CP-643E-08 PART LIST - 第103页

R e f . 3 3 - 7 R e f . 3 1 - 1 R e f . 3 1 - 1 R e f . 3 1 - 1 R e f . 3 1 - 1 W W Z 0 2 3 3 K 5 0 4 9 N K 5 0 4 9 L 4 8 6 1 1 7 5 0 6 2 1 4 4 1 7 1 5 2 6 2 1 6 5 2 6 2 1 8 1 5 4 9 6 1 5 2 6 2 1 6 5 0 6 2 6 5 2 1 5 7 4 …

100%1 / 247
18.第16ｽﾃｰｼｮﾝ(NG部ﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部(CSPU,CSPK)
18.Station 16(Parts eject),Waste tape cutter(CSPU,CSPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
86 N1091A NUT, HEX ﾅｯﾄ 六角 M8-L FE
87 WPK0360 1 GUIDE ｶﾞｲﾄﾞ FE
88 WPK0171 1 GUIDE ｶﾞｲﾄﾞ FE
89 WPK0182 1 RETAINER, WIRING 押え 配線 FE
90 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
91 H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X20L FE
92 S3122A 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3CID OT
93 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
94 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
95 WPK0350 1 PLATE ﾌﾟﾚｰﾄ FE
96 K5188A SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M4X10L FE
97 CSAC0032 1 COVER ｶﾊﾞｰ FE
98 K5195A SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M5X10L FE
99 CSQC5740 1 BKT, CONVEYOR BKT ｺﾝﾍﾞｱ R→L(Option) FE
100 WPU0501 2 COLLAR ｶﾗｰ FE
101 WPU0510 1 PIN ﾋﾟﾝ FE
102 H44323 1 BEARING ﾍﾞｱﾘﾝｸﾞ L-1040ZZ FE
103 S1045A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW-E2.5 FE
104 WPU0404 2 SHAFT ｼｬﾌﾄ FE
105 WPU0436 1 PLATE ﾌﾟﾚｰﾄ FE
106 WPU0441 2 WASHER ﾜｯｼｬ FE
107 WPU0450 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
108 WPU0471 1 PLATE ﾌﾟﾚｰﾄ FE
109 H4287T 2 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ LMO5UU FE
110 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
111 N1076A NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 FE
112 K5339W 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1311F-M5-06（ｼﾛ） OT
113 WPH1330 1 HOSE, AIR ﾎｰｽｴｱｰ Specified part selection(3m) OT
114 WPH1340 1 HOSE, AIR ﾎｰｽｴｱｰ Specified part selection(3.5m) OT
115 K3016A 1
CLIPPER
ｸﾘｯﾊﾟ 3(ｶﾞｲｹｲ55ｶﾗ70ﾖｳ) OT
116 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
117 WPA0954 PIN, LOCATING ﾋﾟﾝ 位置決め . FE
CP-643E PARTS LIST
18 - 5
18.第16ｽﾃｰｼｮﾝ(NG部ﾊﾟｰﾂ排出),残ﾃｰﾌﾟｶｯﾄ部(CSPU,CSPK)
18.Station 16(Parts eject),Waste tape cutter(CSPU,CSPK)
Ref.33-7
Ref.31-1
Ref.31-1
Ref.31-1
Ref.31-1
WWZ0233
K5049N
K5049L
48
61
17
50
62
14
41
71
52
62
16
52
62
18
15
49
61
52
62
16
50
62
65
21
57
40
50
62
13
50
62
65
21
57
40
22
62
52
2
55
6
59
45
43
59
36
69
59
23
43
59
36
69
26
68
72
72
37
3
31
24
31
3
1
47
60
64
54
63
66
34
20
53
63
39
51
62
65
19
4
56
27
28
44
58
48
61
29
38
34
30
11
38
43
59
6
55
5
59
46
3
31
25
31
3
70
61
8
32
7
9
32
35
12
33
49
67
10
33
x9
19 - 1
19.第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)(CSPM)
19.Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
19.第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)(CSPM)
19.Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
CP-643E PARTS LIST
x9
19 - 2
19.第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)(CSPM)
19.Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
19.第17ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認),第18ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換),第19ｽﾃｰｼｮﾝ(ﾉｽﾞﾙ切換前確認)(CSPM)
19.Station 17(Nozzle pre change check),Station 18(Nozzle check),Station 19(Nozzle post change check)(CSPM)
CP-643E PARTS LIST
LOCTITE262
LOCTITE262
ThreeBond1373B
ThreeBond1390E
ThreeBond1373B
ThreeBond1390E
1.96N.m
3.9N.m
LOCTITE222
LOCTITE222
ThreeBond1373B
LOCTITE262
12.74N･m
