36.BKTｺﾈｸﾀ(DCWZ)
36.BKT connector(DCWZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DCWZ0201 1 PLATE ﾌﾟﾚｰﾄ FE
2 DCWZ0210 1 BKT BKT FE
3 CSWZ0090 4 BKT, RETAINER BKT 押え FE
4 DCWZ0221 1 BKT BKT FE
5 DCWZ0161 1 PLATE ﾌﾟﾚｰﾄ FE
6 DCWZ0170 1 BKT BKT FE
7 DCWZ0180 1 BKT BKT FE
8 DCWZ0190 1 RAIL ﾚｰﾙ OT
9 A5043T 2
RETAINER, RAIL
押え ﾚｰﾙ
PFP-M FE
10 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L FE
11 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
12 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L FE
13 H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X10L FE
14 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
15 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
16 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
17 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
18 K5179H SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M4X5L FE
19 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
21 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
22 DCAC0200 1 BKT BKT FE
23 DCAC0151 1 BKT BKT FE
25 H5177A
BOLT, HEX
ﾎﾞﾙﾄ 六角 M5X15L FE
26 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
27 H3012Z 1 FAN ﾌｧﾝ 109P1224H402 OT
28 K1141K 2 GUARD, FIN ｶﾞｰﾄﾞﾌｲﾝ 109-019E OT
29 K5191A SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M4X12L FE
30 W10024 WASHER ﾜｯｼｬ TL-182-2 FE
31 W1041A WASHER, CONICAL ﾜｯｼｬ 平 1W-4 FE
32 H5170A
BOLT, HEX
ﾎﾞﾙﾄ 六角 M4X12L FE
33 DCAC0190 1 BKT BKT FE
34 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M04X012 FE
35 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M05X015 HRC34-44 FE
36 DCWZ0050 1 BKT BKT FE
37 DCAF0550 1 BKT BKT FE
38 DCWZ0040 1 BKT BKT FE .
CP-733E,CP-732E PARTS LIST
36 - 2
36.BKTｺﾈｸﾀ(DCWZ)
36.BKT connector(DCWZ)
Ref.33-7
0.5 1 2 10
A
?
?
x10
6
2
5
5
4
3
33
32
10
33
32
10
12
11
9
17
14
15
17
14
15
18
14
15
24
19
24
20
25
23
22
24
21
1
31
2
4
9
24
20
25
23
22
13
29
28
30
23
27
26
26
27
23
22
21
48
49
50
51
46
52
H5177A 5X15
W1023A 5M/M
W1022A 4M/M
W1022A 4M/M
H5286A 4X6
H5286A 4X6
109-019Eｶﾞｰﾄﾞﾌｨﾝ
109P1224H402ﾓｰﾀﾌｧﾝ
31
DCWZに載っているので載せない
37 - 1
37.イケール(DCAC)
37.ANGLE REST(DCAC)
37.イケール(DCAC)
37.ANGLE REST(DCAC)
CP-733E,CP-732E PARTS LIST
37.ｲｹｰﾙ(DGAC)
37.ANGLE REST(DGAC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DCAC0010 1 ANGLE REST ｲｹｰﾙ FE
2 DCAC0091 2 PLATE ﾌﾟﾚｰﾄ FE
3 DCAC0081 1 COVER ｶﾊﾞｰ FE
4 DCAC0101 2 MIRROR ﾐﾗｰ FE
5 DCAC0120 2 SEAL ｼｰﾙ PL
6 DCAC0070 1 COVER ｶﾊﾞｰ FE
9 DCAC0130 2 BKT BKT FE
10 DCAC0020 2 SPACER ｽﾍﾟｰｻ FE
11 DCAC0030 1 COVER ｶﾊﾞｰ FE
12 DCAC0050 1 COVER ｶﾊﾞｰ FE
13 DCAC0161 1 PLATE ﾌﾟﾚｰﾄ FE
14 W1029A 26
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 16M/M FE
15 W1058T 26 WASHER, FLAT ﾜｯｼｬ 平 16M/MX3.0X28 FE
17 H5418A 18
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M16X60 FE
18 H5417A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M16X55 FE
19 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
20 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
21 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
22 K52565
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L FE
23 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
24 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
25 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
26 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
27 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
28 K5357H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M03X005 FE
29 DCAC0171 1 PLATE ﾌﾟﾚｰﾄ FE
30 DCAC0180 1 PLATE ﾌﾟﾚｰﾄ FE
31 K5215C
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M05X012 FE
32 H5343A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M08X030 FE
33 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE .
CP-733E,CP-732E PARTS LIST
37 - 2
37.ｲｹｰﾙ(DGAC)
37.ANGLE REST(DGAC)
