KW1-M1 1 10-01 1 Continued on Page 12-4,12-5 KW1-M1 12A-000 K87-M1 12L-100 KW1-M1 120-000 No. Part No. Part Name Q'ty Remarks KW1-M1 1 10-01 1 Body Assy 1 K87-M1 12L-100 Sprocket Axis Assy 1 KW1-M1 12A-000 Racking L…

100%1 / 88
S027-M0489-20
CL-82-0402
No. Part No. Part Name Q'ty Remarks
S027-M0489-20 CL-8-7 Reel Holder Unit 1
1 1
2 1
3 1
4 1
5 KW1-M111S-000 Screw,Flat Head+ 1
6
K87-M111S-000 Screw,Flat Head+
2
7
8
S027-M0489-Y0
Serial No.Sticker(STD) 1
9 S027-M0489-Y0 Serial No.Sticker(4P_T03) 1
10 S027-M0489-Y0 Serial No.Sticker(1005) 1
11 S027-M0489-Y0 Serial No.Sticker(0603) 1
12 S027-M0489-Y0 Serial No.Sticker(2P_T03) 1
13 S027-M0489-Y0 Serial No.Sticker(0402) 1
KW1-1107
11
6
REEL PLATE Assy(7in)
CLY-84
CL-84~82E{Pocket (D) type} 8mm-7inch
KW1-M1110-011
Continued on
Page 12-4,12-5
KW1-M112A-000
K87-M112L-100
KW1-M1120-000
No. Part No. Part Name Q'ty Remarks
KW1-M1110-011 Body Assy 1
K87-M112L-100 Sprocket Axis Assy 1
KW1-M112A-000 Racking Lever Assy 1
KW1-M1120-000 Sprocket Assy 1
1
2 KW1-M1112-000 Knock Pin (Front) 1 *Attention
3 KW1-M1113-000 Knock Pin (Rear) 1 *Attention
4
5
6
7
8 KW1-M111E-001 Spring 1
9
10
11 K87-M111H-200 Back Stopper 1
12 KW1-M111A-000 Spring 1
13 K87-M111B-000 Back Stopper Axis 1
14 K87-M111C-000 Plane Washer 1
15
16
17
18
19 K87-M112D-100 Coil Spring 1
20
21
22 K87-M111D-000 Push Pin 1
23 K87-M111F-100 Stopper Pin 1
24 K87-M111G-100 Push Pin 1
25 K87-M111P-000 Screw,Flat Head+ 1
26 K87-M111X-000 Screw,Set 1
27 K87-M111R-000 Screw,Set 5
28
29
K87-M1115-000 Circular Rivet
2
*Attention
KW1-0911
12
1
BODY & RACHET Unit CLY-84E
CL-84(D type) 8mm-4P(STD & EMBOSS)
*Attention: This parts need press t and training.
*Attention:
圧入部品のため修理依頼を推奨します。
KW1-M174S-000
KW1-M1740-020
KW1-M114A-000
No. Part No. Part Name Q'ty Remarks
KW1-M1740-020 TAPE GUIDE UNIT 1
KW1-M174S-000 TAPE GUIDE ASSY 1
KW1-M114A-000 HAND LEVER ASSY 1
1 KW1-M1177-000 MAIN ARM 1
2
3 KW1-M1343-010 SHUTTER PLATE 1 *Attention
4
KW1-M1144-010 SHUTTER GUIDE PIN
2 *Attention
5
KW1-M114N-000 GUIDE AXIS
1
6
KW1-M1345-010
LEAF SPRING 1
*Attention
7 KW1-M116K-000 LEVER AXIS 1
8
9
10
11
12 K87-M111C-000 PLANE WASHER 2
13
K87-M1181-000 ROD CONNECT 1
14
15
16
K87-M1184-000 CONNECT PIN
1
17
KW1-M1185-001
MULTI CYLINDER 1
18 KW1-M111L-001 BARB CONNECTOR STRAIGHT 2
19 K87-M111M-000 GASKET 2
20 KW1-M11B1-000 AIR HOSE(70mm) 1
21 K87-M111P-000 SCREW,FLAT HEAD+ 2 *Attention
22 K87-M11BF-000 SCREW,FLAT HEAD+ 2
23 KW1-M11B6-000 S.W.SCREW,CAPBOLT HEAD 2
24 K87-M11B9-000 CIRCLIP E 1
KW1-1107
12
2
TAPE GUIDE & AIR CYLINDER Assy
CLY-84E
CL&CLI-84E(D type) / CL&CLI-82E(A type) 8mm-EMBOSS
*Attention: This parts need thread locker and training.
*Attention:
接着部品のため修理依頼を推奨します。
