14 Maintenance Parts ■ Main Box D R IV E R 1 S E R V O 1 S E R V O 2 V I S I O N C P U D R IV E R 2 1 No. Part No. Part Name Q'ty Remarks Rank 1 KGN-M4255-10X FLASH DISK 1 B
12
Maintenance Parts
■
Laser Back Light
■
Single Vision Camera A
* This date is change instructions day of parts. It is different from the day when a part was changed.This date is change instructions day of parts. It is different from the day when a part was changed.
* この日付は変更指示日です。実際に部品が変更された日とは異なります。
4
6
7
1
2
3
5
1
2
No. Part No. Part Name Q'ty Remarks Rank *Date of change
1 KG7-M4548-00X L.A.M. ASSY 1 B
2 KG7-M7160-00X BACK LIGHT ASSY 1 B
3 KG7-M7168-01X CYLINDER 1 B
4 KM0-M655A-20X SENSOR, 1-1 1 B
5 KM0-M655A-10X SENSOR, 1-1 1 B
6 KG9-M6463-12X
BACK LIGHT BOARD ASSY
1 SPARE B
7 KG7-M7174-10X DIFFUSER 1 SPARE B
No. Part No. Part Name Q'ty Remarks Rank *Date of change
1 KG7-M72A5-00X
FORE LIGHT BOARD ASSY
1 B
2
KG9-M7210-11X CCD CAMERA
1
CS8420i-27
B
2002/9-
KG9-M7210-10X CCD CAMERA 1 XC-75YG B -2002/9
13
Maintenance Parts
■
Single Vision Camera B
■
Exterior
* This date is change instructions day of parts. It is different from the day when a part was changed.This date is change instructions day of parts. It is different from the day when a part was changed.
* この日付は変更指示日です。実際に部品が変更された日とは異なります。
1
2
1
No. Part No. Part Name Q'ty Remarks Rank *Date of change
1 KM7-M7401-00X FORE LIGHT ASSY 1 B
2
KG9-M7210-11X CCD CAMERA
1
CS8420i-27
B
2002/9-
KG9-M7210-10X CCD CAMERA 1 XC-75YG B -2002/9
No. Part No. Part Name Q'ty Remarks Rank *Date of change
1 KH4-M668R-00X HNS,COVER SW 2 LIMIT SWITCH B
14
Maintenance Parts
■
Main Box
D
R
IV
E
R
1
S
E
R
V
O
1
S
E
R
V
O
2
V
I
S
I
O
N
C P U
D
R
IV
E
R
2
1
No. Part No. Part Name Q'ty Remarks Rank
1 KGN-M4255-10X FLASH DISK 1 B
