2 Everything you will need for maintenance SIPLACE D3
08/2008 US Edition
10
2 Everything you will need for mainte-
nance
The following lists of materials contain all the tools, equipment and consumables that you will need
to maintain the placement machine. 2
Always use ethyl alcohol for cleaning –
do not use solvents. 2
Apply all lubricants sparingly and exactly where they are needed. 2
2.1 Tools and equipment
: Have the following tools and equipment to hand before you start the maintenance:
Tools and equipment Item number
Waste bin
Vacuum cleaner
Drip tray
Brush
Short-bristled brush
Scissors
Set of hexagon socket spanners
Set of slotted-head screwdrivers
Pliers for fitting plastic hose 2MS-PK-3/4
Angled tweezers 00096487-01
Laboratory gloves (cotton)
Drill bit 1.1 mm diameter 00092020-01
Drill bit, 1.4 mm diameter 00092026-01
Oilstone/whetstone
Grease gun with nozzle for X axis (volume applied: approx. 0.13 g) 00374564-01
Grease gun with hose for Y axis (volu
me applied: approx. 0.4 g) 00374563-01
Universal head stand 00363290-01
2
SIPLACE D3 2 Everything you will need for maintenance
08/2008 US Edition
11
2.2 Consumables
: Have the following consumables to hand before you start the maintenance:
Consumables Item number
Protective latex gloves 00372972-01
Soft, lint-free cloths
Cottonwool buds, lint-free 00352931-02
Microtips medium precision applica
tors (cottonwool buds) 03020860S01
SIPLACE cleaning tissue 00315253-02
Lens cloth
Ethyl alcohol
Compressed air
ISOFLEX TOPAS, NCA 52 00328369-01 1 kg can,
00330850-01 50g tube
UNISILKON L250L 00310259S01
WD40, 400 ml 00325833-01
Z axis oil dispenser with Structovis GHD 00367071-01
Klüberplex BEM 34-132 grease 00374565-01, 1 kg can
Fin Grease spray grease (aerosol) 03020782-01
Interflon Teflon spray (to be replaced with spray grease) 03017760-01
DIN A 3 paper
Adhesive tape
2.3 Consumables
: Have the following consumables to hand before you start the maintenance:
Spare parts Item number
Felt filter RFF-92-10 (92 x 92 mm) (for extension k
it)
Size supplied: 1000 x 1500 x 10 mm
or:
Y-axis air filter (120 x 120 mm)
03006574-xx
03053286-xx
Replacement filter for 5 µm compressed air filter for
pneumatic unit
03004680-xx
03038979-01
Filter element for 5 µm filter (new) fo
r pneumatic unit 03038691-xx 03039182-01
Intake filter 03006548-01
Silencer for the Collect&Place head 03003134S01
O-ring for valve plunger 00359382-01
Set of sleeves 12-segment head: 00116113S01
6-segment head: 00116114S01
Individual sleeves 12-segment head: 00350588S02
6-segment head: 00352957S02
2 Everything you will need for maintenance SIPLACE D3
08/2008 US Edition
12
2.4 Spare parts
: Have the following spare parts to hand before you start the maintenance:
Spare parts Item number
Distributor 00319827S02
O-ring, turning station 00320043S01
Star brake for star, complete 03001653S01
Vacuum generator, complete 03003236S01
Cooling air hose 03012467-01
Gas spring 560N (for hood over 2 gantries) 03036763-01
Gas spring 510 N (for hood over 1 gantry) 03039170-01
Suction plate 00354244S01
Set of valve plungers (6 x) 12-segment head: 00351498-03
6-segment head: 00351500-03
Set of cleaned ceramic nozzles or new plastic nozzles
Z axis toothed belt 00334936S01
Distributor 00319827S02
Toothed belt, turning station 00320041S01
O-ring for distributor 8*1 NBR 70 B 00201179S01
O-ring Venturi nozzle
O-ring 10*1.5 NBR 70 B
O-ring 14*1.5 NBR 70 B
O-ring 8*1 Viton 75
O-ring 10*1 Viton 75
00320047S01
00320048S01
00350661S01
00350662S01
Vacuum generator, complete 03003236S01
Vacuum nozzle, diam. 1.5
Vacuum nozzle, diam.1.0
00319420S03
00319423S02
Silencer 03005121S01
Filter element 40 µm
03003717-01
Spare parts Item number
