AIR Ass’y(5/5)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 J6701088A
CYLINDER[CM2C32-50]
2
2
J6711028A ELBOW FITTING KQ2L04-01/SQL04-01S-W
2
3
J6703028A SPEED CONTROLLER [SS4-M5MA]
4
4 J6701018B
STOPPER CYLINDER 1 [WTS10*30-RS2
2
5 J1301188 FITTING [KQ2L04-M5/PL4-M5M/SQL04-M5] 2
6 J1301354 THROTTLE VALVE STRAIGHT [AS1201F-M5-04- 2
7 J9080778B ANC SENSOR CABLE ASSY[SM-CV010] 2
8 HP14-000398 VALVE,THROTTLE-GRLA-E-M5-QS-4C 2
9 HP06-000275 FITTING-DIN 908-G1/8-ST;Plug,Thread 2
10 J67031002A DOUBLE_SPEED_CONTROLLER ASD230F-M5-04 2
11 HP14-000397 VALVE,SOLENOID-VUVG-S10-M52-RT-M5-1H2L 2
12 HP15-000010 ACCESSORY,VALVE-VABB-L1-10-S 1
13 HP06-000279 FITTING-QS-E-1./8-8-C;STRAIGHT FITTING 2
14 HP09-000164 SILENCER-U-E-1/8-S 2
15 AM03-007232A ASSY,AIR-SM482_SOL_VALVE_MODULE 1
16 HP09-000156 ACCESSORY,PNEUMATICS-B-M5-B 1
17 AM03-007338A ASSY,AIR-SOL_VALVE_EDGE_FIX-OPTION 1
