4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC) 4.1.Out conveyor(DCQC) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 128 DCQC0320 2 BELT ﾍﾞﾙﾄ PL 129 DCQC0331 2 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ OT 132 DCQ…
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
69 MQC3313 1 GUIDE, CONVEYOR ｶﾞｲﾄﾞ ｺﾝﾍﾞｱ FE
70 MQC3323 1 GUIDE, CONVEYOR ｶﾞｲﾄﾞ ｺﾝﾍﾞｱ FE
71 GVC0141 2 COLLAR ｶﾗｰ FE
72 GVC0320 2 COLLAR ｶﾗｰ FE
73 GVC0350 3 COLLAR ｶﾗｰ FE
74 GVC2262 1 SPROCKET ｽﾌﾟﾛｹｯﾄ FE
75 CLC9031 1 BKT BKT FE
76 CLC9051 2 HOLDER ﾎﾙﾀﾞ FE
77 CLN8690 2 SPROCKET ｽﾌﾟﾛｹｯﾄ FE
78 IQC6041 2 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
79 M5063H 1 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6AO6ZMR244 OT
80 H4001T 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1 OT
81 DCQC3550 1 SW, PHOTOELECTRIC SW 光電 OT
84 S3034A 3 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T2-Type OT
85 H4445A 6
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ OT
86 S1022A 3
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4 OT
87 T2037E 1 CHAIN ﾁｪｰﾝ RS25NP 355LINK OT
88 T20241 1 CHAIN ﾁｪｰﾝ RS25NP 161LINK OT
89 T20100 1 CHAIN ﾁｪｰﾝ RS25NP 48LINK OT
90 N1014A 2
NUT, FINE U
ﾅｯﾄ ﾌｧｲﾝU AN00 OT
91 H4440A 4
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ OT
92 H4123A 2
BEARING
ﾍﾞｱﾘﾝｸﾞ UFL000 OT
94 H4451A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ OT
96 W10022 2 WASHER ﾜｯｼｬ TL182(NO2) OT
97 S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T1-Type OT
99 K5337G 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-04(ｼﾛ) OT
100 Y3044A 2
UNION
ﾕﾆｵﾝ M-5E OT
101 Y3061E 2
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5(ｼﾛ) OT
107 Y3066X 2
UNION
ﾕﾆｵﾝ KQ2E06-01 OT
108 K50764 2 CONNECTOR ｺﾈｸﾀ KQ2U06-01S OT
113 H5296H
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X55L FE
114 DCQC3200 1 BKT BKT FE
115 DCQC3211 1 PLATE ﾌﾟﾚｰﾄ FE
116 DCQC3221 1 PLATE ﾌﾟﾚｰﾄ FE
117 DCQC3240 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
118 DCQC3230 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
119 M5063K 1 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6A6ZMR428 OT
CP-733E,CP-732E PARTS LIST
4 - 4
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
128 DCQC0320 2 BELT ﾍﾞﾙﾄ PL
129 DCQC0331 2 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ OT
132 DCQC0410 2 BKT BKT FE
135 DCQC0270 2 SHAFT ｼｬﾌﾄ OT
141 DCQC0710 1 STOPPER ｽﾄｯﾊﾟ FE
142 DCQC0720 1 STOPPER ｽﾄｯﾊﾟ FE
143 DCQC0630 2 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ FE
152 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
154 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
159 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
160 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
161 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
162 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
164 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
165 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L FE
166 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
167 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L FE
168 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X20L FE
170 .
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M06X022 FE
171 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
172 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
173 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
174 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
176 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
177 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
179 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
180 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
182 K5359H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M4X10L FE
183 N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X5L FE
187 K52564
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X5L FE
188 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L FE
189 K5261H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X12L FE
191 N1082A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8 FE
192 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 FE
196 . SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X12L FE
197 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
198 DCQC3531 1 BKT BKT FE
CP-733E,CP-732E PARTS LIST
4 - 5
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
203 H5332A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X50L FE
204 H5329A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X35L FE
205 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L . FE .
CP-733E,CP-732E PARTS LIST
4 - 6
4.1.ｱｳﾄｺﾝﾍﾞｱ(DCQC)
4.1.Out conveyor(DCQC)
