V4 Maintenance Parts List 1.Base unit NO. CODE PARTS NAME REMARK 1 LC5-M11A0-000 AIR,ASSY 2 LC5-M11K4-001 PRESSURE GAUGE ASSY. AIR PRESSURE SENSOR 3 LC2-M1118-010 AIR SET 4 KG7-M8503-000 MODULE ADAPTER 5 KH5-M8501-000 EX…
MAINTENANCE PARTS LIST
LC5-1004 (MPL)
V4 Maintenance Parts List
1.Base unit
NO. CODE PARTS NAME REMARK
1 LC5-M11A0-000 AIR,ASSY
2 LC5-M11K4-001 PRESSURE GAUGE ASSY. AIR PRESSURE SENSOR
3 LC2-M1118-010 AIR SET
4 KG7-M8503-000 MODULE ADAPTER
5 KH5-M8501-000 EXHAUST VALVE 300V-03(KOGANEI)
6 LC4-M11A3-000 REGULATOR ARJ310F-01BG-06-1(SMC)
11 LC4-M23K3-010 SENSOR ASSY. VAC LEVEL SENSOR
12 LC5-M23A4-000 REGULATOR VRA2000-8(CKD)
B:20100416
A
2
1
3
4
5
6
11
12
1.Base unit
