3.6.2 Description
All the controls can be reached by a 1.60 m tall person.
Main power switch
The main power switch is used to switch the power supply to the placement machine on and off.
RISK OF DEATH
Some parts inside the placement system carry potentially lethal voltages - even when switched
off at the main switch. 3
Key switch
In normal mode, the key switch is set to "0". The key should be removed and kept in a safe place.
It must only be turned to position "I" (set-up mode) by authorized personnel, and then only for
certain maintenance and servicing work.
Stop button
This button is used to stop the placement machine.
Start button
This button starts the placement machine after it has been switched on or after faults have been
eliminated.
Emergency stop button
The emergency stop button latches in the ON position when pressed. The power supply to the
gantry axes, the components changeover tables, conveyors, and used tape cutters is interrupted
and the voltage supplied to the star axes of the placement heads is reduced. Turn the button to
release it.
Component counter
The component counter displays the number of components processed.
Station computer, monitor and keyboard
The monitor and keyboard are mounted on a rotatable bracket. The station computer is a desk-
top model. It has a Pentium processor and runs the WINDOWS XP operating system. The
SIPLACE graphical user interface, which is based on the Windows standard, is used to operate
and monitor the placement system. A 15" color monitor with a resolution of 1024 x 768 pixels
User Manual SIPLACE CF 3 Technical data
Software version SR.101.xx 06/2003 US Edition 3.6 Controls
83
provides the screen display. The ultra-flat IBM-compatible PC keyboard incorporates a trackball
for controlling the mouse.
Indicator lamps
The sequence of colors is white - green - white. It signals operating statuses and malfunctions of
the placement machine (see chapter 5
).
Component barcode reader
The Datalogic DL910 component barcode reader is attached to a bracket on the output side of
the machine. It enables the components to be set up and topped up quickly and reliably.
3.6.3 Ergonomic arrangement of the controls
Figure 3.6 - 1 on page 80 provides an overview of the position of the controls. They are subdi-
vided into the following groups:
Operating panel on the PCB input side with
– start button
– stop button
– emergency stop button
– main power switch
Operating panel on the PCB output side with
– emergency stop button
– start button
– stop button
– component counter
– key-operated switch
– component barcode reader
Pivoting bracket with
– monitor and
– keyboard
3 Technical data User Manual SIPLACE CF
3.6 Controls Software version SR.101.xx 06/2003 US Edition
84
3.6.3.1 Controls on the input and output sides of the placement machine
Emergency stop button, Start and Stop buttons
There is an emergency stop button, a Start button and a Stop button on both the input and output
sides of the PCB conveyor. This arrangement was adopted for the emergency stop buttons
because it enables them to be reached quickly and easily from any position.
In addition, it is important to have an unrestricted view of the placement heads and placement
area during preventive maintenance, servicing and setting up work in order to be able to check
all the operations carried out inside the machine. This particularly important during testing
phases or when starting single functions, for example.
Key switch
The key switch is located on the operating panel on the PCB output belt. It is only needed for set-
ting up and servicing work so, for reasons of efficiency, it is positioned near the Start and Stop
buttons.
Main power switch
The main switch is part of the power supply unit, so it is positioned on the left-hand side of the
PCB input belt. It is located here because it is only needed for switching the placement system
on or off and is therefore not subject to frequent use.
3.6.3.2 Controls on the placement system console
Monitor and keyboard
The station computer, monitor and keyboard are all mounted on the console. They are arranged
so that any person who is at least 1.60 m tall can work comfortably and efficiently.
Component barcode reader
The two component trolleys for supplying components are arranged on the right and left of the
placement system. For this reason, the component barcode reader was arranged on the PCB
output side so that all the barcode labels are equally accessible. It enables the operators to work
comfortably and efficiently during the component set-up and filling checks.
