User Manual SIPLACE CF 1 Introduction
Software version SR.101.xx 06/2003 US Edition 1.4 Liability of the manufacturer/supplier
17
1.4 Liability of the manufacturer/supplier
We draw your attention to the fact that this user manual only contains descriptive and explanatory
material and does not include any contractual conditions or undertakings. All obligations of Sie-
mens Dematic AG proceed from the conclusion of the contract concerned, under which you have
the machine described herein. This applies in particular to all statements regarding performance
or service life and the agreed liability for faults or defects. The provisions of the contract regarding
the liability for faults or defect are neither extended nor restricted by any statements in this user
manual.. 1
1.5 EU-Declaration of Conformity
The product/device described below 1
product: Automatic Placement SystemSIPLACE CF
item no.: 374500 1
manufactured by 1
SIEMENSDEMATIC AG
Electronics Assembly Systems
Rupert-Mayer-Str. 44
D-81359 Munich 1
conforms to the relevant provisions of: 1
– Directive 98/37/EC of the European Parliament and of the Council of June 22, 1998 on the
approximation of the laws of the Member States relating to machinery
– Council Directive 89/336/EEC of May 3, 1989 on the approximation of the laws of the Mem-
ber States relating to electromagnetic compatibility
The product(s) identified above comply with the requirements of the above EU directive by meet-
ing the following standards: 1
EN 292-1, EN 292-2, EN 294, EN 349, EN 418, EN 811, EN 60204-1, EN 60825-1
BGV A1
1
, BGV A2
1)
, VBG 5
1)
, EN 61000-3-2/3, EN 61000-4-2/3/4/5/6/8 1
1. National specifications
This declaration certifies the compliance with the indicated directives but implies no warranty of properties.
The safety instructions of the accompanying product documentation shall be observed.
1 Introduction User Manual SIPLACE CF
1.6 Revision index Software version SR.101.xx 06/2003 US Edition
18
1.6 Revision index
1
1
1
1.7 Abbreviations
1
1
1
Manual
Software
version
Edition
First edition User Manual SR.101.xx 06/2003 US
CO 1 Component 1
C&P 1 Collect&Place 1
C&P6 1 Collect&Place head with 6 segments 1
DCA 1 Direct Chip Attach 1
FC 1 Flip chip 1
WT 1 Waffle-pack tray 1
WPTC 1 Waffle-pack tray carrier 1
GND 1 Ground 1
IC 1 Integrated circuit 1
PCB 1 Printed circuit board 1
P&P 1 Pick&Place 1
WPC 1 Waffle-pack changer 1
User Manual SIPLACE CF 2 Operational safety
Software version SR.101.xx 06/2003 US Edition 2.1 Safety instructions
19
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This User Manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
2
DANGER or
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment will occur if the danger instructions are not followed.
2
WARNING or
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the warning instructions are not followed.
2
CAUTION or
as used in this User Manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed.
NOTE
as used in this User Manual provides information on the product or indicates a part of the User
Manual that requires particular attention.
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting
up, operation and preventive maintenance of automatic placement systems and add-on devices
and are suitably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-
trical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
