DECAN_F2_S2_TRM(Ver7.4_CS20.12) - 第175页
Page +$1:+$ 171 DECAN F2/S2
Page
+$1:+$
170
DECAN
F2/S2
Y Frame Duct
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
24 FC15-002060D COVER-COVER DRIVER Y;STD 1 #338 ~
25 FC09-007265A BRACKET-AXIS B PROTECT UPPER BKT 1 #338 ~
26 AM06-000943B ASSY,PCB-AXIS_IO_BOARD 1 #338 ~
27 FC09-006580B BRACKET-AXIO BOARD CONNECTOR PROTECT B 1 #338 ~
28 FC09-003419C BRACKET-BKT AXIS B 1 #338 ~
29 FC09-007544A BRACKET-FAN FLOW GUIDE 1 #338 ~
30 FC09-007545C BRACKET-FAN BASE BKT-C 1 #338 ~
31 HP04-001032 FILTER,AIR 1 #338 ~
Page
+$1:+$
171
DECAN
F2/S2
Page
+$1:+$
172
DECAN
F2/S2
Y Frame
