24.1.ｶﾑﾎﾞｯｸｽ(DCPA) 24.1.Cam box(DCPA) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 119 DCPA0430 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ 注1.Note.1 FE 120 DCPA0440 1 HOUSING …
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
48 DCPA0460 2 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め FE
49 DCPA0270 1 KEY ｷｰ FE
50 DCPA1540 1 SHAFT ｼｬﾌﾄ FE
51 DCPA1570 1 GEAR ｷﾞﾔ OT
52 DCPA1580 2 GEAR, PINION ｷﾞﾔ ﾋﾟﾆｵﾝ OT
53 DCPA0490 1 GEAR, BEVEL ｷﾞﾔﾍﾞﾍﾞﾙ OT
56 DCPA0500 1 KEY ｷｰ FE
57 DCPA0260 1 SCREW, ADJUSTING ﾈｼﾞ 調整 FE
60 DCPA0280 1 BKT, ADJUSTING BKT 調整 FE
61 DCPA0520 1 COLLAR ｶﾗｰ FE
62 DCPA0451 1 COVER 蓋 FE
64 DCPA1410 1 SHAFT ｼｬﾌﾄ FE
65 DCPA1440 1 HOUSING ﾊｳｼﾞﾝｸﾞ FE
66 DCPA1500 2 NUT ﾅｯﾄ FE
67 DCPA1520 2 COLLAR ｶﾗｰ CO
68 DCPA1530 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
69 DCPA1610 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
70 DCPA1420 1 SHAFT ｼｬﾌﾄ FE
71 DCPA1450 1 HOUSING ﾊｳｼﾞﾝｸﾞ FE
72 DCPA1510 4 BLOCK 駒 CO
73 DCPA1460 2 COVER ｶﾊﾞｰ FE
77 DCPA0300 1 PLATE ﾌﾟﾚｰﾄ FE
78 DCPA0320 1 BKT BKT FE
79 DCPA0330 2 BKT BKT FE
80 DCPA0390 1 SHAFT ｼｬﾌﾄ FE
81 DCPA1270 1 SHAFT ｼｬﾌﾄ FE
82 DCPA0340 1 BKT BKT FE
83 DCPA0380 3 COLLAR ｶﾗｰ FE
84 DCPA1290 1 BKT BKT FE
85 DCPA1150 1 HOLDER ﾎﾙﾀﾞ AL
92 DCPA0082 1 BKT, MOTOR BKT ﾓｰﾀ FE
93 DCPA0840 1 BKT BKT FE
100 DCPA1140 1 BKT BKT FE
111 DCPA0890 1 PLATE ﾌﾟﾚｰﾄ FE
112 DCPA0861 2 PIN, LOCATING ﾋﾟﾝ め置決め FE
114 DCPA1640 1 PLATE ﾌﾟﾚｰﾄ FE
115 DGPA0060 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ FE
116 DCPA1200 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ FE
117 DCPA1310 1 BKT BKT 注1.Note.1 FE
118 DCPA1320 1 BKT BKT 注1.Note.1 FE
CP-733E,CP-732E PARTS LIST
24 - 4
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
119 DCPA0430 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ 注1.Note.1 FE
120 DCPA0440 1 HOUSING ﾊｳｼﾞﾝｸﾞ 注1.Note.1 FE
140 DCPA1031 1 BKT BKT FE
141 DCPA0400 1 SHAFT ｼｬﾌﾄ FE
142 DCPA0880 2 PIN, LOCATING ﾋﾟﾝ 位置決め FE
143 DCPA0870 2 PIN, LOCATING ﾋﾟﾝ 位置決め FE
146 S1012A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ RTW52 OT
147 H4189Y 2
BEARING
ﾍﾞｱﾘﾝｸﾞ 6205ZZ OT
148 H4181A 6
BEARING
ﾍﾞｱﾘﾝｸﾞ 6003ZZ OT
149 S1036A 3
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW17 OT
153 H4232X 4 BEARING ﾍﾞｱﾘﾝｸﾞ HR32006XJP5 OT
154 S1039A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW25 OT
156 S40443 4 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770A OT
157 N1021Z 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR30 OT
158 H4420T 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ GK35X40X26.8XS OT
159 H4356A 3
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2525DU OT
160 H4349A 1
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2015DU OT
161 H4346A 2
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1815DU OT
162 N1019H 2
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU AN04 OT
164 S31207 2 SW, PHOTOELECTRIC SW 光電 EE-SX771A OT
165 K1001T 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ LAD-20C-4X6 OT
174 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
182 H4193T 4 BEARING ﾍﾞｱﾘﾝｸﾞ 6305ZZ OT
183 DCPA0470 4 SEAL ｼｰﾙ FE
187 WPA1300 3 KEY ｷｰ FE
188 WPA0351 1 WASHER ﾜｯｼｬ FE
189 WPA1642 1 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板 FE
190 WPA1650 1 SCREW ﾈｼﾞ OT
191 WPA1681 1 BKT BKT FE
192 WPA1732 1 GUIDE ｶﾞｲﾄﾞ FE
194 WPA1771 2 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板 FE
195 WPA1750 1 PLATE ﾌﾟﾚｰﾄ FE
196 WPA1740 1 PLATE ﾌﾟﾚｰﾄ FE
198 S31970 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-A501 OT
199 S31971 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-Z01 OT
202 DCPA1090 1 SCALE ﾒﾓﾘ AL
205 DCPA0172 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ OT
209 H52680 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M02.5X015L FE
210 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M FE
219 DCPA0850 1 BKT BKT FE
CP-733E,CP-732E PARTS LIST
24 - 5
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
220 DCPA1250 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
221 DCPA1650 1 BKT BKT FE
222 DCPA1660 1 HANDLE ﾊﾝﾄﾞﾙ OT
223 DCPA1670 1 BKT BKT FE
224 SAM6452 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
225 SAM6503 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
227 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
228 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
229 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
232 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
233 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
234 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
235 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
237 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
238 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
239 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
240 H5307A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X40L FE
241 H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X10L FE
242 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L FE
243 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
244 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
245 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L FE
246 H5340A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X15L FE
247 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X20L FE
248 H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L FE
249 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X30L FE
250 H5344A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X35L FE
251 H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X40L FE
252 H5360A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X25L FE
253 H5364A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X45L FE
255 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
256 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
257 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
258 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
259 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
260 W1026A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
261 W1029A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M FE
262 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
264 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8 FE
265 W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10 FE
CP-733E,CP-732E PARTS LIST
24 - 6
