Page SAMSUNG TECHWIN 161 SM168 Articles of Consumption NO. Lev . P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Referen ce A-1 J9055354A N OZZLE ASSY[J9055354A] 1 1 J9055134C N OZZLE CN040 ASSY[J9055134C] 6 Onl…
Page
SAMSUNG TECHWIN
160
SM168
Articles of Consumption
Page
SAMSUNG TECHWIN
161
SM168
Articles of Consumption
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A-1 J9055354A NOZZLE ASSY[J9055354A]
1
1
J9055134C NOZZLE CN040 ASSY[J9055134C]
6
Only Indication
2
J9055136C NOZZLE CN065 ASSY[J9055136C]
6
Only Indication
3
J9055256A NOZZLE CN140 ASSY[J9055256A]
2
Only Indication
4
J9055351A NOZZLE CN220 ASSY(CERAMIC)[J9055351A]
2
J9055257A Only Indication
5
J9068024A CALIBRATION PLATE[J9068024A]
1
Only Indication
A-2
J90641038A SM421_PACKING_BOX_ASSY J90641038A
1
Only Indication
6 J3601018A FUSE[250V 5A] 2
Only Indication
7 J3601019A FUSE[250V 10A] 2
Only Indication
8 J7055140A STEEL BALL [DIA2, SUS304] 20
Only Indication
9 J72550021C SILICON TUBE(BLACK) J72550021C 6 J7255076A /J7255021B
Consumables (Replacement: 6 months)
10 J67081017A SUCTION_FILTER VYF44-M-50M 6
Only Indication
11 J7500003B BACK UP PIN[J7500003B] 6
Only Indication
12 J8001072A STICKER REMOVER SPRAY [450ML] 1
Only Indication
13 J8001073A TRI-FLOW [59ML] 1
Only Indication
14 J81000118C CLEANING KIT 1
Only Indication
15 J9064035B TOOL SET [J9064035B] 1
Only Indication
16 J8001065A DRIVER (+,-) [KL 207(6), 150mm] 1
Only Indication
17 J5104001A CD-R (RECORDABLE) [MMI BACKUP CD] 1
Only Indication
18 J9055249A LIGHT MAPPING TOOL ASSY[J9055249A] 1
Only Indication
19 J9055250A LIGHT MAPPING TOOL ASSY[J9055250A] 1
Only Indication
20 J67020048B SOLENOID VALVE VA01PEP34A-1U-F 6 J6702048A
Consumables (Replacement: 2 years)
21 J6702049A SOLENOID VALVE[RCS242-M3-D24NP] 1
Consumables (Replacement: 2 years)
22 J7459062A CALIBRATION NOZZLE[J7459062A]
