26.2.ｶﾊﾞｰ前部(733E)(DCPZ) 26.2.Cover front(733E)(DCPZ) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 54 T5012Y 2 HANDLE 取手 THA-255(3202) OT 55 S3193K 4 SW, LIMIT SW ﾘ…
26.2.ｶﾊﾞｰ前部(733E)(DCPZ)
26.2.Cover front(733E)(DCPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADCPZ8111 1 PLATE ﾌﾟﾚｰﾄ OT
3 ADCPZ8040 1 PLATE ﾌﾟﾚｰﾄ OT
4 ADCPZ8050 1 PLATE ﾌﾟﾚｰﾄ OT
6 DCPZ1011 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
7 DCPZ1100 2 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
8 DCPZ1080 1 COVER, OPENING ｶﾊﾞｰ 開き FE
9 DCPZ1090 1 COVER, OPENING ｶﾊﾞｰ 開き FE
10 DCPZ1250 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
11 DCPZ1280 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
12 DCPZ1290 3 BKT BKT FE
13 DCPZ1110 1 FRAME ﾌﾚｰﾑ FE
14 DCPZ1120 1 FRAME ﾌﾚｰﾑ FE
15 DCPZ1030 1 BKT, COVER BKT ｶﾊﾞｰ OT
17 DCPZ1331 1 BKT BKT FE
18 DCPZ1490 1 BKT BKT 733E FE
19 DCPZ1310 2 GUIDE ｶﾞｲﾄﾞ FE
21 DCPZ1320 1 BKT BKT 733E FE
22 DCPZ1400 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
23 DCPZ1410 3 PLATE, SW ﾌﾟﾚｰﾄ SW FE
24 DCPZ1540 1 BKT, COVER BKT ｶﾊﾞｰ 733E FE
25 DCPZ1041 1 BKT, COVER BKT ｶﾊﾞｰ OT
27 DCPZ1480 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
28 DCPZ1240 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
29 DCPZ1450 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
30 DCPZ1460 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
42 DCPZ1300 2 BKT, COVER BKT ｶﾊﾞｰ FE
43 DCPZ1380 2 STOPPER ｽﾄｯﾊﾟ FE
44 DCPZ1390 1 STOPPER ｽﾄｯﾊﾟ FE
45 DCPZ1270 2 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
46 DCPZ1260 2 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
47 DCPZ1441 1 COVER 蓋 FE
48 DCPZ1370 5 STOPPER ｽﾄｯﾊﾟ FE
49 DCPZ1351 2 BKT, PIVOT BKT 支点 FE
50 DCPZ1360 4 BOLT ﾎﾞﾙﾄ FE
51 T10683 2 DAMPER ﾀﾞﾝﾊﾟ TM150-100-20-C OT
52 MPZ1411 12 HINGE 蝶番 FE
53 M1012B 2
MAGNET CATCH
ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-272(NO.2) OT
CP-733E,CP-732E PARTS LIST
26 - 6
26.2.ｶﾊﾞｰ前部(733E)(DCPZ)
26.2.Cover front(733E)(DCPZ)
26.2.ｶﾊﾞｰ前部(733E)(DCPZ)
26.2.Cover front(733E)(DCPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
54 T5012Y 2
HANDLE
取手
THA-255(3202) OT
55 S3193K 4 SW, LIMIT SW ﾘﾐｯﾄ D4DL-1DFG-B OT
56 S3193R 1 SW, LIMIT SW ﾘﾐｯﾄ D4DS-K2 OT
57 S3193S 3 SW, LIMIT SW ﾘﾐｯﾄ D4DS-K3 OT
58 A1004D 6 LEG, RUBBER 脚 ｺﾞﾑ TK-10(ｱｲﾎﾞﾘｰ) OT
59 A1004N 2
LEG, RUBBER
脚 ｺﾞﾑ
TK-20 OT
60 DCPZ1420 1 BKT BKT FE
61 DCPZ1430 1 BKT BKT FE
64 DCAC0010 1 ANGLE REST ｲｹｰﾙ FE
67 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L FE
68 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
69 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L FE
70 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
71 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
72 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
73 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L FE
74 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
75 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
76 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
77 H5301A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L FE
78 H5319H
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X8L FE
79 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L FE
80 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
81 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
82 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
83 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
84 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
85 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
86 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
87 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
88 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
89 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
90 W1040A WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7 FE
91 W1050A WASHER, FLAT ﾜｯｼｬ 平 5M/MX1.0X10(1W-5) FE
92 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/MX1.6X17(1W-8) FE
93 N1083A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8 FE
94 N1089A
NUT, HEX
ﾅｯﾄ 六角
M8 P=1.25 FE
CP-733E,CP-732E PARTS LIST
26 - 7
26.2.ｶﾊﾞｰ前部(733E)(DCPZ)
26.2.Cover front(733E)(DCPZ)
26.2.ｶﾊﾞｰ前部(733E)(DCPZ)
26.2.Cover front(733E)(DCPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
100 T5006B 2 HANDLE 取手 THA-240 OT
101 K5359A 2
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ六角穴皿 M4X6L FE
102 W1011A 6 WASHER, CONICAL ﾜｯｼｬ皿 M-4-L FE
103 A1004T 2 LEG, RUBBER 脚 ｺﾞﾑ TK-20(ｱｲﾎﾞﾘｰ) OT
104 ADCPZ8121 1 COVER ｶﾊﾞｰ OT
105 DCPZ1550 1 BKT BKT 733E FE .
CP-733E,CP-732E PARTS LIST
26 - 8
