5 FE
49 H3181Z 1
PLATE, END
ﾌﾟﾚｰﾄ ｴﾝﾄﾞ PBR8FN FE
50 S1021A 16
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3 FE
51 W1019T 48 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ BBY0062611AO FE
52 H4451A 16
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ FE
53 H4407T 16 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA1015Z FE
54 H1163A 32 PACKING ﾊﾟｯｷﾝ MY-8 OT
55 A5054Y 32 O RING Oﾘﾝｸﾞ 4-1W OT
56 A5129T 16
O RING
Oﾘﾝｸﾞ S5 OT
57 ADCPH3262 16 HOLDER ﾎﾙﾀﾞ OT
58 DCPQ0260 1 DOG ﾄﾞｯｸﾞ FE
59 H2040A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ ﾟ2X5 FE
60 DCPH0721 1 COLLAR ｶﾗｰ PL
61 H52681 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.5X18L FE
62 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
63 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
64 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
66 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L FE
67 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
68 K52565
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L FE
69 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
70 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
71 K5261H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X12L FE
72 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L FE
73 H5195A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M8X25L FE
74 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M FE
75 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
76 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
77 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
CP-733E,732E PARTS LIST
2 - 4
2.ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(DCPH)
2.Placing head(DCPH)
2.ﾌﾟﾚｰｼﾝｸﾞﾍｯﾄﾞ(DCPH)
2.Placing head(DCPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
78 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
79 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
80 N1082A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8 FE
81 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 FE
82 N1089A
NUT, HEX
ﾅｯﾄ 六角
M8 P=1.25 3種 FE
83 H5165A
BOLT, HEX
ﾎﾞﾙﾄ 六角
M3X10BL FE
84 H5266A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X6L FE
85 W1020A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
86 W1050A WASHER, FLAT ﾜｯｼｬ 平 5M/MX1.0X10(1W-5) FE
87 ADCPH3130 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ OT
88 ADCPH3140 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ OT
89 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
91 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L FE
92 ADCPH3161 1 CAM, CYLINDRICAL ｶﾑ 円筒 OT
93 ADCPH3250 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ OT
94 ADCPH3181 1 DRUM ﾄﾞﾗﾑ OT
95 ADCPH3190 16 SHAFT ｼｬﾌﾄ OT
97 DCPH0270 1 GEAR, HELICAL ｷﾞﾔ ﾍﾘｶﾙ ∼XNo.48 注2．Note.2 FE
98 DCPH0280 1 RING, LOCKING ﾘﾝｸﾞ 締結 ETP-K-20-T4 ∼XNo.48 注2．Note.2 OT
99 DCPH0764 1 SHAFT ｼｬﾌﾄ 注3．Note.3 FE
100 DCPH0774 1 SHAFT ｼｬﾌﾄ 注3．Note.3 FE
101 DCPH0784 1 SHAFT ｼｬﾌﾄ 注3．Note.3 FE
102 DCPH0794 1 SHAFT ｼｬﾌﾄ 注3．Note.3 FE
104 DCWM0040 3 SEAL ｼｰﾙ Ref.P32-6 PL
105 DCPH1140 1 SEAL ｼｰﾙ PL
106 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
107 DCPH0040 GEAR, HELICAL ｷﾞﾔ ﾍﾘｶﾙ FE
108 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-L FE
109 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/M(1W-8) FE .
注1.№1と№12と№14は組合わせ部品ですので同時に交換してください｡
注2.№97と№98は組合わせ部品ですので同時に交換してください｡
注3.(仕様選択部品)DCPH0762(φ=0.053),DCPH0772(φ=10.048),DCPH0782(φ=10.043),DCPH0792(φ=10.038)
Note.1:No.1,No.12,No.14 are used as set. If the replacement of one is necessary all must be replaced.
Note.2:No.97,No.98 are used as set. If the replacement of one is necessary both must be replaced.
Note.3:(Specified parts selection)DCPH0762(φ=0.053),DCPH0772(φ=10.048),DCPH0782(φ=10.043),DCPH0792(φ=10.038)
