44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 CSQC1042 1 PLATE ﾌﾟﾚｰﾄ FE
2 CSQC0041 1 PLATE ﾌﾟﾚｰﾄ FE
3 CSQC0051 1 PLATE ﾌﾟﾚｰﾄ FE
4 CSQC1171 1 BRIDGE ﾌﾞﾘｯｼﾞ FE
7 CSQC0132 1 STOPPER ｽﾄｯﾊﾟ FE
8 CSQC0142 1 STOPPER ｽﾄｯﾊﾟ FE
9 CSQC0171 1 BKT, SENSOR BKT ｾﾝｻ FE
10 CSQC7431 1 BKT BKT FE
16 CSQC1200 3 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ FE
17 CSQC7460 2 HOLDER 受け FE
18 CSQC7452 1 COVER ｶﾊﾞｰ FE
19 CSQC7491 1 COVER ｶﾊﾞｰ FE
32 CSQC0511 1 COVER, BELT ｶﾊﾞｰ ﾍﾞﾙﾄ FE
42 CSQC0660 1 PLATE ﾌﾟﾚｰﾄ FE
43 CSQC0670 1 PLATE ﾌﾟﾚｰﾄ FE
44 CSQC0680 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ AL
45 CSQC0690 2 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ AL
46 CSQC0700 2 BELT ﾍﾞﾙﾄ OT
50 CSQC0741 1 NAMEPLATE 銘板 PL
51 CSQC1020 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ AL
52 CSQC1030 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ AL
62 MQC1061 4 PULLEY ﾌﾟｰﾘ OT
63 MQC1073 1 SEAL ｼｰﾙ PL
64 MQC1292 4 PULLEY ﾌﾟｰﾘ OT
65 MQC1300 1 SEAL ｼｰﾙ PL
66 MQC1430 2 BKT BKT FE
67 MQC3113 2 BALL SCREW ﾎﾞｰﾙﾈｼﾞ OT
68 MQC3293 2 COVER ｶﾊﾞｰ OT
69 MQC3313 1 GUIDE ｶﾞｲﾄﾞ FE
70 MQC3323 1 GUIDE ｶﾞｲﾄﾞ FE
71 CSQC1050 2 SHAFT ｼｬﾌﾄ FE
72 MQC3421 2 BKT BKT FE
74 MQC3451 1 HOLDER ﾎﾙﾀﾞ FE
75 MQC3461 1 SHAFT ｼｬﾌﾄ FE
76 MQC3501 2 PULLEY ﾌﾟｰﾘ FE
77 MQC3901 8 SPACER ｽﾍﾟｰｻ FE
78 MQC4130 2 SHAFT ｼｬﾌﾄ FE
79 CLC9051 2 HOLDER ﾎﾙﾀﾞ FE
80 GVC0141 2 COLLAR ｶﾗｰ FE
81 GVC0320 2 COLLAR ｶﾗｰ FE
82 GVC0350 4 COLLAR ｶﾗｰ FE
CP-643E PARTS LIST
44 - 2
44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
83 GVC2262 2 SPROCKET ｽﾌﾟﾛｹｯﾄ OT
84 GVC2311 1 SHAFT ｼｬﾌﾄ FE
85 GVC2320 1 SHAFT ｼｬﾌﾄ FE
87 CSQC1071 2 HOLDER ﾎﾙﾀﾞ FE
88 IQC6041 4 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
89 IQC6062 29 NUT ﾅｯﾄ FE
90 IQC6072 64 NUT ﾅｯﾄ FE
91 IQC6291 2 NUT ﾅｯﾄ FE
92 JQC3672 14 NUT, SQUARE ﾅｯﾄ 四角 FE
94 M5063H 2
MOTOR, INDUCTION
ﾓｰﾀ ｲﾝﾀﾞｸｼｮﾝ RM-H6A6ZMR244 OT
95 H4001T 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1 OT
96 H4429M 2
BEARING, BALL
ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK20UU FE
97 H4123A 1
BEARING
ﾍﾞｱﾘﾝｸﾞ UFL000 FE
98 H4445A 8 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ FE
99 H4451A 2 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ FE
100 H4440A 5 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ FE
101 T2030T 1 CHAIN ﾁｪｰﾝ RS25NP 266ﾘﾝｸ OT
102 T2022B 1 CHAIN ﾁｪｰﾝ RS25NP 68ﾘﾝｸ OT
103 S3033A 2 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 1ｶﾞﾀ OT
104 S3034A 5 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2ｶﾞﾀ OT
105 S1022A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4 FE
106 W10022 2 WASHER ﾜｯｼｬ TL182(No.2) FE
108 WQC4081 1 BKT BKT FE
109 CSQC1160 1 BRIDGE ﾌﾞﾘｯｼﾞ FE
110 S3141B 2 SW, PHOTOELECTRIC SW 光電 DL-S3R OT
122 IQC6301 8 NUT ﾅｯﾄ FE
123 WQC0111 1 BKT BKT FE
125 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
126 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
127 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
128 W1043A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-4 FE
129 W1044A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-5 FE
130 W1045A
WASHER, FLAT
ﾜｯｼｬ 平         
4W-6 FE
131 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L FE
132 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-6-H FE
136 N4015A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X4L FE
137 N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
138 N1080A
NUT, HEX
ﾅｯﾄ 六角 M4 P=0.7 FE
139 N1082A
NUT, HEX
ﾅｯﾄ 六角 M5 P=0.8 FE
140 N1085A
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
141 CSQC1230 8
NUT, HEX
ﾅｯﾄ 六角 FE
CP-643E PARTS LIST
44 - 3
44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
142 K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
144 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X10L FE
145 K5178T
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋 M3X12L FE
146 K5214A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X8L FE
149 K5359H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X10L FE
150 H5181A
BOLT, HEX
ﾎﾞﾙﾄ 六角穴 M6X12L FE
152 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
153 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
156 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X18L FE
158 H5296X
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X90L FE
159 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X10L FE
163 H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X10L FE
164 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
165 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L FE
166 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X18L FE
167 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X20L FE
168 H5330A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X40L FE
169 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M8X20L FE
170 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
171 CSQC1190 1 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ FE
172 CSQC1181 1 SPACER ｽﾍﾟｰｻ FE
173 CSQC1060 2 BLOCK ﾌﾞﾛｯｸ FE
175 H5309A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X50L FE
176 .
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M8X18L FE
177 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-8-H FE
178 CSQC1361 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
179 CSQC1371 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
180 CSQC1393 1 BKT BKT X-No.493∼ FE
181 CSQC1400 1 BKT, SENSOR BKT ｾﾝｻ FE
182 K52564 8 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X5L FE
183 CSQC1210 8 WASHER, SPHERICAL ﾜｯｼｬ 球面 FE
184 CSQC1220 8 WASHER, SPHERICAL ﾜｯｼｬ 球面 FE
185 CSQC1470 1 NAMEPLATE 銘板 French PL
186 CSQC7500 1 NUT ﾅｯﾄ X-No.493∼ FE .
CP-643E PARTS LIST
44 - 4
44.1.ｱｳﾄｺﾝﾍﾞｱ(逆流れ)(CSQC)
44.1.Out conveyor (Right-to-left-board flow)(CSQC)
