Mount the TwinHead 10
10
a Start (for ease of accessing the screws) by fitting the inner module (module 1) of the TwinHead
with four screws. Make sure that the screws are of the right length.
10
: Before attaching the outer module (module 2) to the head, insert the screws into the holes be-
tween the modules.
: Screw the oute
r module on in the same way as the inner one.
s Plug these hoses on and the blanking plug in.
d Connect up the exhaust hoses.
10
: Calibrate the TwinHead.
