Page
SAMSUNG TECHWIN
157
SM168
Vision IF B/D(1/2)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-005545A CABLE ASSY-HEAD2 FIDUCIAL CAMERA1 1 SM471_VIS003-1
2 J90831375B FLAT_FIDUCIAL_CAM_CABLE_ASSY 1 SM41_VIS005
3 AM03-006968A CABLE ASSY-FIX1-2_CAMERA 1 SM48_VIS002
4 AM03-005556A CABLE ASSY-VISION IF BD POWER 1 SM471_VIS000
5 AM03-006985A CABLE ASSY-NEXTEYE B/D I/F_MAGA 1 SM48_VIS012-1
Page
SAMSUNG TECHWIN
158
SM168
Vision IF B/D(2/2)
1 2
3 4
