28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADCAF8031 1 DOOR 扉 OT
2 ADCAF8041 1 DOOR 扉 OT
3 ADCAF8011 1 DOOR 扉 OT
4 ADCAF8021 1 DOOR 扉 OT
9 WWM0210 1 SEAL ｼｰﾙ PL
10 DCAF2060 1 BKT BKT XNo.279∼ AL
11 DCAF2070 1 BKT BKT XNo.279∼ AL
12 ADCAF8240 1 COVER 蓋 XNo.279∼ OT
13 ADCAF8280 1 COVER 蓋 XNo.279∼ OT
14 DCAF2150 1 COVER 蓋 XNo.279∼ FE
15 DCAF1380 1 PACKING ﾊﾟｯｷﾝ XNo.279∼ OT
16 DCAF1390 1 PACKING ﾊﾟｯｷﾝ XNo.279∼ OT
17 DCAF0010 1 FRAME ﾌﾚｰﾑ FE
18 DCAF0861 1 FRAME ﾌﾚｰﾑ FE
19 DCAF0050 1 FRAME ﾌﾚｰﾑ FE
20 DCAF0871 1 FRAME ﾌﾚｰﾑ FE
21 DCAF0030 1 COVER ｶﾊﾞｰ FE
22 DCAF2130 1 COVER ｶﾊﾞｰ FE
23 DCAF0070 1 COVER ｶﾊﾞｰ FE
24 DCAF2140 1 COVER ｶﾊﾞｰ FE
25 DCAF0120 1 COVER ｶﾊﾞｰ FE
26 ADCAF8060 1 PLATE ﾌﾟﾚｰﾄ OT
27 DCAF0311 1 JOINT ｼﾞｮｲﾝﾄ FE
28 DCAF0330 2 JOINT ｼﾞｮｲﾝﾄ FE
29 DCAF0321 1 JOINT ｼﾞｮｲﾝﾄ FE
30 DCAF0340 4 PLATE ﾌﾟﾚｰﾄ FE
31 DCAF0380 2 SPACER ｽﾍﾟｰｻ FE
32 DCAF0100 1 COVER ｶﾊﾞｰ FE
33 DCAF0110 1 COVER ｶﾊﾞｰ FE
34 DCAF0611 4 BOLT ﾎﾞﾙﾄ FE
35 DCAF0471 1 PLATE ﾌﾟﾚｰﾄ AL
36 DCAF0490 1 PLATE ﾌﾟﾚｰﾄ AL
37 DCAF0510 1 PLATE ﾌﾟﾚｰﾄ AL
38 DCAF0530 1 PLATE ﾌﾟﾚｰﾄ AL
39 DCAF0481 1 PLATE ﾌﾟﾚｰﾄ AL
40 DCAF0500 1 PLATE ﾌﾟﾚｰﾄ AL
41 DCAF0520 1 PLATE ﾌﾟﾚｰﾄ AL
CP-733E,CP-732E PARTS LIST
28 - 3
28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
42 DCAF0540 1 PLATE ﾌﾟﾚｰﾄ AL
43 DCAF0260 4 SLIDER ｽﾗｲﾀﾞ OT
44 DCAF0210 1 BKT BKT FE
45 DCAF0640 1 BKT BKT FE
46 DCAF0650 2 BKT BKT FE
47 DCAF0660 2 BKT BKT FE
48 DCAF0550 2 BKT BKT FE
49 DCAF0170 2 FRAME ﾌﾚｰﾑ FE
50 DCAF0291 1 BKT BKT FE
51 DCAF0270 1 BKT BKT FE
52 DCAF0182 1 RAIL ﾚｰﾙ XNo.279∼ AL
53 DCAF0202 2 RAIL ﾚｰﾙ XNo.279∼ AL
54 DCAF0301 1 BKT BKT FE
55 DCAF0280 1 BKT BKT FE
56 DCAF0192 1 RAIL ﾚｰﾙ XNo.279∼ AL
57 DCAF0230 1 BKT BKT FE
58 DCAF0240 1 BKT BKT FE
59 DCAF0630 20 BKT BKT FE
60 DCAF2120 1 BKT BKT XNo.279∼ FE
61 DCAF0410 2 BKT BKT FE
62 DCAF0400 2 BKT BKT FE
63 DCAF0420 1 BKT, SW BKT SW FE
64 DCAF0430 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
65 DCAF0450 1 BKT, SW BKT SW FE
66 DCAF0460 1 BKT BKT FE
67 DCAF0440 1 BKT BKT FE
68 DCAF0390 2 LOCATOR 当金 FE
69 ADCAF8071 2 BKT BKT XNo.279∼ OT
71 DCAF0250 4 SLIDER ｽﾗｲﾀﾞ OT
72 T5005T 4 HANDLE 取手 THA-132-3-3473 OT
73 M1010K 8 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-75-1181 OT
75 S3193K 4 SW, LIMIT SW ﾘﾐｯﾄ D4DL-1DFG-B OT
76 S3193N 4 SW, LIMIT SW ﾘﾐｯﾄ D4DS-K1 OT
77 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
78 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L FE
79 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
80 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
CP-733E,CP-732E PARTS LIST
28 - 4
28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
81 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
82 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
83 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L FE
84 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
85 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
86 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
87 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L FE
88 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L FE
89 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
90 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
91 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L FE
92 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
93 H5340A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X15L FE
94 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
95 W1021A
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
96 W1022A
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
97 W1023A
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
98 W1024A
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
99 W1025A
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
100 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
101 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
102 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
103 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
104 W1010A
ﾜｯｼｬ 皿         
M-3-L FE
105 W1011A
ﾜｯｼｬ 皿         
M-4-L FE
106 W1013A
ﾜｯｼｬ 皿         
M-6-H FE
107 K5213Z
小ﾈｼﾞ ﾄﾗｽ M05X005 ﾕﾆｸﾛﾒｯｷ FE
108 K5255H
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X5L FE
109 K5257A
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
110 K5257H
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X12L FE
111 K5261H
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X12L FE
112 K5261T
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X15L FE
113 N1080A
ﾅｯﾄ 六角         
M4 P=0.7 FE
114 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8 FE
115 ADCAF8050 1 PLATE ﾌﾟﾚｰﾄ OT
116 DCAF0220 1 BKT BKT FE
117 DCAF0840 2 COVER 蓋 XNo.249∼ FE
CP-733E,CP-732E PARTS LIST
28 - 5
28.ｶﾊﾞｰ(後面,側面,D軸)(DCAF)
28.Cover(Rear,Side,D axis)(DCAF)
