2 Operational safety User Manual SIPLACE CF
2.2 Warning labels Software version SR.101.xx 06/2003 US Edition
36
2.2.6 Warning label "Danger of crushing" on the component trolley
2
Warning label "Danger of Crushing" (number per component trolley: 2)
2
Fig. 2.2 - 11 Warning label Danger of crushing on the component trolley
2
Warning label Danger of crushing, part no. 00343357-01
2
2
2
WARNING DANGER OF CRUSHING!
Do not place your hands in the danger area
when lowering the component feeder table.
DANGER OF CRUSHING!
User Manual SIPLACE CF 2 Operational safety
Software version SR.101.xx 06/2003 US Edition 2.2 Warning labels
37
2.2.7 Warning labels on the waffle-pack changer
2
Fig. 2.2 - 12 Warning labels on the waffle-pack changer
2
Warning label WPC 80F, part no. 00321262-02 (number per WPC: 1)
WARNING!
Remove IC vision illumination unit before
docking or undocking the machine!
> DANGER OF A CRASH <
Move the waffle-pack changer only over flat and
level floors!
The waffle-pack storage unit must be in its
LOWEST POSITION before transportation!
> DANGER OF OVERTURNING! <
2 Operational safety User Manual SIPLACE CF
2.3 Laser classification Software version SR.101.xx 06/2003 US Edition
38
2
Warning label W110 (number per WPC: 4)
2.3 Laser classification
2.3.1 Laser class 1
2.3.1.1 Classification of the whole machine
2
PLEASE NOTE: 2
Modules in laser classes 1 and 1M are not identified.
2.3.2 Laser class 1M
Do not look directly at this with optical instruments!
2
2
2
2
DANGEROUS VOLTAGES!
The identified parts are under mains voltage. Disconnect the ma-
chine from the main power supply before servicing it!
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
2
All installed camera systems and the whole machine when ready for oper-
ation are assigned to laser class 1.
The laser classes are determined according to DIN EN 60825-1:2001.
2
The following camera systems are assigned to laser class 1M:
24 x 24 component camera on the 6-segment Collect&Place head
IC camera for the Pick&Place head
